Page 3: Table Of Contents
Proline Promass S 300 HART Table of contents Table of contents About this document ....6 Mounting ......21 Document function .
Page 4 Table of contents Proline Promass S 300 HART Access to operating menu via web browser . . . 58 10.6 Simulation ......129 8.4.1...
Page 5 13.2 Measuring and test equipment ... 179 13.3 Endress+Hauser services ....179 Repair ......180 14.1 General notes .
Page 6: About This Document
About this document Proline Promass S 300 HART About this document Document function These Operating Instructions contain all the information required in the various life cycle phases of the device: from product identification, incoming acceptance and storage, to installation, connection, operation and commissioning, through to troubleshooting, maintenance and disposal.
Page 7: Tool Symbols
Proline Promass S 300 HART About this document 1.2.4 Tool symbols Symbol Meaning Flat-blade screwdriver Allen key Open-ended wrench 1.2.5 Symbols for certain types of information Symbol Meaning Permitted Procedures, processes or actions that are permitted. Preferred Procedures, processes or actions that are preferred.
Page 8: Documentation
• Device Viewer (www.endress.com/deviceviewer): Enter the serial number from the nameplate • Endress+Hauser Operations app: Enter serial number from nameplate or scan matrix code on nameplate. The following documentation may be available depending on the device version ordered: Document type...
Page 9: Safety Instructions
Proline Promass S 300 HART Safety instructions Safety instructions Requirements for the personnel The personnel for installation, commissioning, diagnostics and maintenance must fulfill the following requirements: ‣ Trained, qualified specialists must have a relevant qualification for this specific function and task.
Page 10: Workplace Safety
Verification for borderline cases: ‣ For special fluids and fluids for cleaning, Endress+Hauser is glad to provide assistance in verifying the corrosion resistance of fluid-wetted materials, but does not accept any warranty or liability as minute changes in the temperature, concentration or level of contamination in the process can alter the corrosion resistance properties.
Page 11: Device-Specific It Security
Proline Promass S 300 HART Safety instructions Device-specific IT security The device offers a range of specific functions to support protective measures on the operator' s side. These functions can be configured by the user and guarantee greater in- operation safety if used correctly. The following list provides an overview of the most...
Page 12: Infrastructure Mode
Safety instructions Proline Promass S 300 HART WLAN passphrase: Operation as WLAN access point A connection between an operating unit (e.g. notebook or tablet) and the device via the WLAN interface (→  67), which can be ordered as an optional extra, is protected by the network key.
Page 13 Proline Promass S 300 HART Safety instructions The use of relevant industrial standards and guidelines that have been defined by national and international safety committees, such as IEC/ISA62443 or the IEEE, is recommended. This includes organizational security measures such as the assignment of access authorization as well as technical measures such as network segmentation.
Page 14: Product Description
Product description Proline Promass S 300 HART Product description The device consists of a transmitter and a sensor. The device is available as a compact version: The transmitter and sensor form a mechanical unit. Product design N ic te r e rg ö...
Page 15: Identification
• Enter the serial numbers from the nameplates in the Device Viewer (www.endress.com/deviceviewer): all the information about the device is displayed. • Enter the serial numbers from the nameplates into the Endress+Hauser Operations app or scan the DataMatrix code on the nameplate with the Endress+Hauser Operations app: all the information about the device is displayed.
Page 16: Transmitter Nameplate
Incoming acceptance and product identification Proline Promass S 300 HART 4.2.1 Transmitter nameplate 3 4 5 Order code: Ser. no.: Ext. ord. cd.: Date: A0029192  2 Example of a transmitter nameplate Manufacturer address/certificate holder Name of the transmitter Order code...
Page 17: Sensor Nameplate
Proline Promass S 300 HART Incoming acceptance and product identification 4.2.2 Sensor nameplate Order code: Ser. no.: Ext. ord. cd.: Date: A0029199  3 Example of a sensor nameplate Name of the sensor Manufacturer address/certificate holder Order code Serial number (Ser. no.) Extended order code (Ext.
Page 18: Symbols On The Device
Incoming acceptance and product identification Proline Promass S 300 HART 4.2.3 Symbols on the device Symbol Meaning WARNING! This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in serious or fatal injury. Please consult the documentation for the measuring instrument to discover the type of potential danger and measures to avoid it.
