- Page 1 INSTALLATION AND OPERATING INSTRUCTIONS for 48" - 112" Hydrocarbon CBR Refrigerator Models 809-257A REV. 09/04/2024 SEE BACK COVER FOR 3779 CHAMPION BLVD, WINSTON-SALEM, NC 27105 WARRANTY REGISTRATION Phone: (888) 845-9800 | Fax: (800) 253-5168 | Web: Victoryrefrigeration.com...
-
Page 2: Table Of Contents
If you the high standards set by Victory! You have made a have any questions, Please call our Technical Service quality investment that with proper maintenance will give Department at (800) 684-1199. -
Page 3: Safety
R290 equipment. • Clean a dirty condenser with a sharp object. • Use ONLY Victory factory service parts. Use of non • Store gasoline, kerosene or any other flammable OEM parts can be dangerous because of the design material near the cabinet. -
Page 4: Important Information
User Manual for CBR 48" - 112" Refrigerators Victory IMPORTANT INFORMATION This unit is intended to be used in a commercial application. That includes bars and restaurants. If installed in a residence some commercial service companies may not be able to service it on site. -
Page 5: Product Information
User Manual for CBR 48" - 112" Refrigerators Victory PRODUCT INFORMATION Refrigerant Type / Cabinet Dimensions Section Drawer Full Load Power Cord Model Charge (g) / Charge w x d x h (Inches) Count Count Amps Plug (NEMA) (oz) CBR48HC... -
Page 6: Clearance And Placement
User Manual for CBR 48" - 112" Refrigerators Victory CLEARANCE AND PLACEMENT 3 3/4" BOTTOM MINIMUM CLEARANCE Placement Consider the following when selecting a location for your Refrigerator: Clearance: 0" - Top 0" - Left 0" - Right 1" - Rear 3-3/4"... -
Page 7: Unpacking And Set Up
User Manual for CBR 48" - 112" Refrigerators Victory UNPACKING AND SET UP Carefully inspect the shipping carton for damage. This is the only time that shipping damage may be claimed. If damage is suspected, open the carton immediately and, if there is damage, retain the carton and contact the shipper to make a claim. -
Page 8: Electrical
User Manual for CBR 48" - 112" Refrigerators Victory ELECTRICAL This is a cord-connected unit, and must be connected to its own dedicated power supply. Check the dataplate on the machine to confirm the voltage and per the dataplate use the correct fuses or HACR circuit breakers. -
Page 9: Using The Unit - Danfoss Controller
User Manual for CBR 48" - 112" Refrigerators Victory USING THE UNIT - DANFOSS CONTROLLER Operation is simple, just keep it connected to the correct The temperature was set at the factory at 38 F, but you º power supply and the refrigerator will maintain the can adjust it to your own selected temperature. -
Page 10: Sequence Of Operations Refrigerator
User Manual for CBR 48" - 112" Refrigerators Victory 2 34 5 6 6 2 5 5 54 8 6 6 ... - Page 11 User Manual for CBR 48" - 112" Refrigerators Victory User Manual for UCR Refrigerators Beverage-Air DANFOSS CONTROLLER DEFROST (ESC) Electronic Controller SELECT (OK) DOWN Control Panel Display Note: Defrost is manual, LED indicator is inoperative. Defrost LED Alarm LED On fixed:...
- Page 12 01 2 3 ÿ 56 7 8 6 9 ÿ 3 ÿ ÿ 9 ÿ 5 9 ÿ 9 2 3 ÿ 2 2 3 6 2 3 User Manual for CBR 48" - 112" Refrigerators Victory ! " ! # $ % ! & '( # ÿ Victory Rev.
- Page 13 User Manual for CBR 48" - 112" Refrigerators Victory () * + , ÿ . / ÿ 0 1 0 2 3ÿ 4 5 6 1 7 8 9 : ; ÿ < 9 34 8 ÿ 0 2 4 ÿ 9 ; ÿ = 2 : > 2 4 8 8 ÿ ? @A @ÿ / : 1 C 4 2 ÿ : / ÿ < D 4 ÿ = 0 2 0 34 < 4 2 ÿ < 0 E 1 4 F G ÿ < D 4 ÿ 0 1 0 2 3ÿ 9 8 ÿ ; : < ÿ 8 9 > ; 0 1 4 C H ÿ...
