- Page 1 K31 Hardware Instructions V1.3.2 Kingsine Electric Automation Co.,Ltd. © 1999-2021...
- Page 2 Thank you for your using Kingsine brand protection relay testing system. Hope that the technical data and help information in the manual will be provided to you as detailed as possible about how to use Kingsine products. Meanwhile, we shall be much appreciated to receiving any views about this manual from all the readers and all the experts in the line of relay testing.
- Page 3 K31 Hardware Instructions Kingsine Electric Automation Co.,Ltd. © 1999-2021 All rights reserved. No parts of this work may be reproduced in any form or by any means - graphic, electronic, or mechanical, including photocopying, recording, taping, or information storage and retrieval systems - without the written permission of the publisher.
-
Page 4: Table Of Contents
IEC61850 SMV & GOOSE 3.4 Accessories ........................... 21 ................................21 3.4.1 Standard Accessories ................................23 3.4.2 Optional Accessories Fast Binary output & E nergy pulse adapter ..............................25 Low -Level output adapter ..............................27 Part 4 FAQ Kingsine Electric Automation Co.,Ltd. © 1999-2021... -
Page 5: Part 1 Safety Operation
Safety Operation Safety Operation Only operate (or even turn on) the K31 set after you have read this reference manual and fully understood the instructions herein. The K31 set may only be operated by trained personnel. Any maloperation can result in damage to property or persons. -
Page 6: Part 2 Overview
Analog and Binary Transient Record Transient play back up to 3KHz Lightweight, <18Kg Fully function KRT software testing modules Able to test Able of what K31 series can test Items ANSI IEC61850 numerical IEDs relay & merge unit Distance protection relay... - Page 7 Overview Directional voltage relays Voltage and power directional relays Tripping relays Voltage regulating relays Over-impedance relays, Z> Under-impedance relays, Z Time-delay relays Kingsine Electric Automation Co.,Ltd. © 1999-2021...
-
Page 8: Part 3 Hardware Instruction
Run time alarm or error while it turned on Run: It will blinking while kit is running Ethernet port 10/100M Base-Tx RJ45 Ethernet, for PC control connection IRIG-B IRIG-B input, ST type, wavelength 850nm IRIG-B output, ST type, wavelength 850nm Kingsine Electric Automation Co.,Ltd. © 1999-2021... - Page 9 For GPS antenna connection, SMA female, able to connect 407160002 GPS antenna or any other compatible type. Voltage sources output terminals Model: K3166i Up to 7 x 310V voltage channels output, Channel Ub & Uc also used for Auxiliary DC outputs. Kingsine Electric Automation Co.,Ltd. © 1999-2021...
- Page 10 6 phase mode or 3 phase mode (2 groups parallel connection), please follow below instruction for the wire connections before inject current. 6 phase independent output connection method, in KRT software, this is normal testing situation Kingsine Electric Automation Co.,Ltd. © 1999-2021...
- Page 11 Binary output terminals (Relay type) 4 pairs Binary outputs (binary 1~4), 4mm banana type terminals, relay type, see Binary output Binary Input terminals 8 Pairs binary input, 4mm banana type terminals, also used for Kingsine Electric Automation Co.,Ltd. © 1999-2021...
-
Page 12: Rear & Right Panel
3.1.2 Rear & Right Panel Description Fans x 4 Note: Don't hinder the fans air outlet while using. Right Panel Power supply socket, Main switch and Protection grounding port. See: Power supply & Environment Kingsine Electric Automation Co.,Ltd. © 1999-2021... -
Page 13: Technical Parameters
1-Phase AC (L-N) 1 × 248 VA max 1 × 180 VA max 1-Phase AC (L-L) 3 × 140 W at 350Vdc 3 × 105 W at 350Vdc 3-DC(L-N) K3163i & K3130i Voltage Outputs Voltage Range Kingsine Electric Automation Co.,Ltd. © 1999-2021... - Page 14 4.Data measured for 4-phase systems symmetric conditions. (0 °, 90 °, 180 °, -90 °) 5.Valid for sinusoidal signals 50/60Hz and tested at 10V output. 6.Signals above 1KHz not support all the test modules. Kingsine Electric Automation Co.,Ltd. © 1999-2021...
