Dimensions Furniture MoDRN Retro Glam Marion Assembly Instructions Manual

Sleigh base bookcase
Hide thumbs

Advertisement

Available languages

Available languages

Quick Links

Download this manual
ASSEMBLY INSTRUCTIONS
Model: #9093B
MōDRN Retro Glam Marion Sleigh Base Bookcase
Lot Number: _________________
Date of Purchase: ___ / ___ / ____
WARNING The maximum load capacity as listed above may not be exceeded and is assumed
!
to be distributed evenly. Exceeding load capacity may result in collapse and possible injury.
Item must be anchored to the wall by using the included no-tip kit.
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Thank you for your purchase. We want to make sure it is to your complete satisfaction. Hardware is separated individually for easy
all present.
If any parts are missing or defective please contact our customer service department.
Customer Service - 1-866-528-8364 / support@dimensionsfurniture.com
Your satisfaction is our top priority. Our products are designed and manufactured to meet the highest quality. In the event that
you have assembly questions, or parts are missing or damaged, please do not return the product.
Our customer service department would appreciate the opportunity to provide any help necessary regarding assembly and to
provide any necessary parts.
Manufactured by: Dimensions Furniture, Inc
341 Gradle Drive, Carmel, IN 46032
1-866-528-8364 / support@dimensionsfurniture.com
25 lbs
Each shelf has a 25 lbs
Maximum Load,
distributed evenly.
1/16

Advertisement

loading
Need help?

Need help?

Do you have a question about the MoDRN Retro Glam Marion and is the answer not in the manual?

Questions and answers

Related Manuals for Dimensions Furniture MoDRN Retro Glam Marion

Summary of Contents for Dimensions Furniture MoDRN Retro Glam Marion

  • Page 1 ASSEMBLY INSTRUCTIONS Manufactured by: Dimensions Furniture, Inc Model: #9093B 341 Gradle Drive, Carmel, IN 46032 MōDRN Retro Glam Marion Sleigh Base Bookcase 1-866-528-8364 / support@dimensionsfurniture.com Lot Number: _________________ Date of Purchase: ___ / ___ / ____ 25 lbs Each shelf has a 25 lbs Maximum Load, distributed evenly.

