Sonance Mounting Plates SM-Series Instruction Manual

I N S T R U C T I O N M A N U A L
S M S E R I E S M O U N T I N G P L A T E

Introduction

Thank you for purchasing Sonance SM-Series Mounting Plates. This innovative mounting system eases installation by attaching
directly to a J-Box in the ceiling, eliminating the need to cut a mounting hole for the speaker.

Box Contents

I I t t e e m m
SM Mounting Plates
Plastic terminal covers
(attached to the Mounting Plates)
1½" x 6-32 flat-head screws

Before Installation

1. Determine the location for the speaker (refer to the speak-
er instruction manual for details).
2. The Mounting Plate installs onto a single or double J-box
that has already been mounted on the wall or ceiling.
• The Mounting Plate allows the speaker to be installed
after the wall or ceiling has been finished.

Installation

1. Run speaker wires through the wall, ceiling or conduit,
from the amplifier into the J-Box. Mark the wire's "+" and
"–" leads.
• Consult local building codes before running speaker
wires through walls or ceilings.
2. Bring the speaker wires through the J-Box and attach
them to the binding posts on the back of the Mounting
Plate. The SM55 Mounting Plates have two binding posts;
the SM55SST Mounting Plates have four binding posts
(see Figure 1 ). The binding posts will accept banana
plugs or bare wire.
B
F
IGURE
Q Q u u a a n n t t i i t t y y ( ( S S M M 5 5 5 5 P P l l a a t t e e ) )
A, C
A) Loosen Set Screw
B) Insert Wire
C) Tighten Set Screw
1: W M
IRING THE OUNTING
SM55 ( ); SM55SST (
LEFT RIGHT
Q Q u u a a n n t t i i t t y y ( ( S S M M 5 5 5 5 S S S S T T P P l l a a t t e e ) )
2
2
4
Be sure to connect amplifier "+" to the Mounting Plate's
"+" terminal, and amplifier "–" to the Mounting Plate's
"–" terminal.
• Loosen the set screw on the binding post, insert the plug
or wire, then tighten the set screw to secure the wire.
IMPORTANT: When using bare wire, be sure
that no stray "+" and "–" strands touch each
other. (Stray strands that touch each other can
cause a shor t-circuit that can damage the
amplifier.)
3. Use the included 1½" x 6-32 flat head screws to attach
the Mounting Plate to the J-Box. (See Figure 2 .)
• Use two screws for a single-gang J-Box; use four screws
for a double-gang J-Box.
4. The Mounting Plate is fitted with a paint plug that protects
the speaker terminals if the ceiling is painted after the
Plate is installed. Remove the paint plug before installing
the speaker.
5. To install the speaker, refer to the speaker's instruction
manual.
B
A, C
P
LATE
)
1
1
2
F 2: A
IGURE TTACHING THE
M P
OUNTING LATE TO THE
(SM55P S
LATE
J-
BOX
)
HOWN
