Panasonic SC-BTT1270 Easy Setting Manual

Panasonic
Easy Setti ng
G u ide
Blu-ray Disc™ Home Theater Sound System
The order of setting Model No. SC-BT 1270
Prepare the speakers Place the speakers Connect Turn on the Easy setup
See below See below the cables main unit See Easy setup
See over See over screen
1 Prepare the speakers ? Place the speakers
STEP 1
Label each speaker cable by attaching the
numbered sticker at ihe position indicated in
the illustration. Be sure to match the number
on each sticker with the circled number in the
illustration.
Refer to the rear label of the speaker before connecting the corresponding
cable.
Verify the type of speaker with the label on the rear of the speaker.
Speakers @
Front speakers FRONT/AVANT
Center speaker CENTER/CENTRE
Surround speakers SURROUND/AMBIOPHONIE
e.g., Front speaker Lch
Subwoofer Center speaker _ Front speakers Surround speakers
Reh Loh Reh Leh
PURPLE
RED WHITE GRAY BLUE
Connect the speaker cables.
Insert the wire fully, taking care nol fo insert
beyond the wire insulation.
1) White
r~ Recommended - \
>. Blue line
Front speakers Surround speakers
(L, R) (LS, RS)
ap aT
\. A
VQC8047-1
F1210MH1720
