OWNER'S MANUAL

FLOOR CONSOLE INDOOR UNIT

DRAS09F2A, DRAS12F2A, DRAS16F2A

R-454B, 208/230V, 1ph 60HZ

Model Number:

Serial Number:

Purchase Date:

Installing Contractor Company Name:

TIP

Capture relevant information about your Durastar mini-split equipment before it is

installed and write it above for future reference.

FPO

DURASTAR.COM

Table of Contents

Need help?

Do you have a question about the DRAS09F2A and is the answer not in the manual?

Questions and answers

Summary of Contents for DURASTAR DRAS09F2A

Page 1 FLOOR CONSOLE INDOOR UNIT DRAS09F2A, DRAS12F2A, DRAS16F2A R-454B, 208/230V, 1ph 60HZ Model Number: Serial Number: Purchase Date: Installing Contractor Company Name: Capture relevant information about your Durastar mini-split equipment before it is installed and write it above for future reference. DURASTAR.COM...
Page 2: Table Of Contents
OPERATING MODES ......................21 ADVANCED BUTTONS AND FEATURES ..............22 LOUVERED AIR FLOW ......................26 LED DISPLAY INDICATORS ....................28 MANUAL OPERATION (USE WITHOUT REMOTE) ..........28 CARE AND MAINTENANCE ....................29 TROUBLESHOOTING ......................32 LIMITED WARRANTY - PARTS..................36 DURASTAR.COM...
Page 3: Introduction
• Read the troubleshooting section of this manual as it will help you diagnose and solve common issues. • Visit us on the web at www.durastar.com to download product guides and up-to-date information. • If you need warranty service, our friendly customer service representatives are available via email at questions@durastar.com or by telephone at 1-888-320-0706.
Page 4: Important Safety Precautions
Do not operate your air conditioner in a wet room such as a bathroom or laundry room. Too much exposure to water can cause electrical components to short circuit. • If the air conditioner is used together with burners or other heating devices, thoroughly ventilate the room to avoid oxygen deficiency. DURASTAR.COM...
Page 5 For units that have an auxiliary electric heater, do not install the unit within 3 feet (1 meter) of any combustible materials. • Do not install the unit in a location that may be exposed to combustible gas leaks. If combustible gas accumulates around the unit, it may cause a fire. DURASTAR.COM...
Page 6 When the refrigerant sensor malfunctions, the indoor unit will display the error code “FHCC”. The refrigerant sensor can not be repaired and can only be replaced by the manufacturer. It shall only be replaced with the sensor specified by the manufacturer. DURASTAR.COM...
Page 7 All training shall follow the ANNEX HH requirements of UL 60335-2-40 4th Edition. Examples for such working procedures are: • breaking into the refrigerating circuit; • opening of sealed components; • opening of ventilated enclosures. DURASTAR.COM...
Page 8 Where electrical components are being changed, they shall be fit for the purpose and to the correct specification. At all times the manufacturer’s maintenance and service guidelines shall be followed. If in doubt consult the manufacturer’s technical department for assistance. The following checks shall be applied to installations using FLAMMABLE REFRIGERANTS: DURASTAR.COM...
Page 9 (25 % maximum) is confirmed. • Leak detection fluids are also suitable for use with most refrigerants but the use of detergents containing chlorine shall be avoided as the chlorine may react with the refrigerant and corrode the copper pipe-work. DURASTAR.COM...
Page 10 Prior to recharging the system it shall be pressure tested with OXYGEN FREE NITROGEN • (OFN). The system shall be leak tested on completion of charging but prior to commissioning. • A follow up leak test shall be carried out prior to leaving the site. DURASTAR.COM...
Page 11 If in doubt, the manufacturer should be consulted. In addition, a set of calibrated weighing scales shall be available and in good working order. Hoses shall be complete with leak-free disconnect couplings and in good condition. DURASTAR.COM...
Page 12 The effectiveness of signs should not be diminished by too many signs being placed together. Any pictograms used should be as simple as possible and contain only essential details. Disposal of equipment using flammable refrigerants: See national regulations. Storage of equipment/appliances: The storage of the appliance should be in accordance with DURASTAR.COM...
Page 13 Composition: R-454B is classified as safety group A2L per ASHRAE Standard 34. Verify that service equipment and instruments are certified for use with group A2L refrigerants, and in particular with R-454B is a non-azeotropic mixture of 68.9% by weight difluorometh ane (HFC- 32) and 31.1 % by weight 2,3,3,3-tetrafluoro-1-propene (HFO-1234yf). DURASTAR.COM...
Page 14 When the unit detects a refrigerant leak, the minimum airflow of the indoor unit is as follows : Model DRAS09F2A DRAS12F2A DRAS16F2A Nominal Air Volume 353 CFM (600 m³/h) 418 CFM (710 m³/h) 448 CFM (760 m³/h)
Page 15: Fcc Compliance Statement
Newport News, VA City, State： 23606 Postal Code： Durastar.com Telephone number or internet contact information： FCC Compliance Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 16: Accessories
An example is Pb: Lead (>0.004%). Appliances and used batteries must be treated in a specialized facility for reuse, recycling and recovery. By ensuring correct disposal, you will help avoid possible negative consequences for the environment and human health. DURASTAR.COM...
Page 17: Operating Temperatures
Regularly inspect and clean air filters. NOTE Your Durastar air conditioner's outdoor unit is equipped with a base pan heater, allowing it to continue to operate at freezing temperatures as low as -22°F (-30°C). When outdoor air temperatures are at or below 32°F (0°C), we strongly recommend keeping the unit plugged in at all times to ensure smooth ongoing performance.
Page 18: Parts Identification
