Hall Technologies • 1234 Lakeshore Dr Suite #150 Coppell, TX 75019 • halltechav.com
HT-TRK1
18-Channel VGA Video Splitter / Distribution Amplifier
User Manual
Version: UMA1113 Rev. B
Universal Sync Input
(Separate, Composite, or Sync-on-green)
Programmable Sync Output Mode for Each Output
0
5
Hall Technologies
2007
Page
of
Advertisement
Related Manuals for Hall Technologies HT-TRK1
Summary of Contents for Hall Technologies HT-TRK1
- Page 1 Hall Technologies • 1234 Lakeshore Dr Suite #150 Coppell, TX 75019 • halltechav.com HT-TRK1 18-Channel VGA Video Splitter / Distribution Amplifier User Manual Version: UMA1113 Rev. B Universal Sync Input (Separate, Composite, or Sync-on-green) Programmable Sync Output Mode for Each Output...
- Page 2 Powered from supplied AC adapter or customer supplied 5 vDC • Each output can independently generate composite sync • LED power indicator • BNC connectors on input and outputs • Mounting holes for attachment in user equipment Hall Technologies 2010 Page...
- Page 3 Pin 4 = +5v DC (regulated) Specifications Analog inputs: 3 BNC type labeled RED, GREEN, and BLUE Input impedance: 75 ohm, voltage level: 3 vp-p max, 1 vp-p nominal Sync inputs: 2 BNC type labeled HOR, VERT Hall Technologies 2010 Page...
- Page 4 Any defective part should be returned, insured and freight prepaid, to Hall Research, with the following: Return Material Authorization Number (RMA#) Description of failure, as detailed as possible Shipping address and contact name and phone number Hall Technologies 2010 Page...
- Page 5 © Copyright 2010. Hall Technologies, Inc. All rights reserved. 1234 Lakeshore Drive, Coppell, TX 75019 Phone: (714) 641-6607 • Fax: (714) 641-6698 Hall Technologies 2010 Page...
