COM Port PWR Setting Jumpers
1 : PWR_COM1 (For COM Port1)
2 : PWR_COM3 (For COM Port3)
PWR_COM4 (For COM Port4)
20 : PWR_COM2 (For COM Port2)
PWR_COM5 (For COM Port5)
PWR_COM6 (For COM Port6)
1-2: +5V
2-3: +12V
3 : USB3.2 Gen1 Connector (USB3H_2_3)
4 : SATA Power Output Connector
5 : USB2.0 Connectors
(USB2_2_3,
USB2_5_6)
6 : SATA3 Connector (SATA3_1)
7 : TPM Header
8 : USB2.0 Port (USB2_4)
Jumpers and Headers Setting Guide
9 : Brightness Control Mode
(BLT_PWM1)
1-2: From eDP PWM to CON_LBKLT_CTL
2-3: From LVDS PWM to CON_LBKLT_CTL
* Please set to 1-2 when adjusting brightness by Brightness
Control bar under OS.
* Please set to 2-3 when adjusting brightness by BLT_VOL1.
10 : Chassis Intrusion Headers
CI1:
Open: Normal
Short: Active Case Open
Cl2:
Open: Active Case Open
Short: Normal
11 : 4-Pin CPU FAN Connector (+12V)
12 : PWR_BAT2
Open: Normal
GND +5V
Short: Charge Battery
1
13 : Power Loss Header (PWR_LOSS1)
+12V GND
Open: No Power Loss
Short: Power Loss
14 : 4-pin ATX Power Connector
1-2: GND
3-4: DC Input
15 : Battery Connector
16 : Digital Input / Output Power Select
(JGPIO_PWR) (JGPIO_PWR1)
1-2: +12V
2-3: +5V
17 : Digital Input / Output Default Value
Setting (JGPIO_SET1)
1-2: Pull-High
2-3: Pull-Low
1
GND
Signal
GND
+12V
CPU_FAN_SPEED
1
FAN_SPEED_CONTROL
1
2 4
1
3
18 : 24-pin ATX Power Input Connector
19 : CON_LBKLT_EN and CON_LBKLT_CTL
Voltage Level (BLT_EN_PWM1)
1-2: +5V
2-3: +3V
21 : Clear CMOS Jumpers
CLRMOS1:
1-2: Normal
2-3: Clear CMOS
CLRMOS2:
Open: Normal
Short: Auto Clear CMOS When AC Power
On
22 : SIO_AT1
Open: ATX Mode
Short: AT Mode
23 : Internal COM Port Headers
(COM2, 5, 6) (RS232)
Signal Signal Signal Signal
PIN PIN PIN PIN
Name Name Name
10 N/A 8 CCTS# 6 DDSR# 4 DDTR#
9 PWR 7 RRTS# 5 GND 3
24 : SMB_TEST1
1
Signal Signal Signal
PIN PIN PIN
Name Name Name
1 GPIO 2 SMB_CLK 3 SMB_DATA
25 : System Panel Header
PLED+
2
26 : CAN1_2
1
1
HDLED+
Signal Signal Signal
PIN PIN PIN PIN
Name Name Name
10 N/A 8 GND 6 CAN2_RX0 4 CAN2_TX0
9 GP_E13 7 GND 5 CAN1_RX0 3 CAN1_TX0
12 24
1 13
2
1
Signal
PIN
Name Name
2 RRXD
TTXD 1 DDCD#
Signal
PIN
Name
4 GND
PLED-
PWRBTN#
GND
GND
RESET#
GND
HDLED-
Signal Signal
PIN
Name Name
2 3VSB
1 +3VSB