Page 19: Storage And Transport
Proline Promass S 300 HART Storage and transport Storage and transport Storage conditions Observe the following notes for storage: ‣ Store in the original packaging to ensure protection from shock. ‣ Do not remove protective covers or protective caps installed on process connections.
Page 20: Measuring Devices With Lifting Lugs
Storage and transport Proline Promass S 300 HART 5.2.2 Measuring devices with lifting lugs CAUTION Special transportation instructions for devices with lifting lugs ‣ Only use the lifting lugs fitted on the device or flanges to transport the device. ‣...
Page 21: Mounting
Proline Promass S 300 HART Mounting Mounting Mounting requirements 6.1.1 Installation position Installation point A0028772 To prevent measuring errors arising from accumulation of gas bubbles in the measuring pipe, avoid the following mounting locations in the piping: • Highest point of a pipeline.
Page 22 Mounting Proline Promass S 300 HART Ø orifice plate, pipe restriction [mm] [in] [mm] [in] ³⁄₈ 0.24 ½ 0.40 0.55 1 ½ 0.87 1.10 Orientation The direction of the arrow on the sensor nameplate helps you to install the sensor according to the flow direction (direction of medium flow through the piping).
Page 23: Inlet And Outlet Runs
Proline Promass S 300 HART Mounting Inlet and outlet runs No special precautions need to be taken for fittings that create turbulence, such as valves, elbows or T-pieces, as long as no cavitation occurs →  23. A0029322 A0029323 Installation dimensions For the dimensions and installation lengths of the device, see the "Technical...
Page 24 Mounting Proline Promass S 300 HART Thermal insulation In the case of some fluids, it is important to keep the heat radiated from the sensor to the transmitter to a low level. A wide range of materials can be used for the required insulation.
Page 25: Special Installation Instructions
Proline Promass S 300 HART Mounting Heating options If a fluid requires that no heat loss should occur at the sensor, users can avail of the following heating options: • Electrical heating, e.g. with electric band heaters • Via pipes carrying hot water or steam •...
Page 26 Mounting Proline Promass S 300 HART [mm] [in] [mm] [in] [mm] [in] [mm] [in] 1 ½ 25.91 36.5 1.44 30.39 44.1 1.74 2.95 Zero verification and zero adjustment All measuring instruments are calibrated in accordance with state-of-the-art technology. Calibration takes place under reference conditions →  196. Therefore, a zero adjustment in the field is generally not required.
Page 27: Mounting The Measuring Instrument
Proline Promass S 300 HART Mounting Mounting the measuring instrument 6.2.1 Required tools For sensor For flanges and other process connections: Use a suitable mounting tool. 6.2.2 Preparing the measuring instrument 1. Remove all remaining transport packaging. 2. Remove any protective covers or protective caps present from the sensor.
Page 28: Turning The Display Module
Mounting Proline Promass S 300 HART – – 3 mm 4 mm 7 Nm (5.2 lbf ft) A0029993  8 Housing in non-Ex version 1. Depending on the device version: Loosen the securing clamp of the connection compartment cover. 2. Unscrew the connection compartment cover.
Page 29: Post-Installation Check
Proline Promass S 300 HART Mounting – – – 3 mm A0030035 1. Depending on the device version: Loosen the securing clamp of the connection compartment cover. 2. Unscrew the connection compartment cover. 3. Turn the display module to the desired position: max. 8 × 45° in each direction.
Page 30: Electrical Connection
Electrical connection Proline Promass S 300 HART Electrical connection WARNING Live parts! Incorrect work performed on the electrical connections can result in an electric shock. ‣ Set up a disconnecting device (switch or power-circuit breaker) to easily disconnect the device from the supply voltage.
Page 31: Endress+Hauser
Proline Promass S 300 HART Electrical connection Ethernet-APL Shielded twisted-pair cable. Cable type A is recommended. https://www.profibus.com Ethernet-APL White Paper " Current output 0 /4 to 20 mA (excluding HART) Standard installation cable is sufficient. Pulse /frequency /switch output Standard installation cable is sufficient.
Page 32 Electrical connection Proline Promass S 300 HART A standard cable with the following minimum requirements can be used as the connecting cable, even in the hazardous area (Zone 2, Class I, Division 2 and Zone 1, Class I, Division Standard cable 4 wires (2 pairs);...
