Thank you for purchashing your DJ-X100T/E.Please read this manual carefully before using
the product to ensure full performance, and keep this manual for future reference as it contains
information on after-sales service.
In case addendum or errata sheets are included with this product,please read those materials
and keep them together with this instruction manual for future reference.
ALINCO, INC.
DJ-X100T/E
Instruction Manual
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
CAUTION: Changes or Modifications to this device, not expressly approved by
Alinco,Inc.,could void your authority to operate this device under FCC regulations.
MODIFICATION OF THIS DEVICE TO RECEIVE CELLULAR
RADIOTELEPHONE SERVICE SIGNALS IS PROHIBITED UNDER FCC RULES
AND FEDERAL LAW.
It's illegal to intentionally intercept or attempt to intercept electronic communication
and to use or disclose information obtained through receiving electronic
communications, moreover, possession and use of communications receivers is
prohibited in many countries.
Please check your local Radio Law and Privacy act about use of receivers in
advance to purchase this product.
DIGITAL MULTI-MODE RECEIVER