-
Page 14: Using The Unit - Eliwell Controller
User Manual for CBR 48" - 112" Refrigerators Victory 01 2 3 ÿ 56 7 8 6 9 ÿ 3 ÿ ÿ 9 ÿ 5 9 ÿ 9 2 3 ÿ 2 2 3 6 2 3 USING THE UNIT - ELIWELL CONTROLLER +,- ./ÿ... -
Page 15: Sequence Of Operations Refrigerator
Refrigerator with Eliwell Controller Beverage-Air Beverage-Air User Manual for CBR 48" - 112" Refrigerators Victory SEQUENCE OF OPERATIONS REFRIGERATOR SEQUENCE OF OPERATIONS REFRIGERATOR The refrigerator operates based on the air temperature measured by the probe located at the return air. - Page 16 01 2 3 ÿ 56 7 86 9 ÿ 3 ÿ ÿ 9 ÿ 5 9 ÿ 9 2 3 ÿ 2 2 3 6 2 3 User Manual for CBR 48" - 112" Refrigerators Victory ! " ! # $ % ! & '( # ÿ Victory Rev.
- Page 17 01 2 3 ÿ 56 7 86 9 ÿ 3 ÿ ÿ 9 ÿ 5 9 ÿ 9 2 3 ÿ 2 2 3 6 2 3 User Manual for CBR 48" - 112" Refrigerators Victory ÿ ! " ! # $ % ! & '( # Rev.
-
Page 18: Cleaning And Maintenance
User Manual for CBR 48" - 112" Refrigerators Victory CLEANING AND MAINTENANCE Cleaning Schedule: Cabinet Condenser coil Gaskets Daily wipe down Quarterly cleaning Periodic Routine maintenance Weekly interior Annually Daily Exterior Cleaning It is much easier to clean on a regular basis than to have to remove stains once they have built up. -
Page 19: Drawer Cleaning And Maintenance
User Manual for CBR 48" - 112" Refrigerators Victory DRAWER CLEANING AND MAINTENANCE Drawer models are shipped with the drawers already installed in the cabinets. Drawers are designed with slides which have locking mechanisms to prevent drawers from coming off cabinets during normal opening and closing operations. -
Page 20: Condenser Cleaning
User Manual for CBR 48" - 112" Refrigerators Victory CONDENSER CLEANING Keeping the condenser coil clean is critical to efficient 1. Unplug unit from power supply. operation. 2. Remove the bottom screw from the front grille panel. The condenser coil is located behind the front or rear 3. -
Page 21: Methods For Cleaning Stainless Steel
User Manual for CBR 48" - 112" Refrigerators Victory METHODS FOR CLEANING STAINLESS STEEL Cleaning Needed Cleaning Agent Method of Application Affect on Finish Satisfactory for use on all Areal 20, Lac-O-Nu, Lumin Wash Rub with cloth as directed finishes. -
Page 22: Help
User Manual for CBR 48" - 112" Refrigerators Victory HELP Trouble Diagnosis for the User Malfunction Possible Cause Likely Solution Connect to proper voltage circuit Replace Unit not plugged in. fuse or reset breaker. No cooling - unit is silent Fuse or circuit breaker tripped. -
Page 23: For The Service Tech - R290
User Manual for CBR 48" - 112" Refrigerators Victory FOR THE SERVICE TECH - R290 Refrigeration service should only be attempted by a trained trade professional certified to work on R290 systems. Here are some critical service items. Other Information: This list does not qualify anyone to service the unit. -
Page 24: For The Service Tech - Wiring Diagram
User Manual for CBR 48" - 112" Refrigerators Victory FOR THE SERVICE TECH - WIRING DIAGRAM CNTRL *SEE CONTROLLER DETAIL CONDENSER FAN CURRENT RELAY COMP *SEE CONTROLLER DETAIL COMPRESSOR DETAIL (115V 1PH) EVAP FANS POWER *SEE CONTROLLER DETAIL SUPPLY *NOT ALL MODELS* LAMP L.E.D. -
Page 25: Limited Warranty
Victory LIMITED WARRANTY Warranty (Continental USA & Canada Only) Proof of purchase must be supplied to Victory to validate the warranty. This warranty is valid only SEVEN (7) YEAR PARTS, LABOR, AND COMPRESSOR if equipment is properly installed, and started-up as LIMITED WARRANTY outlined in the Owner’s Manual. -
Page 26: Limited Warranty (Continued)
Special installation/applications, including remote LIMITATION OF LIABILITY: locations, are limited in coverage by this warranty. Victory or its affiliates shall not be liable for any Any installation that requires extra work, and/ indirect, incidental, special or consequential or travel, to gain access to the unit for service is damages, or losses of a commercial nature arising the sole responsibility of the equipment purchaser. -
Page 27: Warranty Registration
User Manual for CBR 48" - 112" Refrigerators Victory Warranty Registration Register your product online at Victory.com/parts-service or fill out and mail the form below. Cabinet Model Number: _____________________________________________ Date Of Installation: _________________ Cabinet Serial Number: _____________________________________________ Location Of Product...
