Dairy Tech Matilda Gen III Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
OWNER'S MANUAL
SIMPLER
SMARTER
STRONGER
WARNING
Read and fully understand
owner's manual before
using this machine. Failure
to follow operating
instructions could result in
death or serious injury.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Matilda Gen III and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Dairy Tech Matilda Gen III

Summary of Contents for Dairy Tech Matilda Gen III

  • Page 1 SIMPLER SMARTER STRONGER WARNING Read and fully understand owner’s manual before using this machine. Failure to follow operating instructions could result in death or serious injury. OWNER’S MANUAL...
  • Page 3 Owner’s Manual for Gen3 Matilda Colostrum Pasteurizers & Warmers © Dairy Tech, LLC PO Box 250 Severance, CO 80546 Phone 866.384.2697 • Fax 970.454.8898 www.DairyTechInc.com Service@DairyTechLLC.com...

  • Page 4: Table Of Contents

    Table of Contents Say “Hello” to Matilda ......1 Helpful Hints for Pasteurization ... 21 For Your Safety ........1 Energy and Time Saving Tips ..... 23 Disclaimers ........... 2 Troubleshooting Matilda ...... 24 Product Warranty ........3 No Power to the Control Panel .....24 Product Registration ......

  • Page 5: Say "Hello" To Matilda

    M A T I L D A O W N E R ’ S M A N U A L Chapter Say “Hello” to Matilda Every newborn calf represents an opportunity for you to improve your herd’s production and health. The most influential, cost-effective way to accomplish this is to ensure she receives the correct volume of high quality, pathogen-free colostrum within the first hour...

  • Page 6: Disclaimers

    THIS USE AND CARE GUIDE. IT IS NOT INTENDED TO PASTEURIZE MILK OR OTHER GOODS FOR HUMAN CONSUMPTION. Dairy Tech, LLC has provided this use and care guide to assist you in the assembly, installation, and maintenance of your Matilda Model Pasteurizer (the “Pasteurizer”).

  • Page 7: Product Warranty

    Product Registration If this product was purchased directly from Dairy Tech in Windsor, CO, it has already been registered and no further action is required. If the product was purchased through a distributor or other representative, please call Dairy Tech, LLC. at 866-384-2697 within 10 days of receipt to register the Pasteurizer.

  • Page 8: Important Safety Instructions

    (40°C), for indoor use only. 8. Do not change pasteurization temperature and dwell time without consulting a technical expert at Dairy Tech, LLC. 9. Do not repair or replace any part of Matilda or attempt any servicing unless specifically recommended in the trouble-shooting portion of this manual. Any modifications made to the unit beyond these instructions will void all warranties.

  • Page 9: Installation

    M A T I L D A O W N E R ’ S M A N U A L Installation Choosing and Preparing a Location • Choose an indoor spot that will be protected from the elements. Extreme heat and freezing temperatures will damage the unit.

  • Page 10: Unpacking

    M A T I L D A O W N E R ’ S M A N U A L Unpacking Use care when unpacking your Matilda Model Pasteurizer. It will have arrived in one box or crate. Please make a note of any cautionary labels that are used on the carton suggesting orientation, where to cut with a knife, fragile, etc.

  • Page 11: Cleaning Your Matilda

    M A T I L D A O W N E R ’ S M A N U A L Cleaning your Matilda Before using this unit for the first time, wash out the inside of the sink with hot soapy water and rinse clean. Matilda should be cleaned regularly to ensure peak performance.

  • Page 12: Water Quality

    M A N U A L Water Quality  Dairy Tech LLC is not responsible for your water quality and the effects that it may have on our equipment. If you have dirty, hard, or otherwise poor-quality water, consider purchasing and installing a Dairy Tech water filtration/softener system (see part number below).

  • Page 13: Electrical Requirements

    M A T I L D A O W N E R ’ S M A N U A L Electrical Requirements The electrical supply cord is included with your purchase and requires installation only by certified electricians. Local ordinances and electrical codes will dictate wire sizing, lengths and connections including the need for power kill switches in some locations.

  • Page 14: External Circuit Breakers

    For prompt service, work through the troubleshooting guide in this UNAUTHORIZED manual to give an accurate description of the problem. SERVICE TECHNICIAN MAY The Dairy Tech, LLC. service department can also assist when needed VOID YOUR 1-866-384-2697 WARRANTY.

  • Page 15: First Use Of Matilda

    M A T I L D A O W N E R ’ S M A N U A L Chapter First Use of Matilda Before using this unit for the first time, wash out the inside of the sink with hot STOP! soapy water and rinse clean.

  • Page 16: Operating Matilda

    M A T I L D A O W N E R ’ S M A N U A L Chapter  Operating Matilda Be sure the Using Matilda is simple. We have redesigned the user interface on the machine to operate with only two buttons.

  • Page 17: Light Sequence

    M A T I L D A O W N E R ’ S M A N U A L Light Sequence During each process of the machine, the LED lights will indicate the current status through a light sequence on the button LED’s. 1.

  • Page 18: Using The Perfect Udder App

    ® ® The Perfect Udder app is your essential tool for managing Dairy Tech's machines with ease. This user-friendly app allows you to make setting adjustments, monitor machine performance, and streamline colostrum processing tasks from your phone. Simply scan the QR code to download it directly.

  • Page 19: App Overview

    App Over view Once you've downloaded and opened the app, you’ll be greeted by the information dashboard. This is where you can see all powered-on, compatible Dairy Tech equipment within range, providing an overview of each machine's status. What’s on the Dashboard? 1.

  • Page 20: Machine Information Screen

    M A T I L D A O W N E R ’ S M A N U A L Machine Information Screen When you select a machine from the dashboard, you’ll be taken to a detailed screen showing the following: 1.

