The following table outlines the steps for removing and replacing the WWAN card on the Latitude™ D620.

Removing and Replacing the WWAN Card

1. Before removing the WWAN card:
Remove the AC power.
Remove the battery.
Remove the hinge cover.
Remove the keyboard.
Remove the memory DIMM
2. Locate the WWAN card.
3.
Disconnect the two cables from the WWAN card.
