Hall Technologies HT-TRK1 User Manual

Apollo technology room kit
Hide thumbs Also See for HT-TRK1:

Advertisement

Quick Links

Hall Technologies • 1234 Lakeshore Dr Suite #150 Coppell, TX 75019 • halltechav.com
HT-TRK1
Apollo Technology Room Kit
User Manual
Version: 5.1
Hall Technologies
November 13, 2024
Page 1 of 29

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HT-TRK1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Hall Technologies HT-TRK1

  • Page 1 Hall Technologies • 1234 Lakeshore Dr Suite #150 Coppell, TX 75019 • halltechav.com HT-TRK1 Apollo Technology Room Kit User Manual Version: 5.1 Hall Technologies November 13, 2024 Page 1 of 29...
  • Page 2: Table Of Contents

    Name / Location ..........................19 Audio Mix ............................20 Control Settings ..........................21 Commands ............................ 22 EDID / Scaling ..........................23 Network ............................24 Preferences ........................... 25 Firmware Upgrade ........................26 Specifications ............................27 Hall Technologies November 13, 2024 Page 2 of 29...
  • Page 3: Introduction

    Introduction OVERVIEW The HT-TRK1 Apollo Technology Room Kit is a turn-key solution for classrooms and training rooms. The solution provides HDMI video switching, system control, video extension and analog audio amplification in a convenient and simple 3-piece kit. Utilizing HDBaseT technology, power, control, video up to 4K@60Hz, and audio are transported over a single Cat6 cable between the wall plate transmitter and the receiver.
  • Page 4: Package Contents

    1 x Control Panel • 1 x 2-Gang Plastic Decora Plate, White • 4 x #6-32*20mm Screws, Silver • 4 x #6-32*7mm Screws, White • 1 x Sheet of Pre-printed Button Labels Hall Technologies November 13, 2024 Page 4 of 29...
  • Page 5: Product Views

    Product Views TRANSMITTER CONTROL PANEL RECEIVER Hall Technologies November 13, 2024 Page 5 of 29...
  • Page 6: Connectors & Indicators

    Connect to a USB host, such as a laptop or PC. To Control Panel Connect to the control panel using Cat5e/6/6a/7 cable. HDBT OUT Connect to the receiver using Cat5e/6/6a/7 cable. Hall Technologies November 13, 2024 Page 6 of 29...
  • Page 7: Receiver - Front Panel

    The LED indicators will blink quickly, and the transmitter and receiver will reset to factory defaults. HDBT IN Connect to the transmitter using a Cat5e/6/6a/7 cable. Hall Technologies November 13, 2024 Page 7 of 29...
  • Page 8 AUDIO OUT Connect to an audio amplifier or other audio input device. LEFT-RIGHT Connect each to a separate 4Ω/8Ω loudspeaker. Selector Switch Select the desired speaker output. Connect to the 70V loudspeakers. Hall Technologies November 13, 2024 Page 8 of 29...
  • Page 9: Control Panel

    Note: When power sync function is set to ON the display and system power on functions will be tied together.  Short press the button to power off the display.  Hold press the button for 3 seconds to power off the system. Hall Technologies November 13, 2024 Page 9 of 29...
  • Page 10 When a video source is selected, its corresponding selector button will light up. Video Video 1~4 1~3 is for HDMI IN on the transmitter; HDMI 4 is on the receiver. To Transmitter Connect to the transmitter using Cat5e/6/6a/7 cable. Hall Technologies November 13, 2024 Page 10 of 29...
  • Page 11: Installation

    2. Attach the bracket as shown. 3. Repeat steps 1 and 2 for the other side of the device. 4. Attach the brackets to the desired surface (screws provided by others). Hall Technologies November 13, 2024 Page 11 of 29...
  • Page 12: Application Wiring

    Application Wiring See diagram for connecting devices. USB-B Hall Technologies November 13, 2024 Page 12 of 29...
  • Page 13: Pinout Information

    150mVrms level, there may be audio clipping and distortion. 3. To connect wireless microphones, check if the microphone receiver outputs LINE or MIC level audio signal, and switch accordingly. Hall Technologies November 13, 2024 Page 13 of 29...
  • Page 14: Audio Out

    AUDIO OUT RS232 SPEAKER OUT SPEAKER WIRING CONFIGURATIONS Hall Technologies November 13, 2024 Page 14 of 29...
  • Page 15: Auto Switch

    If that port has no source inserted, the input will be switched to the active source with highest priority. This kit supports OSD (On Screen Display) to display the IP address. Hall Technologies November 13, 2024 Page 15 of 29...
  • Page 16: Control

