Living Spaces 1318T-4272 Assembly Instruction

Caution: Please read instructions thoroughly before unpacking assembly parts.Sharp,exposed staple tips can
cause injury,therefore,for your protection,please remove any exposed staples used in packing.
1. We recommend that you should assemble this product with the assistance of another person;this will make
assembly easier, and will help to eliminate damage to the product or injury to persons during assembly.
2. Be sure to check all packing materials carefully for small parts that may have come loose inside the carton
during shipment.
3. Please do not over tighten screws or bolts.
4. Please Put all parts on a non-abrasive floor before assembly, and follow the assembly steps to assemble your
newly purchased product correctly and efficiently.
No.
A TABLE TOP
B TABLE LEG
C STRETCHER 2
D STRETCHER 1
STEP 1
STEP 2
6
1318T-4272/1211T-4272/1319T-4272/1320T-4272
PART LIST
PART DESC
B
Assembly Instruction for
DINING TABLE
No.
Q'TY
1
1
2
2
3
2
4
1
5
6
7
5
4
3
D
B
MADE IN VIETNAM
HARDWARE LIST
HARDWARE DESC
ALLEN BOLT (5/16*90mm)
ALLEN BOLT (5/16*45mm)
FLAT WASHER (5/16*19*1.5mm)
SPRING WASHER (5/16)
ALLEN KEY (M5*60*60mm)
WOOD DOWEL
(ɸ10 x 30mm)
WOODEN CAP (
ɸ21-ɸ19*12mm)
8
x4
7
Q'TY
4
14
18
18
1
2
4
3 4
PAGE 1 OF 2
