- Page 2 Introduction Thank you for choosing Bintelli as your next LSV and welcome to the family! As your comfort and safety are very important to us, we strongly recommend that you read and follow the operating instructions in this manual to prolong the service life of your vehicle and to avoid serious personal injury while operating.
-
Page 3: Operating The Vehicle
Operating the Vehicle Prior to use, contact your local DMV for rules and regulations regarding who may legally operate the vehicle. Switch the Tow/Run switch to the “Run” position. Make sure the Forward/Reverse switch is switched to Neutral before switching the ignition to “On”. Do not forget to disengage the parking brake. Once “On”... -
Page 4: Vehicle Information
Vehicle Information The VIN plate (if your vehicle is so equipped) is located on the base of the seat as shown in Fig. 1 On a 4-passenger VIN plate is located on the base of the driver side. On the 6-passenger VIN plate is located on the base of the second row of seats. -
Page 5: Dash Controls
Dash Controls 1. Combination Switch (Fig. 5) 2. Speedometer/LCD Meter **See Fig. 3 for the breakdown of the speedometer controls** 3. Lead Acid Battery Meter 4. Parking Brake (4 Passenger) **Please note 6 Passenger will have a hand brake located on the base of the front seat** 5. - Page 6 LCD Meter (Fig. 3) As shown in Fig. 3, The LCD meter displays the status of the vehicle. Icons that can be seen on the LCD Meter reference the following functions of the vehicle: ● The low beam icon will light up when the vehicle is in the low beam mode. ●...
-
Page 7: Combination Switch
Tow/Run Switch (Also Off/On Switch) (Fig. 4) Warning Pushing or towing the vehicle while in the “Run” position will cause damage to the motor and the electrical components of the cart. This could also cause a potential fire hazard. Combination Switch (Fig. - Page 8 Screen 2.0 Your vehicle features a touch screen infotainment system as pictured below: 1. POWER Button ○ Short press to turn on, long press to shut down 2. HOME Button ○ Press to go into main menu (Fig. 6) or return to display screen 3.
- Page 9 Radio (Fig. 7) 1. FM/AM Band ○ Switches between different FM/AM preset screens 2. Scan ○ Pressing this button will read all stations available and add them to presets menu 3. Introduce ○ Pressing this will switch from one preset to the next with a short pause between each station.
- Page 10 To connect to a device: Open BT setting on your device and choose the specific Beyond ID that is depicted towards the top right of the screen (Fig. 9) Apple devices will automatically ask to connect to Bintelli Play Android devices will automatically connect to Bintelli Auto...
- Page 11 3. Pressing will load music from usb connected device a. This connection is from the top usb port right of the ignition switch Connecting to this port with a Bintelli Play or Auto capable device will initialize the respective player and automatically switch to PhoneLink screen.
- Page 12 7. Pressing will switch to this screen if on any other screen, if on this screen will switch to dash. 8. Pressing will mute volume, shows current volume level 9. Pressing will switch between three brightness options: full, dim, and off. 10.
- Page 13 Solid Green: EcoCast Receiving Mode – Paired with EcoCast Transmitting speaker Solid Yellow: FM Mode vii. Solid Purple: Aux-In 2. Power button a. Short-press to turn the soundbar on / put into Standby. Press and hold for 3 seconds to turn all 4 LED Zones on / of 3.
- Page 14 b. In FM Mode Short press either button to tune to a radio station. To “seek” (jump to the next available station), Press and hold either Button for a few seconds until it starts to seek a station. 13. Play / Pause / Answer / EcoTalk Button: a.
-
Page 15: Maintenance
Maintenance The appropriate care must be used when performing maintenance, service, or accessory installation. Only trained technicians should service or repair the vehicle and/or battery charging system. Repair and service should only be done by those with knowledge and experience in electrical and mechanical repairs. -
Page 16: Battery Meter
Although this does not give you an exact percentage reading as the Lester phone application or infotainment screen does, it also allows you to monitor the vehicle's current state of charge. (only applicable with Bintelli branded lithium batteries) Warning Please make sure the battery is recharged BEFORE the battery power meter shows 20% or less. - Page 17 Eco Branded battery Warning Only licensed technicians should be performing maintenance on batteries with the exception of checking and cleaning terminals while the batteries and vehicle are fully powered off. Please contact your local dealer or Eco Support for anything other than routine battery care. Features for Users Located on the side of the lithium battery.
- Page 18 Lithium Resources Registering Eco Battery- 90 days after purchase for 8 year warranty Eco battery registration Submitting Warranty Claims- Eco Battery Warranty Claims Eco Battery Support- support@ecobattery.com For additional questions and customer support, please contact your local dealer or Bintelli directly.
-
Page 19: Regular Maintenance Checklist
Regular Maintenance Checklist C=Check, CA=Check/Adjust, R=Replace, S=Perform, CL=Clean/Lubricate Before Every Every 6 Every Every 2 Every 4 month/20 months/125 year/250 years/500 years/1000 hours/ 100 house/600 hours/1200 hours/2500 hours/5000 miles miles miles miles miles Battery Charger Clean battery Check brakes Check Steering Check tires... - Page 20 Client Responsibilities Battery Cables – Cleaning cables and ensuring the surface is free of moisture and debris. Checking cables and securing connections to Battery. Charger Power Cord – Do not remove the manufacturer tag on the power cord as doing so will void the warranty.
