Summary of Contents for Grace Company Wonderfoot 360

  • Page 1 Copyright 11/5/2021 Version 2.0...
  • Page 2 Table of Contents Included Parts and Tools ......... 3 Changing the Lens ..........5 Installing the 360 Wonderfoot ......... 6 Reinstalling the Standard Hopping Foot ....11...
  • Page 3: Included Parts And Tools

    Included Parts and Tools Hopping Foot Height Tool SMP-04-12171 Thumb Screw 4 mm HDW-03-15109 360 Wonderfoot SHCS M3 x 8 mm ACC-09-15216 HDW-03-10966 Lens A - Stitch in the Ditch ACC-05-15206 Lens B - 1/4” Offset ACC-05-15207 Lens C - 3/8” Offset ACC-05-15208 Lens D - 1/4”...
  • Page 4 Check the style of hopping STOP foot currently installed on your machine. Continue to the installation instructions. Install the Standalone Hopping Foot Collar upgrade. Purchase from www.graceframe.com.
  • Page 5: Changing The Lens

    Changing the Lens To remove: Push the tab inward to pop out the lens. Use a small, flat object. You don’t want to touch the machine needle! To install: Slide the lens under the inside ridge, then push down.
  • Page 6: Installing The 360 Wonderfoot

    Installing the 360 Wonderfoot Take the following steps to remove the hopping foot and install the 360 Wonderfoot: Use the hand wheel to raise the needle to the highest position. While holding the needle in place, remove the needle bar thumb screw. If needed, loosen with a flat head screwdriver (not included).
  • Page 7 While still holding the needle in place, attach the new 4 mm thumb screw. If using a flat head screwdriver, do not over-tighten the screw. Thumb Screw 4 mm If the needle moves, use your needle magnet to realign it (see machine manual for details). Use a 3 mm Allen wrench (not included) to remove the hopping foot screw and the hopping foot.
  • Page 8 Slide the 360 Wonderfoot onto the hopping foot collar. Attach with the 3 mm Allen wrench and hopping foot screw, but do not tighten. 360 Wonderfoot Slowly lower the needle with the hand wheel. The needle should dip into the center hole without contacting the lens.
  • Page 9 Continue until the needle reaches its lowest position, then slide the hopping foot height tool under the 360 Wonderfoot. Hopping Foot Height Tool Slide from behind, under the Wonderfoot wheel. Adjust the 360 Wonderfoot so it rests evenly on the height tool, then tighten the hopping foot screw with the 3 mm Allen wrench.
  • Page 10 Tips: • Use the included tutorial patterns to practice with each 360 Wonderfoot lens. You can download and reprint the patterns at the following link: graceframe.com/en/accessories/360-wonderfoot • Before moving the machine onto fabric, rotate the inside circlet so the wheel housing is on the far end, away from the fabric edge.
  • Page 11: Reinstalling The Standard Hopping Foot

    Reinstalling the Standard Hopping Foot Take the following steps to remove the 360 Wonderfoot and reinstall the standard hopping foot: Use the hand wheel to raise the needle to the highest position. Use a 3 mm Allen wrench (not included) to remove the hopping foot screw and the 360 Wonderfoot.
  • Page 12 Slide the standard hopping foot onto the collar. Attach with the 3 mm Allen wrench and hopping foot screw, but do not tighten. Standard Hopping Foot Slowly rotate the hand wheel until the needle is in the lowest position. If the hopping foot gets stuck, loosen the screw more.
  • Page 13 Slide the hopping foot height tool under the hopping foot. Hopping Foot Height Tool Adjust the hopping foot so it rests evenly on the height tool, then tighten the hopping foot screw with the 3 mm Allen wrench. Hopping Foot Screw...
  • Page 14 www.graceframe.com 1-800-264-0644...