Control Outlet and Louver Holder Air Freshening Filter Drain Hose Air Filter Refrigerant Pipes OUTDOOR UNIT Signal Cable Wiring Air Inlets Terminal Refrigerant Pipes Outdoor Unit Power Cable Valve Cover Air Outlet NOTE Outdoor units will vary in appearance. DURASTAR.COM...
Page 19: Remote Control
13. HUMIDITY Button: Adjust the room humidity during DRY operation in a range of 35%~85%. Press to increase the humidity in 5% increments. After setting, the humidity settings will display on the screen. 14. LED Button: Press to turn on and off the indoor unit's display screen. DURASTAR.COM...
Page 20: Remote Control Screen Indicators
35% - 85% This display is blank when operating in FAN mode. NOTE All indicators shown in the above figure are for purposes of clear representation. During actual operation, only the relative indicators are illuminated in the display window. DURASTAR.COM...
Page 21: Operating Modes
*For this series of mini-splits, changing the temperature in DRY mode does not deviate performance from the above mode description. NOTE The FAN speed cannot be adjusted in AUTO or DRY Mode. NOTE Press and hold the UP and DOWN buttons simultaneously for 3 seconds to switch between °F and °C. DURASTAR.COM...
Page 22: Advanced Buttons And Features
25% or 50% based on the selection. Press the ECO/GEAR button to turn off this feature. NOTE The overall energy consumption of the unit is affected by many factors and this feature's energy reduction level setting will not result in directly proportional money savings on your energy bill. DURASTAR.COM...
Page 23 Press and hold the TURBO button again for seven (7) seconds to unlock and turn off this feature. The remote will display "OF" for three (3) seconds. NETWORK SETUP ( This feature is only shown if available on this unit. DURASTAR.COM...
Page 24 GENTLE button to slow the unit and divert the air flow away from you. Press the GENTLE button again to turn this feature off. This feature is only available under COOL, DRY, and FAN modes. This feature is not available in multiple zone configurations. DURASTAR.COM...
Page 25 The LOCK feature disables the remote's buttons so your settings cannot be changed. To activate the remote LOCK feature, simultaneously press the CLEAN and TURBO buttons for five (5) seconds. To turn off the LOCK feature, simultaneously press CLEAN and TURBO again for five (5) seconds. DURASTAR.COM...
Page 26: Louvered Air Flow
Quickly press the SWING button 2-6 times to adjust the fixed angle of the louver. Each press will adjust the louver by 6°. Press the button until the desired angle is reached. The remote will display the selected angle. The unit automatically remembers the louver angle next time it is turned on. DURASTAR.COM...
Page 27 1. Within 10 minutes of powering the unit on, press and hold the MANUAL button for 5 seconds. 2. Press the MANUAL button again to open or close the lower air louver. NOTE During the setting process, the display panel displays the status of the lower air louver. ON - open OF - closed DURASTAR.COM...
Page 28: Led Display Indicators
3. Press the MANUAL button once to activate AUTO mode (heating or cooling). 4. Press the MANUAL button twice to enter TEST mode.TEST mode runs for 30 minutes in the COOLING mode, then runs in the AUTO mode after. 5. Press the MANUAL button three times to turn the unit off. DURASTAR.COM...
Page 29: Care And Maintenance
• Do not use water to clean the inside of the indoor unit. This can destroy insulation and cause electrical shock. • Do not expose filter to direct sunlight when drying. This can shrink the filter. DURASTAR.COM...
Page 30 5. Clean the main air filter by gently vacuuming the surface or washing it in warm water with a mild detergent. 6. Rinse the filter with clean water and allow it to air dry. Do not dry the filter in direct sunlight. 7. Replace the air freshening filters. 8. Reinstall the filter. DURASTAR.COM...
Page 31: Maintenance - Long Periods Of Non-Use
After long periods of non-use, or before periods of frequent use, do the following: • Inspect for damaged wires • Clean all filters. • Check for leaks. • Replace batteries. • Make sure nothing is blocking the air inlets and outlets. DURASTAR.COM...
Page 32: Troubleshooting
The indoor unit makes A rushing air sound may occur when the louver resets its position. noises A squeaking sound may occur after running the unit in HEAT mode due to expansion and contraction of the unit’s plastic parts. DURASTAR.COM...
Page 33 • Press ON/OFF button on remote control to restart operation. NOTE If problem persists, contact a local dealer or your nearest customer service center. Provide them with a detailed description of the unit malfunction as well as your model number. DURASTAR.COM...
Page 34 The unit may stop operation or continue to run safely. If the indicator lamps lamps continue to flash or error codes appear, wait for about 10 minutes. The problem continue may resolve itself. flashing or If the problem persists, contact your nearest service technician. error code appears DURASTAR.COM...
Page 35 Wait three minutes after restarting the been activated unit Timer is activated Turn timer off NOTE If your problem persists after performing the checks and diagnostics above, or the error code remains, turn off your unit immediately and contact an authorized service center. DURASTAR.COM...
Page 36: Limited Warranty - Parts
Covered Equipment Parts are warranted to be free from defects in material and workmanship for a period of seven (7) years from the date of installation, under normal use and service. Durastar will, at its option, repair or replace any part determined by Durastar to be defective. Replacement parts carry the balance of the original parts warranty.
Page 37 These items will be required to complete any warranty service. A Durastar authorized representative will verify warranty eligibility and determine appropriate service options. Service will be provided during normal business hours.
Page 38 THIS PAGE INTENTIONALLY LEFT BLANK. DURASTAR.COM...
Page 39 THIS PAGE INTENTIONALLY LEFT BLANK. DURASTAR.COM...
