- Page 1 INSTALLATION AND OPERATING INSTRUCTIONS for all Hydrocarbon ACRS Air Curtain Refrigerator Models 809-197A 02/05/2021 SEE BACK COVER FOR 3779 CHAMPION BLVD, WINSTON-SALEM, NC 27105 WARRANTY REGISTRATION Phone: (888) 845-9800 | Fax: (800) 253-5168 | Web: victoryrefrigeration.com...
-
Page 2: Table Of Contents
From the earliest stages of production design, to focused steps in fabrication and assembly, rigid standards of We thank you for your choice and confidence in Victory quality are maintained by our staff of skilled employees. Equipment. -
Page 3: Safety
R290 equipment. • Clean a dirty condenser with a sharp object. • Use ONLY Victory factory service parts. Use of non • Store gasoline, kerosene or any other flammable OEM parts can be dangerous because of the design material near the cabinet. -
Page 4: Safety
User Manual for ACRS Air Curtain Refrigerators Victory SAFETY Even though the cabinet weighs 320 pounds, it is easy to maneuver when in use. This is accomplished by the use of recessed side hand grips, a push bar handle (except on pass-thru models) with rubber bumpers and heavy duty non- marking casters. -
Page 5: Important Information
User Manual for ACRS Air Curtain Refrigerators Victory IMPORTANT INFORMATION This unit is intended to be used in a commercial application. That includes bars and restaurants. If installed in a residence some commercial service companies may not be able to service it on site. -
Page 6: Product Information
Sections Charge (g) / Charge w x d x h (Inches) Full Door Solid Door Amps (oz) ACRS-1D-S1-HC 29 x 37 5/8 x 78 7/8 Solid ACRS-1D-S1-PT-HC 30 1/2 x 38 x 78 7/8 Solid ACRS-1D-S1-PT-G-HC 30 1/2 x 35 1/4 x 78 7/8... -
Page 7: Clearance And Placement
User Manual for ACRS Air Curtain Refrigerators Victory CLEARANCE AND PLACEMENT 14" ABOVE UNIT 0" SIDE TO BUMPER 0" BUMPER TO SIDE " FLOOR TO CABINET BOTTOM Placement Consider the following when selecting a location for your Refrigerator: Clearance: •... -
Page 8: Unpacking And Set Up
User Manual for ACRS Air Curtain Refrigerators Victory UNPACKING AND SET UP Carefully inspect the shipping carton for damage. This is the only time that shipping damage may be claimed. If damage is suspected, open the carton immediately and, if there is damage, retain the carton and contact the shipper to make a claim. -
Page 9: Pan Slide Installation
User Manual for ACRS Air Curtain Refrigerators Victory PAN SLIDE INSTALLATION Insert the back tab of the pan/tray slide into the square cut out and press down to lock in place. Align the front tab with the square cut out and press down, locking it as shown. -
Page 10: Electrical
User Manual for ACRS Air Curtain Refrigerators Victory ELECTRICAL This is a cord-connected unit, and must be connected to its own dedicated power supply. Check the dataplate on the machine to confirm the voltage and per the dataplate use the correct fuses or HACR circuit breakers. -
Page 11: Sliding Door Pass-Thru Model
User Manual for ACRS Air Curtain Refrigerators Victory SLIDING DOOR PASS-THRU MODEL Certain models feature a door that, when opened, may be secured to the side of the cabinet, keeping it out of the way when loading or unloading product. -
Page 12: Using The Unit
User Manual for ACRS Air Curtain Refrigerators Victory USING THE UNIT Operation is simple, just keep it connected to the correct power supply and the refrigerator will maintain the The Refrigerator will automatically defrost as needed, internal temperature it has been set to. Keep the doors there is no set time for defrost. -
Page 13: Adding Product
User Manual for ACRS Air Curtain Refrigerators Victory ADDING PRODUCT Temperature graph below shows the product temperature increase over a 90 minute period with a starting product temperature of 35 degrees Use these guidelines for the best use of your ACRS unit 1. -
Page 14: Sequence Of Operations
User Manual for ACRS Air Curtain Refrigerators Victory SEQUENCE OF OPERATIONS COMPONENT OPERATION CONTROLLER ACTION OPERATION CONTROLLER ACTION COMPRESSOR Compressor turns The Compressor Compressor turns The Compressor on when the cabinet Contact is energized off when the cabinet Contact is de-... -
Page 15: Control Panel Display
User Manual for ACRS Air Curtain Refrigerators Victory CONTROL PANEL DISPLAY Control Panel Indicators Icon Operation Meaning Compressor Permanently On Compressor On Blinking Delay, protection or start-up blocked Otherwise Defrost Permanently On Defrost active Blinking Activated manually or from Digital input... - Page 16 User Manual for ACRS Air Curtain Refrigerators Victory Relay/Probe Description Terminal Compressor 10,11 Out 1 Evaporator Fan 4, 5 Out 2 Defrost Element 7, 9 Out 3 Light (or alarm relay if electronic Lock model) 13, 14 Out 4 Air/control probe 18, 19 PB1 –...
