Advanced Installation Manual
WARNING
!
Installation and service of the boiler must be performed by a qualified installer or service technician.
Read all instructions, including this manual and all other information shipped with the boiler, before
installation or operation. Perform steps in the order given. Failure to comply can result in severe
personal injury, death or substantial property damage.
Models 725/850 Series 1
1500-3000 Series 2
Commercial Condensing
Gas-Fired Water Boilers
1000 Series 1
Manual Part Number 550-143-071/0924