  • Page 21: Program Selection

    M A T I L D A O W N E R ’ S M A N U A L Program Selection Matilda offers four different program options to cater to your specific needs. Tap on the program you wish to use, then tap Start. PASTEURIZE, FEED NOW: Colostrum is pasteurized then cooled to a predetermined FEEDING TEMPERATURE for immediate use.

  • Page 22: Test Mode

    Machine Histor y You can view the logs of all past cycles by selecting History from the bottom menu. The log helps diagnose errors or incomplete cycles. Dairy Tech technicians may request log files to better understand any issues you encounter.

  • Page 23: Adjusting Settings

    M A T I L D A O W N E R ’ S M A N U A L Adjusting Settings Access Settings from the machine information screen to modify the machine’s configuration. If it’s your first time, you’ll be prompted to set up a password. Settings Overview: Toggle: This allows you to pick between two options.

  • Page 24: Owner's Manual

    Forgot your password? No worries! If the password is lost or forgotten, the system has a default password that can be retrieved. Just contact your Dairy Tech Dealer or reach out to our Service Department at 1-866-384-2697 for assistance.

  • Page 25: Quality Control And System Monitoring

    M A T I L D A O W N E R ’ S M A N U A L Chapter Quality Control and System Monitoring The following recommendations should be carried out when the system is first installed and then on a monthly schedule to make certain that the pasteurization process is working adequately.
  • Page 26 M A T I L D A O W N E R ’ S M A N U A L 2. What if the colostrum becomes spoiled before I pasteurize it? This condition is common and can happen at times even when the same successful routines have been followed.

  • Page 27: Energy And Time Saving Tips

    M A T I L D A O W N E R ’ S M A N U A L Energy and Time Saving Tips 1. Matilda® can be turned off during non-busy times to conserve energy. 2. Pasteurize the colostrum as quickly as possible after collection. This will prevent the excessive growth of bacteria in the colostrum and take advantage of the heat to improve energy efficiency.

  • Page 28: Troubleshooting Matilda

    M A T I L D A O W N E R ’ S M A N U A L Chapter Troubleshooting Matilda This guide is intended for use as a troubleshooting S A F E T Y S Y M B O L S directive.

  • Page 29: Matilda Does Not Heat

    “Resistance” to check continuity across the switch. c. Open/Closed Status: If the switch is open, wait until the water jacket cools below 140°F for it to close. If the switch has failed open, contact Dairy Tech for a replacement part. Test the Relays 1.

  • Page 30: 240 Vac Is Getting To The Heating

    240 VAC is Getting to the Heating Elements, but Still No Heat 1. Check for continuity through the heating elements. If no continuity, replace the heating element. Order replacement part QE-Element2.5kW from Dairy Tech, LLC. a. HEATING ELEMENTS: The heating elements can be replaced when necessary.

  • Page 31: Matilda Does Not Get To Temperature, But The Element Is Hot Or Heats Slowly

    M A T I L D A O W N E R ’ S M A N U A L Matilda Does Not Get to Temperature, but the Element is Hot or Heats Slowly 1. Check the Heating Elements: There are two (2) or three (3) active heating elements in each unit depending on the model.

  • Page 32: Running

    M A T I L D A O W N E R ’ S M A N U A L Cooling Solenoid Valve Will Not Stop Running 1. Check the power supply to the valve. If there is power keeping it open during unwanted times, the control could be malfunctioning, especially if the Blue “Water”...

  • Page 33: Colostrum Is Separated Or Congealed

    M A T I L D A O W N E R ’ S M A N U A L Colostrum is Separated or Congealed The most common cause for colostrum to separate or congeal is acidification. Fermentation of the colostrum by bacteria will cause the release of lactic acid and other acidic by-products resulting in a lower pH.

  • Page 34: Error Symbols

    M A T I L D A O W N E R ’ S M A N U A L Error Symbols If a problem is detected, Matilda will display a RED symbol to help you determine what the issue could be. Tapping on the error number will give additional information about the error.
  • Page 35 M A T I L D A O W N E R ’ S M A N U A L The Sink Temperature Sensor • Check that the Sink Temperature Sensor is plugged into the Controller PCB. measurement • Try power cycling the machine and checking if the problem persists. was out of range.
  • Page 36 M A T I L D A O W N E R ’ S M A N U A L Element #1, #2, or #3 was using • Check that the voltage across indicated heating element does not exceed 250 VAC. more current •...

  • Page 37: Matilda Wiring Diagram

    M A T I L D A O W N E R ’ S M A N U A L Matilda Wiring Diagram...

  • Page 38: Matilda Wiring Options

    M A T I L D A O W N E R ’ S M A N U A L Matilda Wiring Options...

  • Page 39: Matilda Time And Temperature Defaults

    M A T I L D A O W N E R ’ S M A N U A L Matilda Time and Temperature Defaults Times and Temperatures Settings Name Default Feed Temp (°F/°C) 105/40.5 90/32.2 115/46.1 Feed Hold Time Cool Temp (°F/°C) 90/32.2 40/4.4...

  • Page 40: Replacement Parts

    M A T I L D A O W N E R ’ S M A N U A L Drain Stopper Replacement Par ts Replacement Drain Stopper. Mounts to bottom of Drain Operator This section lists the replacement parts and their Rod (Drain Operator part numbers.
  • Page 41 M A T I L D A O W N E R ’ S M A N U A L Propeller Assembly Complete propeller assembly for Matilda®. Includes: Propeller, Stir Shaft, Shaft Bearing Q-Assy-Prop- Part number: Igus Shaft Seal Rotary Shaft Oil Seal. 9x24x7.
