Summary of Contents for Bintelli Beyond
-
Page 2: Security Statements
Introduction Thank you for choosing Bintelli Electric Vehicles, welcome to the family. Your comfort and safety are very important to us, we strongly recommend that you read and follow the operating instructions in this manual, to avoid serious personal injury. Please make sure anyone operating your vehicle is familiar with the cart's functions. - Page 3 Caution Do NOT shift from Forward or Reverse while the vehicle is moving. Please note your vehicle has regenerative braking and will start slowing down when the accelerator is not pressed. Exercise caution in areas such as: ● Steep sloped ●...
-
Page 4: Vehicle Information
Vehicle Information The VIN plate is located on the base of the seat as shown in Fig. 1 On a 4-passenger VIN plate is located on the base of the driver side. On the 6-passenger VIN plate is located on the base of the second row of seats. -
Page 5: Dash Controls
Dash Controls 1. Combination Switch Fig. 5 2. Speedometer/LCD Meter **See Fig. 3 for the breakdown of the speedometer controls** 3. Lead Acid Battery Meter 4. Parking Brake (4 Passenger) **Please note 6 Passenger will have a hand brake located on the base of the seat** 5. Brake Pedal 6. Accelerator Pedal... - Page 6 LCD Meter Fig. 3 As shown in Fig. 3, it is used to display the status of the vehicle. All the below icons can be seen on the LCD Meter. ● The low beam icon will light up when the vehicle is in the low beam mode. ● The high beam icon will light up when the vehicle is in the high beam mode.
-
Page 7: Combination Switch
Tow/Run Switch (Also Off/On Switch) Warning Pushing or towing the vehicle while in the “Run” position will burn up the motor and the electrical components of the cart. This is a significant fire hazard. Combination Switch ● Turn signals ○ Push up to turn on the right turn signal. ○ Push down to turn on the left turn signal. - Page 8 Radio Instructions for Bluetooth: Turn on Bluetooth on the cellphone, search Bluetooth device name “BEYOND” and press connect. If the connection has been successful the word “CONNECT'' will be displayed on the radio screen. Once the pairing is complete, BT AUD mode will show in MOD function mode. In BT AUD mode, you can play music from your phone and answer phone calls by pressing the Volume button and hang up by pressing the BND button.
- Page 9 ● Do not operate the vehicle under the influence of alcohol or drugs. ● Do not attempt to go uphill/slopes beyond its grade ability. ● Do not pass other vehicles at crossroads, blind areas, or any dangerous conditions.
-
Page 10: Maintenance
● Verify each battery is filled to the proper lever with distilled water (if using lead acid batteries) and all cable connections are secure. ● Clean the body, seats, battery box, and chassis. ● If storing outdoors, cover the vehicle with a storage cover. ● Plug in the onboard smart charger and leave it plugged in. -
Page 11: Lead Acid Batteries
Lead Acid Batteries Our standard vehicles are equipped with lead-acid batteries. The quantity of batteries will vary depending on the cart model. See Figure 1 and Figure 2 below for distinction. Warning Battery electrolyte is poisonous and dangerous and may cause severe burns and injury. Always wear gloves and protective eye gear when working around battery electrolytes. - Page 12 Warranty Claims: Contact Continental Battery Systems Customer Experience (844) 935-1186 for any warranty questions/claims. For additional questions and customer support, please contact your local dealer or Bintelli manufacturer. Cleaning Batteries can attract dust, dirt, and grime. Keeping them clean will help you spot signs of trouble if they appear, and avoid problems associated with grime.
-
Page 13: Lithium Batteries
Please make sure the battery is recharged BEFORE the battery power meter shows 20% or less. An overcharged battery will have a short service life. Watering Distilled water should always be added after fully charging. Before charging, there should be enough water to cover the plates. - Page 14 For more details, visit the user link found in the Lithium Manual section. There are different variations of lithium ion features in the Beyond editions. It’s important to note that the state of charge feature will change depending on the charger in the cart.
- Page 15 Lithium Resources Registering Eco Battery- 90 days after purchase for 8 year warranty Eco battery registration Submitting Warranty Claims- Eco Battery Warranty Claims Eco Battery Support- support@ecobattery.com For additional questions and customer support, please contact your local dealer or Bintelli manufacturer.
-
Page 16: Regular Maintenance Checklist
Regular Maintenance Checklist C=Check, CA=Check/Adjust, R=Replace, S=Perform, CL=Clean/Lubricate Before Every Every 6 Every Every 2 Every 4 month/20 months/125 year/250 years/500 years/1000 hours/ 100 house/600 hours/1200 hours/2500 hours/5000 miles miles miles miles miles Battery Charger Clean batteries Check brakes Check Steering Check tires... - Page 17 Client Responsibilities Batteries – Battery fluid must be checked at least once monthly for lead acid. Use distilled water only. Do not overfill. Battery Cables – Tighten battery cables per battery manufacturer instructions located on batteries. Failure to tighten once a month could result in damage to the batteries. BEFORE placing the vehicle into service, please check all battery cables and tighten as they may become loose due to turbulence in shipping.
