Zenox Cloud Series Assembly Manual

Advertisement

Quick Links

Package Content
A
- 1 Chair Spine
B
- 1 Set of Backrests (2pcs)
C
- 1 Cushioned Seat Base
D
- 1 Wheelbase
E
- 1 Set of Armrests (2pcs)
F
- 1 Seat Base Support
G
- 1 Set Casters (5pcs)
H
- 1 Backrest Bracket
I
- 1 Spine Handle
J
- 1 Control Knob
K
- 2 Tightening Knob
L
- 1 Hex Key
M
- 4 M6*20mm Bolts
N
- 10 M6*45mm Bolts
Contact us via email at aftersales@zenoxstore.com,
or WhatsApp™ at +852 8481 7841.
如有需要請以電郵或WhatsApp™跟我們聯絡.
SUPPORT
The product is considerably heavy, grab a friend and do
the installtion together if possible.
產品有一定重量,如果可以找個朋友幫忙安裝.
HEAVY
Stop using the product with damaged parts.
如發現產品有損壞,請立刻停止使用.
CAUTION
Sit in the center of the chair,
back against the backrest.
請坐於椅子中間,背靠椅背.
Do Not Sit at the edge of the chair,
as it will tilt the balance.
請勿坐於椅子邊,造成傾倒危險.
Do Not Stand on the chair, and use
it as any form of stool or ladder.
請勿站在椅子上,或當成梯子或脚踏使用.
Be Careful when using the recliner and
other moving parts of chair.
請小心使用調角器和其他移動部件.
Avoid Direct Sunlight as it would cause
fading and damage the upholstery.
避免陽光直接照射產品,導致面料損壞.
Avoid Strong Chemicals or scrubbing
excessively, as it would cause fading and
damage the upholstery..
避免使用强烈清潔劑或大力摩擦,導致面料損壞.
Cloud Series
Junior Ergonomic Chair Assembly Guide
Assemble Videos
www.zenoxstore.com/pages/assembly-guides

Advertisement

loading
Need help?

Need help?

Do you have a question about the Cloud Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Zenox Cloud Series

  • Page 1 Package Content - 1 Chair Spine - 1 Set of Backrests (2pcs) Cloud Series - 1 Cushioned Seat Base Junior Ergonomic Chair Assembly Guide - 1 Wheelbase - 1 Set of Armrests (2pcs) - 1 Seat Base Support - 1 Set Casters (5pcs)
  • Page 2 Step 03 Step 04 Assemble armrests and seat base. Install the supoort onto the seat base. 把扶手和座墊組合. 把座墊連接件和座墊組合. Step 05 Step 06 Assemble the parts and tighten with knob. Slide on and tighten the backrest bracket. 把部件裝上後用扭扣鎖上 把椅背連接件裝上後用扭扣鎖上 Step 07 Final Step Step 01 Step 02...

This manual is also suitable for:

Junior ergonomic chair
