INSTALLATION MANUAL
WALL MOUNTED INDOOR UNIT
SPLIT-STYLE AIR CONDITIONER
DRAW09F1A, DRAW12F1A, DRAW18F1A, DRAW24F1A
Model Number:
Serial Number:
Purchase Date:
Installing Contractor Company Name:
TIP
Capture relevant information about your Durastar mini-split equipment before it is
installed and write it above for future reference.
1
FPO
DURASTAR.COM
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for DURASTAR DRAW09F1A
Summary of Contents for DURASTAR DRAW09F1A
- Page 1 WALL MOUNTED INDOOR UNIT SPLIT-STYLE AIR CONDITIONER DRAW09F1A, DRAW12F1A, DRAW18F1A, DRAW24F1A Model Number: Serial Number: Purchase Date: Installing Contractor Company Name: Capture relevant information about your Durastar mini-split equipment before it is installed and write it above for future reference. DURASTAR.COM...
-
Page 2: Table Of Contents
STEP 5: CONNECT THE DRAIN PIPE ....................15 STEP 6: CONNECT SIGNAL CABLE ....................16 STEP 7: PREPARE REFRIGERANT PIPING .................. 18 STEP 8: WRAPPING THE CABLES ....................18 STEP 9: MOUNT INDOOR UNIT ......................18 TROUBLESHOOTING ..........................20 DURASTAR.COM... -
Page 3: Introduction
• Read the troubleshooting section of this manual as it will help you diagnose and solve common issues. • Visit us on the web at www.durastar.com to download product guides and up-to-date information. • If you need warranty service, our friendly customer service representatives are available via email at questions@durastar.com or by telephone at 1-888-320-0706. -
Page 4: Important Safety Precautions
Do not wash the air conditioner with water as this could cause an electric shock. • Disconnect the power supply by turning it off at the circuit breaker when cleaning the air conditioner. Otherwise, you could risk electric shock. DURASTAR.COM... - Page 5 • The air conditioner’s circuit board (PCB) is designed with a fuse to provide overcurrent protection. The specifications of the fuse are printed on the circuit board. DURASTAR.COM...
- Page 6 Do not climb onto or place objects on top of the outdoor unit. • Do not allow the air conditioner to operate for long periods of time with doors or windows open, or if the humidity is very high. DURASTAR.COM...
-
Page 7: Operating Temperatures
Regularly inspect and clean air filters. NOTE Your Durastar air conditioner's outdoor unit is equipped with a base pan heater, allowing it to continue to operate at freezing temperatures as low as -13°F (-25°C). When outdoor air temperatures are at or below 32°F (0°C), we strongly recommend keeping the unit plugged in at all times to ensure smooth ongoing performance. -
Page 8: Accessories
The following installation accessories are required and must be purchased separately. • Refrigerant piping (line set) • Indoor and outdoor connection wire • Outdoor power supply cord • Drain pipe • Pipe and cable wrapping tape • Wall hole sleeve and cover • Putty • Wiring u-lugs DURASTAR.COM... - Page 9 Refrigerant leak detector • Copper pipe cutter • Flaring tool • Burr reamer • Crescent or spanner wrench • Hexagonal wrench set • Torque wrench • Multimeter • Electroprobe • Level • Hammer • Wire strippers • Wire crimper DURASTAR.COM...
-
Page 10: Parts Identification
Remote Controller Holder Drain Pipe Indoor Unit Power Cable Outdoor Unit Power Cable Signal Cable Air Flow Louver Refrigerant Piping NOTE Illustrations in this manual are for explanatory purposes. The actual shape of your mini- split equipment may vary slightly. DURASTAR.COM... -
Page 11: Installation Overview - Indoor Unit
INSTALLATION OVERVIEW - INDOOR UNIT 15cm (5.9in) 12cm 12cm (4.75in) (4.75in) 2.3m (90.55in) Attach Mounting Plate Select Installation Location Determine Wall Hole Position Drill Wall Hole Connect Piping Connect Wiring Wrap Piping and Cable Prepare Drain Pipe STEP Mount Indoor Unit DURASTAR.COM... -
Page 12: Indoor Unit Installation
The default position for all piping is the right side of the indoor unit (while facing the unit). However, the unit can accommodate piping to either the left or right. DURASTAR.COM... -
Page 13: Step 2: Attach Mounting Plate To Wall
2 1/8” (54mm) Indoor unit outline 5 7/8” (149mm) 1 15/16” (49mm) Left rear wall Right rear wall 5 7/16” (138mm) hole 2 1/2” (64mm) hole 2 1/2” (64mm) 5 7/8” (149mm) 42 1/2” (1080mm) Model 18K and 24K DURASTAR.COM... -
Page 14: Step 4: Prepare Refrigerant Piping
Connect the Drain Pipe. If there is no pre-existing piping, connect the indoor unit’s refrigerant piping to the connective piping that will join the indoor and outdoor units. Refer to the Refrigerant Piping Connections section of your outdoor unit's installation manual for detailed instructions. DURASTAR.COM... -
Page 15: Step 5: Connect The Drain Pipe
NOT CORRECT NOT CORRECT Do not place the end of the Kinks in the drain pipe drain pipe in water or in will create water traps. containers that collect water. This will prevent proper drainage. DURASTAR.COM... -
Page 16: Step 6: Connect Signal Cable
After turning off the power, always wait 10 minutes or more before you touch the electrical components. WARNING Before performing any electrical or wiring work, turn off the main power to the system. DURASTAR.COM... - Page 17 8. Replace the wire cover on the front of the unit and the plastic panel on the back. WARNING All wiring must be performed strictly in accordance with the wiring diagram located on the back of the indoor unit's front panel. DURASTAR.COM...
-
Page 18: Step 7: Prepare Refrigerant Piping
2. Double-check that the ends of the refrigerant pipes are sealed to prevent dirt or foreign materials from entering the pipes. 3. Slowly pass the wrapped bundle of refrigerant pipes, drain pipe, and signal wire through the hole in the wall. DURASTAR.COM... - Page 19 If you find that you don’t have ample room to connect embedded pipes to the indoor unit, the unit can be adjusted left or right by about 1 1/4-2" (30-50mm), depending on the model. 1 1/4 - 2” 1 1/4 - 2” (30-50mm) (30-50mm) Adjust left or right DURASTAR.COM...
-
Page 20: Troubleshooting
The indoor unit makes A rushing air sound may occur when the louver resets its position. noises A squeaking sound may occur after running the unit in HEAT mode due to expansion and contraction of the unit’s plastic parts. DURASTAR.COM... - Page 21 • Press ON/OFF button on remote control to restart operation. NOTE If problem persists, contact a local dealer or your nearest customer service center. Provide them with a detailed description of the unit malfunction as well as your model number. DURASTAR.COM...
- Page 22 Incompressible gas or moisture has Evacuate and recharge the system with frequently entered the system refrigerant The compressor is broken Replace the compressor The voltage is too high or too low Install a manostat to regulate the voltage DURASTAR.COM...
- Page 23 If the problem persists, disconnect the power and contact your nearest appears customer service center. NOTE If your problem persists after performing the checks and diagnostics above, turn off your unit immediately and contact an authorized service center. DURASTAR.COM...
- Page 24 ©2021 Durastar DURASTAR.COM V1.0 0221...
