Schwinn IC4 Troubleshooting Manual

3/11/24, 8:16 AM
Schwinn IC4: How do I prevent the seat from rotating on the seat post?
Follow this troubleshooting guide to help resolve issues involving the seat on the Schwinn IC4 indoor cycling bike.
Some common complaints may include:
Seat rotates on the Seat Post
Follow these steps to troubleshoot the issue
Tools you may need:
15mm, 17mm wrenches, or the wrenches from the hardware
card included with your machine
1.
Locate the Seat Clamp Bolts underneath the Seat (reference 1). Using a 15mm/17mm wrench, fully tighten both
bolts [11089.E].
2.
If the issue persists, disassemble and reassemble the Seat. Loosen the Seat Adjustment Knob (reference 2) and
remove the Seat from the Seat Post. With the Seat removed, inspect the Seat Clamp and seat assembly for damage.
Reinstall the Seat on the Seat Post and fully tighten the Seat Adjustment Knob and Seat Clamp Bolts (reference
3) [11089.F].
about:blank
Schwinn IC4:  How do I prevent the seat from rotating on the seat post?
The Seat Clamp Bolts are located underneath the seat, on either side of the seat's stem.
(Reference 1)
(Reference 2)
ID: 11089.1
