Yacht Controller SUPREMO V-IPS User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User's manual
2
May 2024
Office - 4545 Ponce De Leon Boulevard - Coral Gables, FL 33146
Showroom - 1300 SE 17th Street - Fort Lauderdale, FL 33316
Phone: 305.667.5811 Fax: 305.663.5551 Toll Free: 888.898.8608 www.YachtController.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SUPREMO V-IPS and is the answer not in the manual?

Questions and answers

Related Manuals for Yacht Controller SUPREMO V-IPS

Summary of Contents for Yacht Controller SUPREMO V-IPS

  • Page 1 User’s manual May 2024 Office - 4545 Ponce De Leon Boulevard - Coral Gables, FL 33146 Showroom - 1300 SE 17th Street - Fort Lauderdale, FL 33316 Phone: 305.667.5811 Fax: 305.663.5551 Toll Free: 888.898.8608 www.YachtController.com...
  • Page 2 Thank you for your purchase of the Yacht Controller system. We are sure you will be well pleased with its operation and your wireless control of your yacht. If we can be of assistance to you at any time please do not hesitate to contact us via e mail.

  • Page 3: Table Of Contents

    Summary SUMMARY ............................... 3 1. INTRODUCTION ............................4 1.1. M ......................4 AIN FEATURES OF THE TRANSCEIVER 2. IMPORTANT RULES BEFORE USE ......................5 3. TRANSCEIVER FUNCTIONING ........................6 3.1. W ..............................6 ARNINGS 3.2. A ..........................7 CTIVATION PROCEDURE 3.3.

  • Page 4: Introduction

    1. Introduction 1.1. Main features of the transceiver The transceiver is equipped with an output control joystick, which exactly reproduces the functions of the original Volvo IPS joystick. On the transceiver are also present the following control buttons: Power on / off. Bow and Stern thrusters.

  • Page 5: Important Rules Before Use

    For your safety do not try to open the transceiver or remove the battery. These operations may cause damages to the battery and to the transceiver, cause injuries and make the transceiver unsafe. In case of failures and malfunctions contact an authorized Yacht Controller dealer. ATTENTION: It is necessary to do a full recharge of the transceiver at least once a month.

  • Page 6: Transceiver Functioning

    This must not worry because, thanks to the communication protocol safety, it is not possible that the system accepts wrong commands. Also, in the nearby presence of other Yacht Controller devices, operating at the same time on adjacent boats, improper activations are not possible because the transceivers continuously modify the communication frequency with the receivers.

  • Page 7: Activation Procedure

    3.2. Activation procedure DANGER: Before using Supremo carefully read chapter 2 "Important rules before use". • Start the main engines in accordance with the usual procedure. • Enable the control head connected to the Supremo receiver by pressing the “Station” button with the levers in the neutral position.
  • Page 8 ON / OFF and engage button Transmission LEDs Figure 2: Power on/off button and transmission LEDs • If the operation has had a good result, to the danger acoustic signal of the receiver takes the place the waiting signal of the engagement. This last signal, characterized by a beep about every two seconds, shows that there is the connection between the receiver and the transceiver and that the system, not yet operational, is waiting for the engagement.

  • Page 9: Deactivation Procedure

    3.3. Deactivation procedure • To regain control from the control station connected to the Supremo receiver, move the right control head lever slightly, then immediately return it to the neutral position. If instead, to regain control from another station, press (with the levers in neutral position) the “Station”...

  • Page 10: Use Of The Joystick

    4. Use of the Joystick DANGER: The use of the Supremo system is reserved to adults with of a boat license and equipped with all the necessary requirements to drive a vessel. DANGER: IT IS ABSOLUTELY REQUIRED THAT THE ELECTRONIC CONTROL LEVERS REMAIN IN THE NEUTRAL POSITION DURING THE USE SUPREMO.
  • Page 11 AUTO AUTO NOTE JOYSTICK ______________________________________________________________________________________________...
  • Page 12 AUTO AUTO NOTE JOYSTICK ______________________________________________________________________________________________...
  • Page 13 AUTO AUTO NOTE JOYSTICK ______________________________________________________________________________________________...
  • Page 14 AUTO AUTO NOTE JOYSTICK ______________________________________________________________________________________________...
  • Page 15 AUTO AUTO NOTE JOYSTICK ______________________________________________________________________________________________...
  • Page 16 AUTO AUTO NOTE JOYSTICK ______________________________________________________________________________________________...
  • Page 17 AUTO AUTO NOTE JOYSTICK ______________________________________________________________________________________________...
  • Page 18 AUTO AUTO NOTE JOYSTICK ______________________________________________________________________________________________...
  • Page 19 AUTO AUTO NOTE JOYSTICK ______________________________________________________________________________________________...