-
Page 17: Electronic Controller Parameter Changes
User Manual for ACRS Air Curtain Refrigerators Victory ELECTRONIC CONTROLLER PARAMETER CHANGES Note: Key pad has a 3 second lock feature. Set key must be pressed for 3 seconds and released before keys will become active. Key pad will beep when unlocked and normal key pad operations performed. -
Page 18: Setting The Real Time Clock
User Manual for ACRS Air Curtain Refrigerators Victory SETTING THE REAL TIME CLOCK To set the real time clock, press and release the set button to enter the machine status menu. “Set will appear on the menu. Use the up and down button to scroll to the real time clock menu folder. “Rtc” will appear on the display. - Page 19 User Manual for ACRS Air Curtain Refrigerators Victory Rev. 02/21 Victory...
- Page 20 User Manual for ACRS Air Curtain Refrigerators Victory Code Description Description Relay Reset Parameters involved to Enable alarm Probe Pb1 failure Active Automatic Ont, Oft Probe Pb2 failure Active Automatic Ont, Oft Probe Pb3 failure Active Automatic Ont, Oft Probe Pb4 failure...
-
Page 21: Cleaning And Maintenance
User Manual for ACRS Air Curtain Refrigerators Victory CLEANING AND MAINTENANCE Cleaning Schedule: Cabinet Condenser coil Gaskets Routine maintenance Daily wipe down Quarterly cleaning Daily inspection, check Annually that hinges are tight to Weekly interior the cabinet. Every two years. -
Page 22: Condenser Cleaning
User Manual for ACRS Air Curtain Refrigerators Victory CONDENSER CLEANING Keeping the condenser coil clean is critical to efficient 3. Examine condenser surface, if dusty, brush and operation. vacuum the dust and lint from the surface of the coil. Brush up and down to avoid damaging the fins. -
Page 23: Methods For Cleaning Stainless Steel
User Manual for ACRS Air Curtain Refrigerators Victory METHODS FOR CLEANING STAINLESS STEEL Cleaning Needed Cleaning Agent Method of Application Affect on Finish Satisfactory for use on all Areal 20, Lac-O-Nu, Lumin Wash Rub with cloth as directed finishes. Smears and fingerprints O’Cedar Cream Polish, Stainless... -
Page 24: Help
User Manual for ACRS Air Curtain Refrigerators Victory HELP Trouble Diagnosis for the User Malfunction Possible Cause Likely Solution Connect to proper voltage circuit Replace Unit not plugged in. fuse or reset breaker. No cooling - unit is silent Fuse or circuit breaker tripped. -
Page 25: For The Service Tech - R290
User Manual for ACRS Air Curtain Refrigerators Victory FOR THE SERVICE TECH - R290 Refrigeration service should only be attempted by a trained trade professional certified to work on R290 systems. Here are some critical service items. Other Information: This list does not qualify anyone to service the unit. It is a Evacuation: It is critical that a refrigeration system be reminder and checklist for the service tech. -
Page 26: For The Service Tech - Wiring Diagram
User Manual for ACRS Air Curtain Refrigerators Victory FOR THE SERVICE TECH - WIRING DIAGRAM VARIABLE SPEED COMPRESSOR DETAIL INVERTER (VFD) HIGH PRESSURE LIMIT SWITCH (NOT ALL MODELS) COMP CONDENSER FAN Victory Rev. 02/21... -
Page 27: Limited Warranty
Victory branded equipment, that such equipment is free from defects in material and Proof of purchase must be supplied to Victory to validate workmanship, under normal use, proper maintenance and the warranty. This warranty is valid only if equipment is service as indicated by Victory’s installation and operation... -
Page 28: Limited Warranty (Continued)
LIMITATION OF LIABILITY: are limited in coverage by this warranty. Any installation Victory or its affiliates shall not be liable for any indirect, that requires extra work, and/or travel, to gain access to the incidental, special or consequential damages, or losses of a... - Page 29 User Manual for ACRS Air Curtain Refrigerators Victory Warranty Registration Register your product online at Victory.com/parts-service or fill out and mail the form below. Cabinet Model Number: _____________________________________________ Date Of Installation: _________________ Cabinet Serial Number: _____________________________________________ Location Of Product Business Name: ____________________________________________________...
