Sonance James SPL2 Installation Manual

INSTRUCTIONS
1. Carefully place the TV and James SPL Soundbar
face down on a soft surface with the soundbar
positioned flush with the bottom of the TV.
Figure 1: Lay TV and Soudbar flat on a Soft Surface
2. Attach bracket mount to the soundbar without
tightening the provided pinch tabs. Adjust the
bracket arms to ensure clearance of speaker
terminals.
Figure 2: Attach Bracket Mount
SPL2 AND SPL3 BRACKET MOUNT
INSTALLATION GUIDE
3. Loosen 10-32 Hex flathead screws on the VESA
bracket and extend to match the TV's VESA hole
pattern.
Figure 3: Loosen Screws
4. Install TV wall mount on top of the VESA bracket
using metric screws. (Use provided spacers if
necessary).
Figure 4: Install Mount on Bracket
