- Page 1 8HP Eurorack Module Designed in E.U. Shakmat Archer’s Rig Building Guide www.shakmat.com...
- Page 2 Therefore, we strongly advised you to follow the steps as described in this guide :) If by any chance there is a missing or damaged part in your kit, feel free to contact us at shakmat.com/support Building Guide Shakmat Archer’s Rig...
- Page 3 16x16 power cable Potentiometer caps Pack 2 User manual Amber LED Amber LED push button White LED push button Green LED push button Jack nuts Potentiometer nuts M3 metal screw 7 segments display Tactile switche caps Building Guide Shakmat Archer’s Rig...
- Page 4 Assemble three pairs of headers with the two PCBs Building Guide Shakmat Archer’s Rig...
- Page 5 Solder one point Solder one point Solder one point Building Guide Shakmat Archer’s Rig...
- Page 6 Flip the PCBs Check PCBs parallelism! Solder one point Solder one point Solder one point Building Guide Shakmat Archer’s Rig...
- Page 7 Solder remaining points Solder remaining points Solder remaining points Building Guide Shakmat Archer’s Rig...
- Page 8 Flip the PCBs Check PCBs parallelism! Solder remaining points Solder remaining points Solder remaining points Building Guide Shakmat Archer’s Rig...
- Page 9 Separate the two PCBs Reserve the bottom PCB Building Guide Shakmat Archer’s Rig...
- Page 10 Place power header Solder one point Building Guide Shakmat Archer’s Rig...
- Page 11 Check header & PCB perpendicularity! Solder remaining points Building Guide Shakmat Archer’s Rig...
- Page 12 Place 3 switches but do not solder! Building Guide Shakmat Archer’s Rig...
- Page 13 Place 4 potentiometers but do not solder! Building Guide Shakmat Archer’s Rig...
- Page 14 As the buttons embed an LED, you must pay attention to the orientation. The three holes on the PCB have to match the three mouldings on the base of the component as shown below: Component base holes Building Guide Shakmat Archer’s Rig...
- Page 15 Place 1 amber LED push button but do not solder! Building Guide Shakmat Archer’s Rig...
- Page 16 Place 2 white LED push button but do not solder! Building Guide Shakmat Archer’s Rig...
- Page 17 Place 9 jack but do not solder! First & second row share holes for one of their pin. Building Guide Shakmat Archer’s Rig...
- Page 18 LED polarity Place 6 amber LED but do not solder! Building Guide Shakmat Archer’s Rig...
- Page 19 Place the 7 segments display but do not solder! Dot on displays should be at the bottom Building Guide Shakmat Archer’s Rig...
- Page 20 Masking tape over LED holes Building Guide Shakmat Archer’s Rig...
- Page 21 Place front panel on the populated PCB Building Guide Shakmat Archer’s Rig...
- Page 22 Tighten 4 hex nuts Push down three button caps Building Guide Shakmat Archer’s Rig...
- Page 23 Check that the 4 potentiometers are still well-sited through the PCB, then solder them. Building Guide Shakmat Archer’s Rig...
- Page 24 Push each LED through the front panel until it sticks to the masking tape. Building Guide Shakmat Archer’s Rig...
- Page 25 Solder the first column of LEDs and cut off the excess legs. Building Guide Shakmat Archer’s Rig...
- Page 26 Solder the second column of LEDs and cut off the excess legs. Building Guide Shakmat Archer’s Rig...
- Page 27 Solder the third column of LEDs and cut off the excess legs. Building Guide Shakmat Archer’s Rig...
- Page 28 Check that the 7 segments display lays flat on the front panel window, then solder one leg Building Guide Shakmat Archer’s Rig...
- Page 29 Check the alignment of the display through the front panel window, correct it by reheating the previously soldered point, if necessary, then solder the remaing legs and cut off the excess. Building Guide Shakmat Archer’s Rig...
- Page 30 Check that the 4 LED push buttons click well, then solder them. Building Guide Shakmat Archer’s Rig...
- Page 31 Check that the 3 push buttons click well, then solder them. Building Guide Shakmat Archer’s Rig...
- Page 32 Solder 9 jack connectors. Building Guide Shakmat Archer’s Rig...
- Page 33 Assemble the two PCBs together Building Guide Shakmat Archer’s Rig...
- Page 34 Power up your Archer’s Rig while pressing the Closed & Trig buttons. Confirm Wait by pressing Load Make sure no jacks are inserted, then press Load to confirm Building Guide Shakmat Archer’s Rig...
- Page 35 Congratulations, you're done! Building Guide Shakmat Archer’s Rig...
