Schwinn IC4: Why is the flywheel making a grinding noise?
Follow this troubleshooting guide to help resolve issues involving the brake magnets making contact with the flywheel on the
Schwinn IC4 indoor cycling bike.
Some common complaints may include:
Metallic grinding noise
Follow these steps to troubleshoot the issue
Tools you may need:
Phillips head screwdriver
5mm hex/Allen wrench, or the Allen wrench from the
hardware card included with your machine
10mm wrench, or the wrench from the hardware card
included with your machine
1.
Unplug the Resistance Sensor wire (reference 1) from the right-hand side of the bike. Using a Phillips head
screwdriver, remove the three screws attaching the black metal bracket to the bike's frame (reference 2).
This image shows the location of the Resistance Sensor. It is located on the user's right side of the bike
about:blank
Schwinn IC4: Why is the flywheel making a grinding noise?
(Reference 1)
(Reference 2)
ID: 11059.1
1/4
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Schwinn IC4
Summary of Contents for Schwinn IC4
- Page 1 3/11/24, 8:14 AM Schwinn IC4: Why is the flywheel making a grinding noise? Schwinn IC4: Why is the flywheel making a grinding noise? ID: 11059.1 Follow this troubleshooting guide to help resolve issues involving the brake magnets making contact with the flywheel on the Schwinn IC4 indoor cycling bike.
- Page 2 3/11/24, 8:14 AM Schwinn IC4: Why is the flywheel making a grinding noise? The three yellow circles indicate the location of the screws to remove in order to access the Resistance Sensor Magnet. Move the Resistance Sensor out of the way to uncover and remove the Resistance Sensor Magnet (reference 3). ...
- Page 3 3/11/24, 8:14 AM Schwinn IC4: Why is the flywheel making a grinding noise? The hardware to loosen is circled in yellow. Use the 10mm wrench with the Allen wrench in reference 5 to loosen the hardware. (Reference 5) The hardware to loosen is circled in yellow. Use the 5mm Allen wrench with the open-ended wrench in reference 4 to loosen the hardware.
- Page 4 A Customer Care Agent will be able to assess your current warranty eligibility and provide you with your options. Please note that if you did not purchase your machine directly from BowFlex, Schwinn, or Nautilus, we will need a copy of your purchase receipt in order to register your machine for warranty.
