Item
1
EMEA/KR/China label
3
Country label
5
Microsoft label
7
COA label
9
USA RTC Battery warning label
11
India label
13
TW label
M.2 solid-state drive and its bracket (for selected models)
Before you start, read
Generic Safety and Compliance Notices
Attention: The M.2 solid-state drive is sensitive. Inappropriate handling might cause damage and
permanent loss of data.
When handling the M.2 solid-state drive, observe the following guidelines:
• Replace the M.2 solid-state drive only for repair. The M.2 solid-state drive is not designed for frequent
changes or replacement.
• Before replacing the M.2 solid-state drive, make a backup copy of all the data that you want to keep.
• Do not apply pressure to the M.2 solid-state drive.
• Do not touch the contact edge or circuit board of the M.2 solid-state drive. Otherwise, the M.2 solid-state
drive might get damaged.
• Do not subject the M.2 solid-state drive to physical shocks or vibration. Put the M.2 solid-state drive on a
soft material, such as cloth, to absorb physical shocks.
1. Disable the built-in battery. See "Disabling the built-in battery" on page 67.
2. Turn off the computer and disconnect the computer from ac power and all connected cables.
3. Close the computer display and turn over the computer.
4. Remove the base cover assembly. See "Base cover assembly of ThinkPad P14s Gen 5" on page 68 or
see "Base cover assembly of ThinkPad P16s Gen 3" on page 70.
72
ThinkPad P14s Gen 5 and ThinkPad P16s Gen 3 Hardware Maintenance Manual
Item
2
China CECP label
4
Service QR code
6
S/N label
8
SVT label
10
Asset tag label
12
IMEI label
and print the following instructions.