  • Page 20: Exclusive Activation Of The Bow/Stern Thrusters

    4.2 Exclusive activation of the bow/stern thrusters IMPORTANT: These buttons (see picture 1, buttons 6 7 8 e 9) are always active to allow small and quick variations without the delay of the engines. To activate the right bow thruster excluding the engines, keep pressed button 6.

  • Page 21: Acceleration (Optional)

    10 sec. 5 sec. If you desire a customized profile, it is possible to ask it to Yacht Controller, with a surcharge on the standard price. The percentage of acceleration is meant relatively to the maximum rpm of the engines and is reached, depending on the current profile, in the estimated time.

  • Page 22: Dynamic Positioning (Optional)

    This is an optional function, which means it may not be installed on your system. If you wish to implement it, request it at a surcharge from Yacht Controller. To activate the function, press and hold the Joystick button for more than 3 seconds. Activation is signaled by the blinking of the green and yellow LEDs located between the anchor winch activation buttons (see figure 1).

  • Page 23: Hold Function

    4.5. Hold function Move the boat sideways using only bow and stern thrusters, in order to keep the boat close to the dock so that even a single person can easily manage the mooring maneuver. IMPORTANT: This function can only be used on boats equipped with proportional stern and bow thrusters.

  • Page 24: Maintenance

    If the battery gets completely exhausted, it will be necessary to replace it at the Yacht Controller laboratories. IMPORTANT: In case of non-compliance with the rules of use, the battery replacement WILL NOT BE COVERED BY WARRANTY.

  • Page 25: How To Clean The Transceiver

    If the transceiver is turned on when it falls into the water, it may have irrevocable damage. Before using it again TEST IT COMPLETELY TIED UP AT DOCKSIDE OR IN A SECURE AREA. If you notice ANY anomalies, contact the retailer or Yacht Controller Customer Service. ______________________________________________________________________________________________...

  • Page 26: Problems And Malfunctions

    If you encounter problems which are not contemplated in this table or if the possible malfunction is repeated, contact the Dealer Yacht Controller’s customer service directly ______________________________________________________________________________________________...

  • Page 27: Technical Specifications

    6. Technical specifications Power: Rechargeable battery in lithium 3.7V Cover: In ABS with protection degree IP65. Number of channels: 25 (5 x 5) Transmission code: 16 bits digital Dimensions (LxHxW): 70 x 123 x 55 mm Weight: 140 g Power of transmission: 10mW (30-50 mt.

  • Page 28: Warranty

    Each SUPREMO system is warranted for 24 months, as from the date of sale to the first user . The warranty on the Yacht Controller S.r.l.’s devices is for all the possible defects of material and breakdowns not caused by the customer.

  • Page 29: Ce Mark

    8. CE Mark 0051 SUPREMO IS A SYSTEM IN COMPLIANCE WITH THE FOLLOWING CE DIRECTIVES: RED (RADIO EQUIPMENT DIRECTIVE) DIRECTIVE 2014 / 53 / UE SECURITY REQUIREMENTS (ART. 3.1A): LOW VOLTAGE DIRECTIVE 2014/35/UE EMC REQUIREMENTS (ART. 3.1B): ELECTROMAGNETIC COMPATIBILITY DIRECTIVE EMC 2014/30/UE RADIO REQUIREMENTS (ART.

  • Page 30: Conformity Declaration

    Conformity Declaration The manufacturer: Yacht Controller S.r.l. Via Pavia, 21 20835 Muggiò (MB) Declares that the product: SUPREMO Is in compliance with the qualifications and with the pertinent dispositions established from the Directive 1999/5/CE. FCC ID: R86TX001YCDB Verification according to § 15.19 (a) (3): This device complies with Part 15 of the Rules.