  • Page 2: Pre-Assembly Preparation

    PRE-ASSEMBLY PREPARATION: CAUTION ! Please read below statements before beginning assembly.   Assembly should take place in a secure environment that is clean and dry.  Assembly can be done by one person, but two persons are recommended.  Allen wrench available for assembly.
  • Page 3 PRE-ASSEMBLY PREPARATION: PARTS LIST Bottom Panel Central Leg 2pcs 3/16...
  • Page 4 STEP-BY-STEP ASSEMBLY Step 1 Lay a Side Frame on a at surface with the holes facing up as shown. Fasten three Cross Rails to the Side Frame with six Short Bolts with Washers using an Allen Wrench as shown. NOTE: Tighten evenly. Do not over tighten. Next, roll the assembly over on its side as shown.
  • Page 5 STEP-BY-STEP ASSEMBLY Step 2 Fasten only the top Cross Rail to the other Side Frame with two Short Bolts with Washers using an Allen Wrench as shown, but keep bolts loose. Flip the assembly upright, as shown. Short Bolt with Washers (1/4”...
  • Page 6 STEP-BY-STEP ASSEMBLY Step 3 Fasten the remaining Cross Rails to the Side Frame with four Short Bolts with Washers using an Allen Wrench shown, but keep bolts loose. Once all bolts have been inserted, tigthen them while ensuring the Side Frames and Cross Rails are properly aligned with each other.
  • Page 7 STEP-BY-STEP ASSEMBLY Fasten the Top Panel to the assembly with four Long Bolts with Washers using an Allen Wrench as shown. Step 4 NOTE: Tighten evenly. Do not Over tighten. Long Bolt with Washers (1/4” x 1-1/2”) Allen Wrench 7/16...
  • Page 8 STEP-BY-STEP ASSEMBLY Step 5 Carefully Guide a Shelf through the Side Frame in the location shown. Once the Shelf is fully inserted, lay it at and align the corresponding holes on the Shelf and Side Frames . NOTE: To ensure the shelf & frame won’t be damaged as the shelf is guided through the side frame, make sure to tilt it as shown.
  • Page 9 STEP-BY-STEP ASSEMBLY Step 6 Fasten the Shelf to the assembly with four Long Bolts with Washers using an Allen Wrench as shown. NOTE: Tighten evenly. Do not Over tighten. Long Bolt with Washers (1/4” x 1-1/2”) Allen Wrench 9/16...
  • Page 10 STEP-BY-STEP ASSEMBLY Step 7 Carefully Guide a Shelf through the Side Frame in the location shown. Once the Shelf is fully inserted, lay it at and align the corresponding holes on the Shelf and Side Frames . NOTE: To ensure the shelf & frame won’t be damaged as the shelf is guided through the side frame, make sure to tilt it as shown.
  • Page 11 STEP-BY-STEP ASSEMBLY Step 8 Fasten the Shelf to the assembly with four Long Bolts with Washers using an Allen Wrench as shown. NOTE: Tighten evenly. Do not Over tighten. Long Bolt with Washers (1/4” x 1-1/2”) Allen Wrench 11/16...
  • Page 12 STEP-BY-STEP ASSEMBLY Step 9 Carefully Guide the Bottom Panel through the Side Frame in the location shown with the holes facing down. Once the Bottom Panel is fully inserted, lay it at and align the corresponding holes on the Bottom Panel and Side Frames .
  • Page 13 STEP-BY-STEP ASSEMBLY Fasten the Bottom Panel to the assembly with four Long Bolts with Washers using an Allen Wrench as shown. Step 10 NOTE: Tighten evenly. Do not Over tighten. With help, stand the bookcase up with the bottom facing up as shown.
  • Page 14 STEP-BY-STEP ASSEMBLY Step 11 Attach both Central Legs to the assembly, as shown, using eight Short Bolts with Washers . Be sure to leave bolts loose until each bolt is inserted properly then go back and tighten evenly with an Allen Wrench NOTE: Do not over tighten.
  • Page 15 STEP-BY-STEP ASSEMBLY Step 12 With help, move the assembled Bookcase into its desired location. Secure the Bookcase to the wall by using the included No-Tip Kit . Locate a wall stud behind the Bookcase. Position one of the brackets on a stud approximately 1” below the top of the Bookcase.

  • Page 16: Limited One-Year Warranty

    Warranty available to original purchaser only. Proof of purchase is required. This warranty is your sole remedy for product defect and does not cover damage due to mishandling, misuse, or abuse. The manufacturer is not responsible for incidental or consequential damages. Dimensions Furniture, Inc 341 Gradle Drive, Carmel, IN 46032 1-866-528-8364 / support@dimensionsfurniture.com...
  • Page 17 Printed in China...
  • Page 18 INSTRUCIONES DE ENSAMBLAJE Manufactured by: Dimensions Furniture, Inc Modelo: #9093B 341 Gradle Drive, Carmel, IN 46032 MōDRN Retro Glam Marion Sleigh Base Bookcase 1-866-528-8364 / support@dimensionsfurniture.com Numero de Lote: _________________ Fecha de Compra: ___ / ___ / ____ 25 lbs Cada estante tiene una capacidad de peso máximo...
  • Page 19 PREPARACIÓN DE PRE-ENSAMBLAJE: ¡PRECAUCIÓN! Por favor lea las instrucciones antes de comenzar el ensamblaje. Ensamble en una super cie plana y pareja.  El ensamble debe realizarse en un ambiente limpio y seco.  El ensamble lo puede hacer una sola persona pero se recomienda dos personas. ...

