Dimensions Furniture 8509 Assembly Instructions

Sofa table

Advertisement

Quick Links

Thank you for purchasing our fine product!
This package contains all tools necessary for assembly.
WARNING
: Failure to follow these directions and warnings can result in serious injury
and/or product damage.
!
Assistance is required to assemble this table.
!
Never stand on the table or use it as a ladder.
!
Do not place hot items directly on the table.
!
Periodically re-tighten all bolts and legs.
!
Do not exceed 100 lbs. (45.36 kg) weight limit on the table.
!
If any parts become missing, damaged or worn, discontinue use until they are replaced with identical parts.
!
Always seek assistance before moving furniture.
#8509 Sofa Table
Assembly Instructions
Give us a chance to make it right.
Do not return this item to the store. Contact our friendly customer
service department with any problems or comments. Replacements
for missing or damaged parts are normally shipped the same day!
TOLL FREE: 1-866-528-8364
Monday - Friday, 8am-5pm, ET. After business hours, leave a message.
We will return your call the next business day.
#8509 Sofa Table
D
i m e n
i o n
s
Furniture
Page 1
s
