INSTALLATION MANUAL
DIGITAL FULL COLOR
MULTIFUNCTIONAL SYSTEM
CONTENTS
[21] MX-PN13A/B/C/D (PUNCH MODULE) . . . . 21-1
[22] MX-TM10 (TRIMMING MODULE) . . . . . . . . 22-1
[23] MX-KB16 (KEYBOARD) . . . . . . . . . . . . . . . 23-1
[24] MX-PX12 (INTERFACE KIT) . . . . . . . . . . . . 24-1
[25] MX-PX13 (INTERFACE KIT) . . . . . . . . . . . . 25-1
[26] MX-SL10N (STATUS INDICATOR) . . . . . . . 26-1
[27] MX-PF10 (BARCODE FONT KIT) . . . . . . . . 27-1
[28] AR-SU1 (STAMP UNIT). . . . . . . . . . . . . . . . 28-1
[29] MX-FR58U (DATA SECURITY KIT). . . . . . . 29-1
[30] IC card reader . . . . . . . . . . . . . . . . . . . . . . . 30-1
[31] MX-AMX1
(APPLICATION INTEGRATION MODULE) . . 31-1
[32] MX-AMX2 (APPLICATION COMMUNICATION
MODULE) . . . . . . . . . . . . . . . . . . . . . . . . . . . 32-1
[33] MX-AMX3
(EXTERNAL ACCOUNT MODULE) . . . . . . . 33-1
[34] Remote operation panel function Enable
setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34-1
[35] Setting, Adjustments, Operation check . . . . 35-1
[36] Setup and adjustment data recording . . . . . 36-1
[37] Necessary works before moving the
machine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37-1
SHARP CORPORATION
CODE: 00ZMX8090/I3E
MX-7090N
MX-8090N
MODEL
This document has been published to be used
for after sales service only.
The contents are subject to change without notice.
