- Page 1 KF86 Hardware Instructions V1.3.1 Kingsine Electric Automation Co.,Ltd. © 1999-2022...
- Page 2 Thank you for your using Kingsine brand protection relay testing system. Hope that the technical data and help information in the manual will be provided to you as detailed as possible about how to use Kingsine products. Meanwhile, we shall be much appreciated to receiving any views about this manual from all the readers and all the experts in the line of relay testing.
- Page 3 KF86 Hardware Instructions Kingsine Electric Automation Co.,Ltd. © 1999-2022 All rights reserved. No parts of this work may be reproduced in any form or by any means - graphic, electronic, or mechanical, including photocopying, recording, taping, or information storage and retrieval systems - without the written permission of the publisher.
-
Page 4: Table Of Contents
Optional Accessories Fast Binary output & E nergy pulse adapter ..............................23 C-Shunt ..............................25 Low -Level output adapter ..............................26 3.5 Hardware Test Tips ........................... 27 ................................27 3.5.1 Optional Accessories_2 Part 4 FAQ Kingsine Electric Automation Co.,Ltd. © 1999-2022... -
Page 5: Part 1 Safety Operation
The KF86 set may only be operated by trained personnel. Any maloperation can result in damage to property or persons. KF86 must only be used from a power outlet that has a protective earth. refer to Power supply & Environment Do not connect any of the front panel VOLTAGE/CURRENT OUTPUTS, respectively, to protective earth. -
Page 6: Part 2 Overview
Analog and Binary Transient Record Transient play back up to 3KHz Lightweight, <10Kg Fully function KRT software testing modules Able to test Able of what KF86 series can test Items ANSI IEC61850 numerical IEDs relay & merge unit Distance protection relay... - Page 7 Overview Voltage regulating relays Over-impedance relays, Z> Under-impedance relays, Z Time-delay relays Kingsine Electric Automation Co.,Ltd. © 1999-2022...
-
Page 8: Part 3 Hardware Instruction
Hardware Instruction Panel descriptions Front Panel 3.1.1 WIFI port Wifi sending port, Inbuilt WIFI DHCP service, use for WIFI connection USB port USB port, which is use for report upload and software upgrade COM port Kingsine Electric Automation Co.,Ltd. © 1999-2022... - Page 9 +1+1+2+2+2)(Binary input turn over potential can be programmable),Sampling Rate:10kHz, Time measurement range:0 105s,Time accuracy:±1ms @ <1s, ±0.1% @ ≥1s 10 group FT3 type Fiber port Kingsine Electric Automation Co.,Ltd. © 1999-2022...
-
Page 10: Power Switch Button
" means power on status," " means power off status. Grounding port Sometimes, power supply without grounding terminal, we need to connect grounding port to earth stable to keep human safety. We have grounding cable in accessories package Kingsine Electric Automation Co.,Ltd. © 1999-2022... -
Page 11: Rear & Right Panel
R+,R- port: Device receive external time source for synchronize. TR_O: Two or more KINGSINE relay tester synchronize with external time TR_I: Two or more KINGSINE relay tester synchronize with internal time.(For example, we can use switch signal to trigger) IRIG-B Fiber port... -
Page 12: Technical Parameters
Technical Parameters Current and Voltage outputs 3.2.1 Model Configuration 3.2.1.1 Model Current outputs Voltage outputs KF86(6U6I) 6*35A / 3*70A 6*310V KF86(4U6I) 6*35A / 3*70A 4*310V KF86(4U3I) 3*35A 4*310V Kingsine Electric Automation Co.,Ltd. © 1999-2022... -
Page 13: Voltage Sources
1 × 200 VA max 1 × 175 VA max 3-DC(L-N) 3 × 180 W at 350Vdc 3 × 150 W at 350Vdc KF86(4U6I) & KF86(4U3I) Voltage Outputs Voltage Range 3-Phase AC (L-N) 3 × 310 Vac 4-Phase AC (L-N) *1 4 ×... -
Page 14: Current Sources
6. Signals above 1KHz not support all the test modules. 7. Rd = reading; Rg = Range value. Current Sources 3.2.1.3 KF86(6U6I) & KF86(4U6I) Current Outputs Current Range 6-Phase AC (L-N) 6 × 0~35A (Group1 and Group2 independent) 3-Phase AC (2L-N) 3 ×... - Page 15 (6 phase mode, group 1 and group 2 independent, simultaneous) Current output (A) 0-20 Power (W) 0-1200 1250 1350 1200 1200 Duty Cycle 100% T.on (Sec) >1800 T.off (Sec) T.continue for Cycle (min) >30 Kingsine Electric Automation Co.,Ltd. © 1999-2022...
