HD2VD33-8AVF
HD SDI 1080P ICR 33 IR
Weatherproof Dome Camera
FEATURES
•
SDI 1080P - 1920 x 1080
•
SDI / CVBS Output
•
1/2.8" Sony CMOS 2.0 Megapixel
•
2.8~12.0mm Megapixel Varifocal Lens / F1.4
•
33 IR LED; Distance up to 60ft / 20m
•
12V DC, 490mA max.
•
IP65 Rating
Please read the Manual before attempting to use this product.
Specifications and appearance are subject to change without notice.
Copyright © 2014. All Rights Reserved.
All manuals and user guides at all-guides.com
USER MANUAL
HDC-38
R201402-V12
Advertisement
Related Manuals for Okina USA HD2VD33-8AVF
Summary of Contents for Okina USA HD2VD33-8AVF
- Page 1 All manuals and user guides at all-guides.com HD2VD33-8AVF HD SDI 1080P ICR 33 IR Weatherproof Dome Camera USER MANUAL FEATURES • SDI 1080P - 1920 x 1080 • SDI / CVBS Output • 1/2.8” Sony CMOS 2.0 Megapixel • 2.8~12.0mm Megapixel Varifocal Lens / F1.4 •...
-
Page 2: Limited Warranty
When the video product exhibits a distinct change in performance. LIMITED WARRANTY OKINA USA products are covered under warranty for one (1) year from the date of purchase. The warranty will automatically be voided if any of the following occurs: 1. -
Page 3: Package Contents
All manuals and user guides at all-guides.com PACKAGE CONTENTS One (1) HD2VD33-8AVF Dome Camera Four (4) Mounting Screws Four (4) Wall Anchors One (1) User Manual * For any returns, please include all components listed above with original packaging in Resalable Condition. - Page 4 All manuals and user guides at all-guides.com LENS Default LENS VIDEO MANUAL Vari-Focal lens can be installed on this camera. Manual – Iris is adjusted manually DC – Iris is adjusted automatically by the camera according to light conditions. EXPOSURE EXPOSURE SHUTTER 1/60...
- Page 5 All manuals and user guides at all-guides.com ACCE (DWDR) Stand for Adaptive Contrast and Color Enhancement which is equivalent to dynamic range reduction technique. The contrast ratio of the image can be effectively expressed and the edge information can be improved in order to enhance the overall visibility of the image.
- Page 6 All manuals and user guides at all-guides.com SELECT AREA1,AREA2,AREA3 DISPLAY POSITION MOTION SENSITIVITY 0~100 MOTION VIEW OFF,ON DEFAULT RETURN RET / END PRIVACY SELECT AREA1~AREA8 DISPLAY ON/POSITION COLOR 1~16 DEFAULT RETURN RET / END LANGUAGE DEFECT LIV DPC ON,OFF LEVEL 0~60 STATIC DPC ON,OFF...
-
Page 7: Specifications
All manuals and user guides at all-guides.com SPECIFICATIONS Model HD2VD33-8AVF Image Sensor 1/2.8” SONY CMOS : 2.0 Megapixel Resolution NTSC: 1920x1080P @ 30fps / PAL: 1920x1080P @ 25fps Synchronizing System Internal Scanning System 2:1 Interlace Video Output SDI / CVBS... - Page 8 All manuals and user guides at all-guides.com www.okinausa.com www.okinausa.com HDC-38 MADE IN TAIWAN Copyright © 2014. All Rights Reserved. R201402-V12...
