INSTALLATION INSTRUCTIONS
79005T-4
79006T-4
BEFORE YOU BEGIN
All information is based on the latest product information available at the time of publication.
Kohler Co. reserves the right to make changes in product characteristics, packaging, or availability at any time
without notice.
Please leave these instructions for the consumer. They contain important information.
NOTES:
1. Flush the water supply pipes thoroughly to remove debris.
2. An inline water filter must be used with this product.
3. Do not remove the rubber protector from the valve body until instructed to.
4. Install valve 78980T-DR according to the rough-in dimensions of 79005T-4, install valve 78981T-DR according
to the rough-in dimensions of 79006T-4.
5. All installations should comply with the relevant requirements of AS/NZS 3500.
ROUGH-IN DIMENSIONS
1293173-AN2-A
Recessed Thin Bath Shower Trim Kit
Recessed Thin Shower Only Trim Kit
Ø160
14
The finished wall
Ø100
14
The finished wall
3.5
32~52
3.5
32~52
PURIST
79005T-4
79006T-4
1