-
Page 16: Low-Level Outputs
3.2.2 Low-Level outputs KF86 series have 10 Low-Level outputs represents an interface connector holding two independent generator triples. These 10 high accuracy analog signal sources can serve to either control an external amplifier or to directly provide small signal outputs. -
Page 17: Binary Output
Binary Output (Relay Type) Quantity 4pairs (1~4) Type Potential free relay contacts, software controlled Break Capacity AC Vmax 250V AC / Imax 0.5A Break Capacity DC VmVmax 250V DC / Imax 0.5A Fiber optical port 3.2.6 Kingsine Electric Automation Co.,Ltd. © 1999-2022... -
Page 18: Ethernet Port
Connection Type Standard AC socket 60320 Operating Temperature C ~ 55 Storage Temperature C ~ 70 Humidity <95%RH, non-condensing Grounding Terminal 4mm banana socket Weight 10 Kg Dimensions(W x D x H) 390mm×256mm×140mm Optional Modules Kingsine Electric Automation Co.,Ltd. © 1999-2022... -
Page 19: Energy Meter Calibration Module
Input Impedance 15Ω IEC61850 SMV & GOOSE 3.3.3 KF86 series products able to test IEC61850 SMV & GOOSE, (SMV complied IEC61850-9-1, IEC61850-9-2, IEC61850-9-2LE). The communication adapt see Fiber optical port Each fiber port able to simulate maximum 36 SMV channels and map 128 GOOSE channels. -
Page 20: Accessories
Power supply cable, 1.8m,10A/250V 1 package Direct net cable, 3 meters 1 pcs Factory certification 1 pcs KF86 Hardware User manual+Maintenance manual 1 pcs 8GB flash 1 pcs PP Plastic waterproof trolley transport case 1 pcs PP Plastic waterproof internal Liner... - Page 21 Red x 2; Yellow x 2; Green x 2; Blue x 2; Black x 4; 451010029 Carry case, pack the test kit inside for safety storage or transport 640mm x 505mm x 280mm Kingsine Electric Automation Co.,Ltd. © 1999-2022...
-
Page 22: Optional Accessories
Clamp for standard meter Independent current measurement optional accessory Input range: AC 0~30A, class 1set Jaw size: 20mm Max. channel 30120057 C-Shunt Independent optional Input/Output:4mm banana accessory plugs 1set See: C-Shunt for ordering channel reference. Kingsine Electric Automation Co.,Ltd. © 1999-2022... -
Page 23: Fast Binary Output & Energy Pulse Adapter
(Optional with IEC61850 type:62.5/125um functions) 451070006 ST-ST fiber optical cable 2pcs Length: 3m (Optional with IEC61850 type:62.5/125um functions) Fast Binary output & Energy pulse adapter 3.4.3.1 Material Order No.: 421080066 (14pin combination plug to bananas) Kingsine Electric Automation Co.,Ltd. © 1999-2022... - Page 24 Pin7 pulse input; or refer the below open-collector picture connect a external 1Kohm resistor between the Pin6 and Pin7 to convert the input signal from passive to active. The pin 8 is 5V pulse output for energy meter calibration; Kingsine Electric Automation Co.,Ltd. © 1999-2022...
-
Page 25: C-Shunt
(Fast binary outputs, open-collector interf ace) See: Semiconductor Binary outputs C-Shunt 3.4.3.2 For current measurement, It can be directly inserted into the binary inputs 1~8 Connector type: 4mm banana plugs 1 C-Shunt may measuring 1 channel only. Kingsine Electric Automation Co.,Ltd. © 1999-2022... -
Page 26: Low-Level Output Adapter
Resistance tolerance: 0.1% Resistance tolerance: 0.1% Temperature coefficient: <10ppm/K (0~70°C) Temperature coefficient: <10ppm/K (0~70°C) Metarial Order No.: 30120057-1 Metarial Order No.: 30120057-2 Connection method: Low-Level output adapter 3.4.3.3 Material Order No.:421080068 (16pin combination plug to bananas) Kingsine Electric Automation Co.,Ltd. © 1999-2022... -
Page 27: Hardware Test Tips
Reference to wire connection, we use Relay test set injection voltage to burden side, and measure current from the circuit, in this case we can get burden specification after calculate the injection value and measure value. Wiring check Kingsine Electric Automation Co.,Ltd. © 1999-2022... - Page 28 Step2: The secondary voltage of the voltage loop can be applied either at the TV root or at the secondary open (or fuse) outlet of the local terminal box. The voltage of each group of phase voltages of the TV secondary loop can be applied 57.7 V respectively at Kingsine Electric Automation Co.,Ltd. © 1999-2022...
- Page 29 TV ratio, polarity, the circuit's exactly right CT/VT Polarity Check We use KF86 output pulse current with setting value when we connect device to CT primary. And a phase table will connect to secondary side to receive the pulse current from secondary side.
-
Page 30: Part 4 Faq
Connect the power cable to test set loosened,poor correctly and stably. contact. 4. inner part of the Please contact tech support of Kingsine test set failed KRT no response while 1.Communication failCheck PC connecting cable status and the test set is power on make sure it works well 2.Connecting setting... - Page 31 Set the frequency to 50/60HZ testing protection relay frequency. set are irregular or the 2.The output zero is Contact Kingsine to calibrate the AC tested data are not right, inappropriately big zero offset in the system calibration when the testing is in module process.
- Page 32 Kingsine Electric Automation Co.,Ltd.
