Tikom L8000 PRO Manual

Getting Started

Notes:
Please search "Tikom Technology" in YouTube to find installation videos.

Notes:

• Always keep the charging station plugged in to ensure the robot can automatically return to recharge when the battery level is low.
• Clear objects within 1.6 ft/0.5m of the left and right sides, and within 4.9 ft/1.5 m in front of the Charging Station.
• Recommend to use adhesive tapes to fix Charging Station on the ground.

Notes:
Please ensure your robot is fully charged before its first use. Attach Robot to the Charging Station by aligning its Charging Contacts with the Charging Contacts on the Charging Station. Once the robot is successfully connected to the charging station, the voice prompt, "Start charging".

Product Overview

APP Connection

1. Ensure that Bluetooth on your smartphone or tablet is turned ON.
2. Ensure that the robot and your mobile device are in close proximity to the router during the connection process.
3. Ensure that your smartphone or tablet is connected to a 2.4GHz Wi-Fi network.
4. If your router is a dual-band 2.4GHz/5GHz router, select the 2.4GHz network.
5. If both bands use the same Wi-Fi name in your router, rename the 2.4GHz network on the router's control page and connect your mobile phone to this newly named 2.4GHz network.

1. Search for Tuya Smart on the App Store/Google Play, or scan the QR code below to download and install it on your mobile device.

2. Register and log in on the app.

3. Press and hold and buttons on the robot at the same time for 3 seconds, Robot will say "Wi-Fi reset, ready for Wi-Fi connection", and Wi-Fi Status Light will Fast Flash.

4. Open Tuya Smart App, Tap "Add Device" or "+" at the upper right corner.

5. Robot is discovered, then tap "Add" button.

6. Select the same router's 2.4GHz Wi-Fi as mobile phone and enter the correct password. Tap "Next".

7. Connecting to Wi-Fi. Robot will say "Connecting to Wi-Fi".

8. Connection successful, and Robot will say "Wi-Fi Connection Successful", and Wi-Fi Status light will be solid.


Notes: If fail to connect Wi-Fi in Quick Mode as above, please try Wi-Fi connecting in AP Mode, details please check "Connect Wi-Fi with AP Mode"
Installation Video

Start with Tuya Smart APP

Mapping Whole House Layout

1. Place the robot docked on the charging station.
2. Press on the robot or press on App to let the robot start mapping.

Notes:

1. Please remove any objects from the floor that may entangle the robot vacuum, such as pet waste, socks, clothing, tissues, toys, slippery items, and power cords. You can utilize the provided Cable Ties to organize your wires and power cords.

2. During the initial cleaning, ensure that each room's door is open to assist the robot in fully exploring your house.

3. Since the robot can cross thresholds up to 0.7 in/18 mm high, if any room's outer threshold is less than 0.7 in/18 mm, but the threshold measured from the inside of the room is higher than 0.7 in/18 mm due to height differences, the robot may enter but not exit the room, potentially becoming trapped. In such cases, set up a "No-Go Zone" or "Virtual Wall" for this room to prevent the robot from being trapped in this room.


Set Restricted Zone

No matter when robot is cleaning or mapping, you could stop robot and set "No-Go Zone", "No-Mop Zone" or "Virtual Wall" in Tuya smart APP "Restricted Zone Setting" as you want, then let the robot continue cleaning.
No-Go Zone (Max 7): To prevent Robot enter this zone in any time. For some place where robot couldn't clean, or don't want robot enter in, or somewhere robot is easily stuck or trapped. Examples are as below.

1. Children's playroom: where have too many toys on the ground, robot easily gets stuck in this place.

2. Bathroom: Where there is too much water on the ground, and robot would be damaged by water.

3. Certain Room: There are high steps in some places, and the robot can't get out once it goes in. Robot is trapped.

4. Some furniture: Where robot would easily get stuck because its height exceeds the bottom height of certain furniture.


No-Mop Zone (Max 7): Special for Carpet areas. When Robot installs Mopping cloth holder, Robot can't enter this zone to mop.
Virtual Wall (Max 20): Robot can't go cross virtual Wall.

Edit room layout on APP

Enter "Map Edit" in APP to merge, split rooms and rename each room to make sure the whole map is same as your house layout.

Enter "Map Management" to save current map

When the current map is lost or corrupted for some reason, you can use a saved map from the list of Map Management."
