COM Port PWR Setting Jumpers
1 : PWR_COM1 (For COM Port1)
2 : PWR_COM3 (For COM Port3)
PWR_COM4 (For COM Port4)
20 : PWR_COM2 (For COM Port2)
PWR_COM5 (For COM Port5)
PWR_COM6 (For COM Port6)
1-2: +5V
2-3: +12V
3 : USB 3.2 Gen1 Connector (USB3H_2_3)
4 : SATA Power Output Connector
(SATA_PWR1)
5 : USB 2.0 Connectors
(USB2_2_3, USB2_5_6)
6 : SATA3 Connector (SATA3_1)
7 : SPI TPM Header
RST#
CS#
MOSI
GND
GND
CLK
MISO
IRA
TPM PWR
8 : USB 2.0 Port (USB2_4)
Jumpers and Headers Setting Guide
1 2 3
48
HDMI1
SATA_PWR1
47
46
1 1
1
45
USB3H_2_3
VGA2
44
1
43
USB 3.2 Gen1
Top:
42
T: USB3H_2
LAN1
B: USB3H_1
USB 2.0
Top:
41
T: USB2_8
LAN2
B: USB2_7
HD_AUDIO1 SPEAKER1
40
1
39
1
DACC2
1
38 37 36 35
9 : Brightness Control Mode
(BLT_PWM1)
1-2: From eDP PWM to CON_LBKLT_CTL
2-3: From LVDS PWM to CON_LBKLT_CTL
* Please set to 1-2 when adjusting brightness by Brightness
Control bar under OS.
* Please set to 2-3 when adjusting brightness by BLT_VOL1.
10 : Chassis Intrusion Headers
CI1:
Open: Normal
Short: Active Case Open
Cl2:
Open: Active Case Open
Short: Normal
11 : CPU FAN Connector (+12V) (CPU_FAN1)
12 : PWR_BAT2
Open: Normal
Short: Charge Battery
GND +5V
1
13 : Power Loss Header (PWR_LOSS1)
+12V GND
Open: No Power Loss
Short: Power Loss
14 : 4-pin ATX Power Connector
1-2: GND
3-4: DC Input
15 : Battery Connector (BAT1)
16 : Digital Input / Output Power Select
(JGPIO_PWR) (JGPIO_PWR1)
1-2: +12V
2-3: +5V
17 : Digital Input / Output Default Value
Setting (JGPIO_SET1)
1-2: Pull-High
2-3: Pull-Low
4 5 6 7
USB2_4
1 1
BIOS
1 1
TPM1
USB2_5_6 USB2_2_3
ROM
SATA3_1
1
CPU_FAN1
SATA3_2
1
1
1
ESPI1
1
1
JGPIO1
1 1
1
PCIE1
PANEL1
PLED PWRBTN
1
1
UART2
HDLED RESET
34 33 32 31 30 29 28 27 26 25
1
GND
Signal
1
CPU_FAN_SPEED
FAN_SPEED_CONTROL
2 4
1
3
8 9 10
1 1
1
CI2 CI1
BLT_PWM1
1 1
BAT1
ATX12V1
JGPIO_PWR1 JGPIO_SET1
1 1
BLT_PWM2
1
1
CLRMOS1
1
1
1 1
CLRMOS2
PWR_COM2
PWR_COM5 PWR_COM6
SMB_TEST1
SIO_AT1
1 1 1
1
COM2 COM6
COM5
24 23
18 : 24-pin ATX Power Input Connector
19 : CON_LBKLT_CTL Voltage Level
(BLT_PWM2)
1-2: +3V
2-3: +5V
21 : Clear CMOS Jumpers
CLRMOS1:
1-2: Normal
2-3: Clear CMOS
CLRMOS2:
Open: Normal
Short: Auto Clear CMOS When AC Power
On
22 : SIO_AT1
Open: ATX Mode
Short: AT Mode
GND
+12V
23 : Internal COM Port Headers
(COM2, 5, 6) (RS232)
1
Signal Signal
PIN PIN PIN
Name Name
10 N/A 8 CCTS# 6
9 PWR 7 RRTS# 5
24 : SMB_TEST1
1
Signal Signal
PIN PIN PIN
Name Name
1 GPIO 2 SMB_CLK
25 : System Panel Header (PANEL1)
PLED+
PLED-
PWRBTN#
GND
1
GND
RESET#
GND
HDLED-
HDLED+
11
12
13
14
15
16
17
18
19
20
21
22
12 24
1 13
2
1
Signal Signal Signal
PIN PIN
Name Name Name
DDSR# 4 DDTR# 2 RRXD
GND 3 TTXD 1 DDCD#
Signal Signal
PIN
Name Name
3 SMB_DATA 4 GND