-
Page 15: Current Sources
Range II: 35A Current Range Auto Range Resolution 1mA / 2mA for 2-phases in parallel Frequency Frequency Range 0~1000Hz at 0~Imax Frequency Error ±0.5ppm Frequency 0.001 Hz Resolution Phase Angle Phase Range -360° ~ +360° Kingsine Electric Automation Co.,Ltd. © 1999-2021... -
Page 16: Low-Level Outputs
(min) Low-Level outputs 3.2.2 K31 series have 13 Low-Level outputs represents an interface connector holding two independent generator triples. These 13 high accuracy analog signal sources can serve to either control an external amplifier or to directly provide small signal outputs. -
Page 17: Auxiliary Dc Source (Battery Simulator)
AC mode of Channel Ub & Uc. once Auxiliary DC activated, Channels Ub and Uc AC mode outputs will automatically disable to invalid. Range 0~350V @ 140W max Accuracy 0.5%Rg Guar. Kingsine Electric Automation Co.,Ltd. © 1999-2021... -
Page 18: Binary Input
Relay type Binary Output (Relay Type) Quantity 4pairs (1~4) Type Potential free relay contacts, software controlled Break Capacity AC Vmax: 400Vac / Imax:8A / Pmax:2500VA Break Capacity DC Vmax: 300Vdc / Imax:8A / Pmax:150W Kingsine Electric Automation Co.,Ltd. © 1999-2021... -
Page 19: Fiber Optical Port
Fiber Type 62.5/125um (Multiple optical fiber, Orange Red) Wavelength 1310nm Transmission >1Km Indicator Spd Green(light): Valid connection Link/Act Yellow(Blinking): Data exchanging Note: All hardware of this module are ready for activated IEC61850 SMV & GOOSE Kingsine Electric Automation Co.,Ltd. © 1999-2021... -
Page 20: Ethernet Port
1 pulse input port, 5Vdc high level valid only. Pulse Range 500KHz pulse input Max. Pulse Output 1 Transistor output, maximum load 5Vdc/5mA Details of interface see: Fast Binary output & Energy pulse adapter Kingsine Electric Automation Co.,Ltd. © 1999-2021... -
Page 21: Transducer Calibration Module
<0.2% rg Typ. <0.5% rg Guar. Input Impedance 15Ω 3.3.3 IEC61850 SMV & GOOSE K31 series products able to test IEC61850 SMV & GOOSE, (SMV complied IEC61850-9-1, IEC61850-9-2, IEC61850-9-2LE). The communication adapt see Fiber optical port Each fiber port able to simulate maximum 16 SMV channels and map 16 GOOSE channels. - Page 22 2mm pin for connection of 4mm 1pack banana plugs 4x4mm Include: black x 6, red x 2, yellow x 2, green x 2, blue x 2 1mm pin for connection of 4mm 1pack banana plugs 4x4mm Kingsine Electric Automation Co.,Ltd. © 1999-2021...
-
Page 23: Optional Accessories
640mm x 505mm x 280mm Protection grade: IP67 Impact resistance: IK08 Optional Accessories 3.4.2 Photo Descriptions Qty. 421080068 K31 Low-Level output Independen adapter t Optional: 1set 16 Pins combination plug to bananas see: Low-Level outputs Kingsine Electric Automation Co.,Ltd. © 1999-2021... - Page 24 (Optional Length: 3m with IEC61850 type:62.5/125um functions) 451070002 LC-ST fiber optical 2pcs cable (Optional Length: 3m with IEC61850 type:62.5/125um functions) 451070006 ST-ST fiber optical 2pcs cable (Optional Length: 3m with IEC61850 type:62.5/125um functions) Kingsine Electric Automation Co.,Ltd. © 1999-2021...
-
Page 25: Fast Binary Output & Energy Pulse Adapter
1Kohm resistor between the Pin6 and Pin7 to convert the input signal from passive to active. The pin 8 is 5V pulse output for energy meter calibration; Kingsine Electric Automation Co.,Ltd. © 1999-2021... - Page 26 2 and pin 3; All these fast outputs are open-collector circuit, user have to connect an external active signals(refer the red squareness of below picture). (Fast binary outputs, open-collector interface) See: Semiconductor Binary outputs Kingsine Electric Automation Co.,Ltd. © 1999-2021...
-
Page 27: Low-Level Output Adapter
Signals Bananas color Yellow 01-UA Green 02-UB 03-UC Blue 04-UX Yellow 05-Ua Green 06-Ub 07-Uc OUTGND Black 08-GND1 Yellow 09-IA Green 10-IB 11-IC Yellow 12-Ia Green 13-Ib 14-Ic OUTGND Black 15-GND2 OUTGND Black 16-GND3 Kingsine Electric Automation Co.,Ltd. © 1999-2021... -
Page 28: Part 4 Faq
Warning while not in The power Check the power supply motion after supply is whether it is too high. Make starting-up abnormal. sue the voltage of power supply is within 15% of the rated power supply Kingsine Electric Automation Co.,Ltd. © 1999-2021... - Page 29 AC zero offset in the tested data are not inappropriately system calibration module right, when the testing is in process. It shows ”unable to 1.The mismatch Download the update file that Kingsine Electric Automation Co.,Ltd. © 1999-2021...
- Page 30 “mismatching in the 2.The update Select “unzip to current file updating file and file is unzipped. folder” in unzipping update file. the current version” in software updating progress. Kingsine Electric Automation Co.,Ltd. © 1999-2021...