Page 33: Terminal Assignment
Proline Promass S 300 HART Electrical connection 7.2.3 Terminal assignment Transmitter: supply voltage, input/outputs The terminal assignment of the inputs and outputs depends on the individual order version of the device. The device-specific terminal assignment is documented on an adhesive label in the terminal cover.
Page 34 Electrical connection Proline Promass S 300 HART – – – 3 mm A0029813 1. Loosen the securing clamp of the connection compartment cover. 2. Unscrew the connection compartment cover. 3. Squeeze the tabs of the display module holder together. 4. Remove the display module holder.
Page 35 Proline Promass S 300 HART Electrical connection 22 mm 24 mm – A0029816 10. Connect the cable according to the terminal assignment.  Signal cable terminal assignment: The device-specific terminal assignment is documented on an adhesive label in the terminal cover.
Page 36: Connecting The Remote Display And Operating Module Dkx001
Electrical connection Proline Promass S 300 HART 7.3.2 Connecting the remote display and operating module DKX001 The remote display and operating module DKX001 is available as an optional extra →  182.. • The remote display and operating module DKX001 is only available for the following housing version: order code for "Housing": option A "Aluminum, coated"...
Page 37: Special Connection Instructions
Proline Promass S 300 HART Electrical connection Special connection instructions 7.5.1 Connection examples Current output 4 to 20 mA HART 4...20 mA A0029055  11 Connection example for 4 to 20 mA HART current output (active) Automation system with current input (e.g. PLC) Ground cable shield at one end.
Page 38: Hart Input
Electrical connection Proline Promass S 300 HART HART input 4...20 mA A0028763  13 Connection example for HART input with a common negative (passive) Automation system with HART output (e.g. PLC) Active barrier for power supply (e.g. RN221N) Ground cable shield at one end. The cable shield must be grounded at both ends to comply with EMC requirements;...
Page 39: Pulse/Frequency Output
Proline Promass S 300 HART Electrical connection Pulse/frequency output 12345 A0028761  16 Connection example for pulse/frequency output (passive) Automation system with pulse/frequency input (e.g. PLC with 10 kΩ pull-up or pull-down resistor) Power supply Transmitter: observe input values →  190...
Page 40: Relay Output
Electrical connection Proline Promass S 300 HART A0029279  19 Connection example for double pulse output (passive) Automation system with double pulse input (e.g. PLC with a 10 kΩ pull-up or pull-down resistor) Power supply Transmitter: observe input values →  191...
Page 41: Status Input
Proline Promass S 300 HART Electrical connection Status input A0028764  22 Connection example for status input Automation system with status output (e.g. PLC) Power supply Transmitter Ensuring the degree of protection The measuring instrument fulfills all the requirements for the degree of protection IP66/67, Type 4X enclosure.
Page 42 Electrical connection Proline Promass S 300 HART If supply voltage is present:  Does an indication appear on the display module? Are dummy plugs inserted in unused cable entries and have transportation plugs been replaced  with dummy plugs? Endress+Hauser...
Page 43: Operation Options
Proline Promass S 300 HART Operation options Operation options Overview of operation options A0034513 Local operation via display module Computer with web browser or operating tool (e.g. FieldCare, DeviceCare, AMS Device Manager, SIMATIC PDM) Field Xpert SFX350 or SFX370 Field Xpert SMT70 Mobile handheld terminal Automation system (e.g.
Page 44: Structure And Function Of The Operating Menu
Operation options Proline Promass S 300 HART Structure and function of the operating menu 8.2.1 Structure of the operating menu For an overview of the operating menu for experts: see the "Description of Device Parameters" document supplied with the device...
Page 45: Operating Philosophy
Proline Promass S 300 HART Operation options 8.2.2 Operating philosophy The individual parts of the operating menu are assigned to certain user roles (e.g. operator, maintenance etc.). Each user role contains typical tasks within the device life cycle. Menu/parameter User role and tasks...
Page 46: Access To Operating Menu Via Local Display
Operation options Proline Promass S 300 HART Menu/parameter User role and tasks Content/meaning Expert Function- Tasks that require detailed knowledge of Contains all of the device parameters and allows direct access to these by oriented the function of the device: means of an access code.
Page 47: Display Area
Proline Promass S 300 HART Operation options Display area In the display area, each measured value is prefaced by certain symbol types for further description: Measured variable Measurement channel Diagnostic behavior number ↓ ↓ ↓ Example Appears only if a diagnostics event is present for this measured variable.
