Chapter 3. nShield PCIe HSMs

3.1.2. Handling the HSM

nShield HSMs contain solid-state devices that can withstand normal handling. However, do
not drop the module or expose it to excessive vibration.
Before installing hardware, you must disconnect your computer from
the power supply. Ensure that a grounded (earthed) contact remains.

Perform the installation with care, and follow all safety instructions in
this guide and from your computer manufacturer.
Static discharge can damage modules. Do not touch the module

connector pins, or the exposed area of the module.
Leave the module in its anti-static bag until you are ready to install it. Always wear an anti-
static wrist strap that is connected to a grounded metal object. You must also ensure that
the computer frame is grounded while you are installing or removing an internal module.

3.1.3. Environmental requirements

The nShield HSMs operate within the following environmental conditions.
3.1.3.1. Temperature and humidity specifications
nShield 5s
nShield 5s environmental
conditions
Operating temperature*
Storage temperature
Transportation temperature -40°C (-40°F)
Operating humidity
Storage humidity
Transportation humidity
Altitude
nShield v13.6.5 Hardware Install and Setup
Guides
Operating range
Min.
5°C (41°F) 55°C (131°F)
-5°C (-23°F) 60°C (140°F)
70°C (158°F)
5% 85%
5% 93%
5% 93%
-100m (-328ft) 2000m (6561ft)
Comments
Max.
Subject to sufficient airflow
-
-
Relative. Non-condensing at
30°C (86°F)
Relative. Non-condensing at
30°C (86°F)
Relative. Non-condensing at
30°C (86°F)
Above Mean Sea Level
