Dimensions Furniture 1700 CHAISE Assembly Instructions

Advertisement

Thank you for purchasing our fine product!
This package contains all tools necessary for assembly.
WARNING
: Failure to follow these directions and warnings can result in serious injury
and/or product damage.
!
Assistance is required to assemble this chaise.
!
Never stand on the chaise or use it as a ladder.
!
Do not tip the chaise when seated.
!
Periodically re-tighten all bolts and legs.
!
Do not exceed 400 lbs. (181.4 kg) weight limit on the chaise.
!
If any parts become missing, damaged or worn, discontinue use until they are replaced with identical parts.
!
Always seek assistance before moving furniture.
#1700 CHAISE
Assembly Instructions
Give us a chance to make it right.
Do not return this item to the store. Contact our friendly customer
service department with any problems or comments. Replacements
for missing or damaged parts are normally shipped the same day!
TOLL FREE: 1-866-528-8364
Monday - Friday, 8am-5pm, ET. After business hours, leave a message.
We will return your call the next business day.
#1700 CHAISE
D
i m e n
i o n
s
Furniture
Page 1
s

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1700 CHAISE and is the answer not in the manual?

Questions and answers

Summary of Contents for Dimensions Furniture 1700 CHAISE

  • Page 1 #1700 CHAISE Assembly Instructions Furniture Thank you for purchasing our fine product! This package contains all tools necessary for assembly. Give us a chance to make it right. Do not return this item to the store. Contact our friendly customer service department with any problems or comments.
  • Page 2 #1700 CHAISE Assembly Instructions Furniture PARTS LIST Part Part Name Qty. Part Part Name Qty. Drawing Drawing CHAISE CHAISE SEAT BACK FRONT REAR BOLT WITH ALLEN WASHERS WRENCH Step 1 - Remove all parts from their packaging and confirm that the quantities match those listed above.
  • Page 3 #1700 CHAISE Assembly Instructions Furniture Step 2 - Lay the chaise back (PART B) on a large flat surface. Align the bolt holes in the back of the chaise seat (PART A) with the bolt holes in the bottom-front of the chaise back. Portion of dust cover may need to be pulled back in order to locate the bolt holes in the chaise seat.
  • Page 4 #1700 CHAISE Assembly Instructions Furniture Step 6 - With front portion of the dust cover pulled back, align the bolt holes in in the front legs (PART C) with the bolt holes in the side aprons of the chaise seat.