  • Page 20: Panel Inferior

    PREPARACIÓN PRE-ENSAMBLAJE: LISTA DE PIEZAS Panel Inferior Pata Central 2pcs 3/16...
  • Page 21 ENSAMBLE PASO POR PASO Paso 1 Coloque un Marco Lateral sobre una super cie plana con los agujeros hacia arriba como en la gura. Fije tres Rieles Transversales al Marco Lateral con seis Pernos Cortos con Arandelas usando una Llave Allen , como en la gura.
  • Page 22 ENSAMBLE PASO POR PASO Paso 2 Fije solo el Riel Transversal superior al otro Marco Lateral con dos Pernos Cortos con Arandelas usando una llave Allen como en la gura, pero mantenga los pernos sueltos. Voltee el ensamblaje en posición vertical, como se muestra. Perno Corto con Arandelas (1/4”...
  • Page 23 ENSAMBLE PASO POR PASO -STEP ASSEMBLY Paso 3 Fije los Rieles Transversales restantes al Marco Lateral con cuatro Pernos Cortos con Arandelas usando una Llave Allen como se muestra, pero mantenga los pernos sueltos. Una vez que se hayan insertado todos los pernos, ajústelos mientras se asegura que los Marcos Laterales y los Rieles Transversales C estén alineados correctamente entre sí.
  • Page 24 ENSAMBLE PASO POR PASO Fije el Panel Superior al ensamblaje con cuatro Pernos Largos con Arandelas usando una Llave Allen , como se Paso 4 muestra. NOTA: Ajuste uniformemente. No ajuste excesivamente. Perno Largo con Arandelas (1/4” x 1-1/2”) Llave Allen 7/16...
  • Page 25 ENSAMBLE PASO POR PASO Paso 5 Con cuidado, dirija un Estante por el Marco Lateral en el lugar que se muestra. Una vez que el Estante esté completamente insertado, recuéstelo y alinee los ori cios correspondientes en el Estante y los Marcos Laterales NOTA: Para asegurarse de que el estante y el marco no se dañen mientras guía el estante a través del marco lateral, inclínelo como se muestra en la gura.
  • Page 26 ENSAMBLE PASO POR PASO -STEP ASSEMBLY Paso 6 Sujete el Estante al conjunto con cuatro Pernos Largos con Arandelas utilizando una Llave Allen , como en la gura. NOTA: Ajuste uniformemente. No ajuste excesivamente. Perno Largo con Arandelas (1/4” x 1-1/2”) Llave Allen 9/16...
  • Page 27 ENSAMBLE PASO POR PASO Paso 7 Con cuidado, dirija un Estante por el Marco Lateral en el lugar que se muestra. Una vez que el Estante esté completamente insertado, recuéstelo y alinee los ori cios correspondientes en el Estante y los Marcos Laterales NOTA: Para asegurarse de que el estante y el marco no se dañen mientras guía el estante a través del marco lateral, inclínelo como se muestra en la gura.
  • Page 28 ENSAMBLE PASO POR PASO Paso 8 Sujete el Estante al ensamblaje con cuatro Pernos Largos con Arandelas utilizando una Llave Allen , como en la gura. NOTA: Ajuste uniformemente. No ajuste excesivamente. Perno Largo con Arandelas (1/4” x 1-1/2”) Llave Allen 11/16...
  • Page 29 ENSAMBLE PASO POR PASO Paso 9 Con cuidado, dirija un Estante por el Marco Lateral en el lugar que se muestra. Una vez que el Estante esté completamente insertado, recuéstelo y alinee los ori cios correspondientes en el Panel Inferior y los Marcos Laterales .
  • Page 30 ENSAMBLE PASO POR PASO -STEP ASSEMBLY Sujete el Panel Inferior al conjunto con cuatro Pernos Largos con Arandelas usando una Llave Allen como en la Paso 10 gura. NOTA: Ajuste uniformemente. No ajuste excesivamente. Con ayuda, coloque la estantería con la parte inferior hacia arriba como en la muestra.
  • Page 31 ENSAMBLE PASO POR PASO P-BY-STEP ASSEMBLY Paso 11 Una ambas Patas Centrales al conjunto, como se muestra, usando ocho Pernos Cortos con Arandelas . Asegúrese de dejar los pernos sueltos hasta que cada perno se inserte correctamente, luego vuelva y ajústelos uniformemente con una Llave Allen .
  • Page 32 ENSAMBLE PASO POR PASO P-BY-STEP ASSEMBLY Paso 12 Con ayuda, mueva la biblioteca ensamblada a su ubicación deseada. Fije la biblioteca a la pared utilizando el kit Antivuelco incluido. Ubique una viga de pared detrás de la biblioteca. Coloque uno de los soportes en una viga aproximadamente 1"...

  • Page 33: Garantia Limitada De Un Año

    Esta garantía le otorga derechos legales especí cos y usted también puede tener otros derechos que varían de estado a estado. Dimensions Furniture, Inc 341 Gradle Drive, Carmel, IN 46032 1-866-528-8364 / support@dimensionsfurniture.com 16/16...
  • Page 34 Impresso en China...