    Technology Room Kit, the ON and OFF buttons will need to be pressed for three seconds. RS-232 Control Advanced users may want to control the Technology Room Kit through RS-232 serial communication. Please refer to the HT-TRK1_commands.pdf document for instructions and a list of commands. Hall Technologies November 13, 2024 Page 16 of 29...
  • Page 17: Web Ui

    Web UI The Web UI designed for the HT-TRK1 allows for basic controls and device settings. This Web UI can be accessed through a modern browser, e.g., Chrome, Safari, Firefox, IE10+, etc. To get access the Web UI: Connect the LAN port of the switcher to a local area network. Ensure there’s a DHCP server in the network so that the device can obtain a valid IP address.
  • Page 18 Audio Selection: When MIXING function is set to OFF, click to select audio source. Selection Level: Increase/Decrease audio. Settings: Click to enter advanced settings Home: When in advanced settings tab, click home to return to main page. Firmware: Shows installed firmware version. Hall Technologies November 13, 2024 Page 18 of 29...
  • Page 19: Advanced Settings

    Advanced Settings NAME/LOCATION UI Element Description BUILDING Enter the Building Name where the HT-TRK1 is installed. FLOOR Enter the Floor Name/Number where the HT-TRK1 is installed. ROOM NAME/NUMBER Enter the Room Name/Number where the HT-TRK1 is installed. APPLY / CANCEL Click to apply or cancel the changes.
  • Page 20: Audio Mix

    Ducking Level: Use the slider to set the volume ratio of the master audio and other audio inputs in mixed audio. The larger the ratio set, the lower the volume of the other audio inputs with the main master audio input. Hall Technologies November 13, 2024 Page 20 of 29...
  • Page 21: Control Settings

    COMMAND ENDING: Select between NONE, \r, \n, or \r\n to append to an ASCII command. AUDIO MUTE Select between all audio muted and muted during paging. VIDEO SWITCHING Select between Auto or Manual video switching. Hall Technologies November 13, 2024 Page 21 of 29...
  • Page 22: Commands

    LIGHTS A / B To have ON and SOURCE illuminated at the same time, set one as A and one as B. EXPORT/IMPORT Export the list of commands saved and import into another unit. Hall Technologies November 13, 2024 Page 22 of 29...
  • Page 23: Edid / Scaling

    Click the drop-down menu to select a compatible resolution for the connected display. By OUTPUT RESOLUTION default the Output Resolution is set to “auto”. CANCEL / APPLY Save or cancel the setting changes. Hall Technologies November 13, 2024 Page 23 of 29...
  • Page 24: Network

    Default setting is DHCP. STATIC When the kit fails to obtain an IP address from the network, select Static as the mode. CANCEL / APPLY Save or cancel the setting changes. Hall Technologies November 13, 2024 Page 24 of 29...
  • Page 25: Preferences

    Save or cancel the setting changes. Click “Upload” to select a PNG image from a local PC to upload. This image must be in PNG CUSTOM WEB UI LOGO format with a resolution of 292x80 pixels. Hall Technologies November 13, 2024 Page 25 of 29...
  • Page 26: Firmware Upgrade

    Click browse for the MCU upgrade in .zip format. A status bar will indicate how much of MCU UPGRADE the firmware has been loaded. NOTE: all devices need to be connected during firmware upgrade. Hall Technologies November 13, 2024 Page 26 of 29...
  • Page 27: Specifications

     Audio In & Mic/Line In: Stereo Audio Format  Audio Out & 4Ω/8Ω Speaker Out: Stereo  70V Speaker Out: Mono Transmitter: Maximum Data Rate HDMI In, HDBT Out: 10.2Gbps Hall Technologies November 13, 2024 Page 27 of 29...
  • Page 28 Receiver: 215mm x 42mm x 160.2mm | 8.46” x 1.65” x 6.31” Control Panel: 45mm x 105.6mm x 28.7mm | 1.77” x 4.16” x 1.13” Transmitter: 0.3kg | 0.66lb Weight Receiver: 1.43kg | 3.15lb Control Panel: 0.16kg | 0.35lb Hall Technologies November 13, 2024 Page 28 of 29...
  • Page 29 © Copyright 2022. Hall Technologies All rights reserved. 1234 Lakeshore Drive, Suite #150, Coppell, TX 75019 halltechav.com / support@halltechav.com (714)641-6607 Hall Technologies November 13, 2024 Page 29 of 29...
