Chapter 2. nShield Network-Attached HSMs
Weight
11.5kg
Dimensions
43.4mm x 430mm x 690mm

The module is compatible with 1U 19" rack systems.
Measurements given are height x width x length/depth. If the inner slide rails are attached,
the width of the unpackaged module is 448mm.

2.1.3. Handling the HSM

nShield HSMs contain solid-state devices that can withstand normal handling. However, do
not drop the module or expose it to excessive vibration.
If you are installing the module in a 19" rack, make sure that you follow the nShield Connect
or 5c Slide Rails Instructions provided with the rails. In particular, be careful of sharp edges.
Only experienced personnel should handle or install an nShield HSM. Always consult your
company health and safety policy before attempting to lift and carry the module. Two
competent persons are required if it is necessary to lift the module to a level above head
height (for example, during installation in a rack or when placing the module on a high shelf).

2.1.4. Environmental requirements

To ensure good air flow through and around the module after installation, do not obstruct
either the fans and vents at the rear or the vent at the front. Ensure that there is an air gap
around the module, and that the rack itself is located in a position with good air flow.
2.1.4.1. Temperature and humidity recommendations
Entrust recommends that your module operates within the following environmental
conditions.
Environmental conditions
Operating temperature
Storage temperature
Operating humidity
nShield v13.6.5 Hardware Install and Setup
Guides
Operating range (Min. | Max.)
5 °C 35 °C
-20 °C 70 °C
10 % 85 %
Comments
-
-
Relative. Non-condensing at 35 °C.
