Summary of Contents for SMC Networks 2208USB/ETH - annexe 1
- Page 2 SMC. SMC assumes no responsibility for any inaccuracies that may be contained in this User Guide. SMC makes no commitment to update or keep current the information in this User Guide, and reserves the right to make changes to this User Guide and/or product without notice.
- Page 3 Note: In order to maintain compliance with the limits of a Class B digital device, SMC requires that you use a quality interface cable when connecting to this device. Changes or modifications not expressly approved by SMC could void the user’s authority to operate...
-
Page 4: Wichtige Sicherheitshinweise (Germany)
EC Conformance Declaration - Class B SMC contact for these products in Europe is: SMC Networks Europe, Edificio Conata II, Calle Fructuós Gelabert 6-8, Planta 2, 08970 - Sant Joan Despí, Barcelona, Spain. This RF product complies with R&TTE Directive 99/5/EC (Annex IV) and with the... - Page 5 Gerät gelangen. Dies könnte einen Brand bzw. elektrischen Schlag auslösen. 13. Öffnen Sie niemals das Gerät. Das Gerät darf aus Gründen der elektrischen Sicherheit nur von authorisiertem Servicepersonal geöffnet werden. 14. Wenn folgende Situationen auftreten ist das Gerät vom Stromnetz zu trennen und von einer qualifizierten Servicestelle zu überprüfen: a.
-
Page 6: Package Contents
Immediately inform your dealer in the event of any incorrect, missing or damaged parts. If possible, please retain the carton and original packing materials in case there is a need to return the product. Please register this product and upgrade the product warranty at SMC's Web site: http://www.smc.com... -
Page 7: Hardware Description
2| Hardware Description SMC’s family of USB products offers a convenient and cost-effective means of bringing straightforward peripheral connectivity to the desktop based on the Universal Serial Bus (USB). These products feature true plug-and-play connection of PC peripherals "outside the box" and mark a significant advance in desktop cable management. - Page 8 3| Driver Installation on Windows 98/ME/2000/XP NOTE: Installation processes such as this may require the use of your original, licensed copy of Windows. Please have your Windows CD available BEFORE proceeding with the installation. Windows 98 1. Make sure your PC is powered on and that you are running the Windows 98 operating system. 2.
- Page 9 5. Select "Search for the Best Driver for your device (Recommended)", click the "Next" button. 6. Select "CD-ROM drive" and click the "Next" button.
- Page 10 7. After Windows finds the driver, click the "Next" button. 8. Windows may request you to "Insert Windows 98 CD-ROM into the driver selected, and click OK". Follow the instruction and insert CD-ROM or disks as needed, direct Windows to the proper location, and then click the "OK"...
- Page 11 11. After restart your computer, connect RJ-45 cable to RJ-45 connector of USB to 10/100 Mbps Ethernet Adapter. The network function is now ready.
-
Page 12: Windows Me
Windows ME 1. Make sure your PC is powered on and that you are running the Windows ME operating system. 2. Insert the EZ Installation Wizard and Documentation CD. 3. Click the [Install Driver] button to continue. 4. Insert the SMC2208SUSB/ETH (the A-type connector) into the USB port on your PC. The system will display the "Add New Hardware Wizard"... - Page 13 5. Windows ME will search and recognize the driver, and then Windows will automatically copy the driver files and related files into the system. After copying the driver files, the installation is completed. Click the "Finish" button. 6. System will ask you "Do you want to restart your computer now". Click the "Yes" button to restart your computer.
- Page 14 Windows 2000 1. Make sure your PC is powered on and that you are running the Windows 2000 operating system. 2. Insert the EZ Installation Wizard and Documentation CD. 3. Click the [Install Driver] button to continue. 4. Insert the SMC2208USB/ETH Ethernet Adapter (the A-type connector) into the USB port on your PC. The system will display the "Found New Hardware Wizard"...
- Page 15 5. Select "Search for a suitable driver for my device (Recommended)" and click the "Next" button. 6. Select "CD-ROM drive" and click the "Next" button.
- Page 16 7. After Windows finds the driver, click the "Next" button. The driver will then install itself. 8. Click the "Yes" button.
- Page 17 9. When Windows finishes the installation, click the "Finish" button. 10. Connect RJ-45 cable to RJ-45 connector of USB to 10/100Mbps Ethernet Adapter. The network function is now ready.
-
Page 18: Windows Xp
Windows XP 1. Make sure your PC is powered on and that you are running the Windows XP operating system. 2. Insert the EZ Installation Wizard and Documentation CD. 3. Click the [Install Driver] button to continue. 4. Insert the SMC2208USB/ETH (the A-type connector) into the USB port on your PC. The system will display the "Found New Hardware Wizard"... - Page 19 5. Windows XP will search and recognize the driver. Windows will automatically copy the driver files and related files into the system. After copying the driver files, the installation is completed. Click the "Finish" button. 6. Connect RJ-45 cable to RJ-45 connector of USB to 10/100Mbps Ethernet Adapter. The network function is now ready.
- Page 20 4| Driver Installation on Mac OS There are two ways to install Driver on Mac OS. First, select the”ADM8513 Driver for Mac OS” folder, and double click the”Installer” icon. Second, follow the steps below. Install 1. On Mac OS9, uncompress the ADM8513_Install_xx_xxxx.sit file 2.
-
Page 21: Troubleshooting
5| Troubleshooting Q1. When I plug in my SMC2208USB/ETH USB to 10/100Mbps Ethernet Adapter, there is no LED indicator signal. A: If your SMC2208USB/ETH doesn't have any LED signal, you need to check if the USB cable is connected to the PC's USB port, or if the Ethernet cable is connected to the network. Q2. -
Page 22: Specifications
6| Specifications Interfaces • Complies with USB specification v1.0 and v1.1 • One 4-pin A-type USB connector • One RJ-45 connector for Ethernet network interface Standards • USB Specification 1.0 and 1.1 • IEEE 802.3 Ethernet • IEEE 802.3u Fast Ethernet Access Method •... - Page 23 Environment • Operating Temperature: 0 ~ 55 C Humidity: 10 ~ 90% • Storage Temperature -20 ~ 65 C Humidity 10 ~ 90% Size • 74.5 x 28.1 x 15.1 mm (L x W x H) Weight • .25oz...
- Page 24 FOR TECHNICAL SUPPORT, CALL: From U.S.A. and Canada (24 hours a day, 7 days a week) (800) SMC-4-YOU; Phn: (949) 679-8000; Fax: (949) 679-1481 From Europe : Contact details can be found on www.smc-europe.com or www.smc.com INTERNET E-mail addresses: techsupport@smc.com european.techsupport@smc-europe.com...