Page 48 Operation options Proline Promass S 300 HART Diagnostic behavior Symbol Meaning Alarm • Measurement is interrupted. • Signal outputs and totalizers assume the defined alarm condition. • A diagnostic message is generated. Warning • Measurement is resumed. • The signal outputs and totalizers are not affected.
Page 49: Navigation View
Proline Promass S 300 HART Operation options 8.3.2 Navigation view In the submenu In the wizard /../Operation 0091-1 /../Select medium Access stat.disp Select medium Operator Liquid Locking status Display A0013993-EN A0013995-EN Navigation view Navigation path to current position Status area Display area for navigation Operating elements →...
Page 50: Locking Procedure
Operation options Proline Promass S 300 HART Setup Is displayed: • In the menu next to the "Setup" selection • At the left in the navigation path in the Setup menu Diagnosis Is displayed: • In the menu next to the "Diagnostics" selection •...
Page 51: Editing View
Proline Promass S 300 HART Operation options 8.3.3 Editing view Numeric editor +0.000 Xx – A0034250  24 For entering values in parameters (e.g. limit values) Entry display area Input screen Confirm, delete or reject entry Operating elements Text editor...
Page 52 Operation options Proline Promass S 300 HART Operating key Meaning Enter key • Pressing the key briefly confirms your selection. • Pressing the key for 2 s confirms your entry. Escape key combination (press keys simultaneously) Close the editing view without accepting a change.
Page 53: Operating Elements
Proline Promass S 300 HART Operation options 8.3.4 Operating elements Operating key Meaning Minus key In menu, submenu Moves the selection bar upwards in a picklist In wizards Goes to previous parameter In the text and numeric editor Move the entry position to the left.
Page 54 Operation options Proline Promass S 300 HART Calling up and closing the context menu The user is in the operational display. 1. Press the  and  keys for longer than 3 seconds.  The context menu opens. XXXXXXXXXX Setup Conf.backup...
Page 55: Navigating And Selecting From List
Proline Promass S 300 HART Operation options 8.3.6 Navigating and selecting from list Different operating elements are used to navigate through the operating menu. The navigation path is displayed on the left in the header. Icons are displayed in front of the individual menus.
Page 56: Calling Up Help Text
Operation options Proline Promass S 300 HART The direct access code consists of a 5-digit number (at maximum) and the channel number, which identifies the channel of a process variable: e.g. 00914-2. In the navigation view, this appears on the right-hand side in the header of the selected parameter.
Page 57: User Roles And Related Access Authorization
Proline Promass S 300 HART Operation options Ent. access code Invalid or out of range input value Min:0 Max:9999 A0014049-EN For a description of the editing view - consisting of the text editor and numeric editor - with symbols →  51, for a description of the operating elements →  53 8.3.10...
Page 58: Enabling And Disabling The Keypad Lock
Operation options Proline Promass S 300 HART 2. Enter the access code.  The -symbol in front of the parameters disappears; all previously write- protected parameters are now re-enabled. 8.3.12 Enabling and disabling the keypad lock The keypad lock makes it possible to block access to the entire operating menu via local operation.
Page 59: Requirements
Proline Promass S 300 HART Operation options 8.4.2 Requirements Computer hardware Hardware Interface CDI-RJ45 WLAN Interface The computer must have a RJ45 The operating unit must have a WLAN interface. interface. Connection Standard Ethernet cable Connection via Wireless LAN. Screen Recommended size: ≥12"...
Page 60: Connecting The Device
Operation options Proline Promass S 300 HART Measuring device: Via CDI-RJ45 service interface Device CDI-RJ45 service interface Measuring device The measuring device has an RJ45 interface. Web server Web server must be enabled; factory setting: ON  For information on enabling the Web server →  64...
Page 61 Proline Promass S 300 HART Operation options NOTICE Note the following to avoid a network conflict: ‣ Avoid accessing the measuring device simultaneously from the same mobile terminal via the service interface (CDI-RJ45) and the WLAN interface. ‣ Only activate one service interface (CDI-RJ45 or WLAN interface).
Page 62: Logging On
Operation options Proline Promass S 300 HART 2. Enter the IP address of the web server in the address line of the web browser: 192.168.1.212  The login page appears. 2 3 4 Device name: Device tag: Signal Status: Web server language...
Page 63: User Interface
Proline Promass S 300 HART Operation options 8.4.5 User interface A0029418 Function row Local display language Navigation area Header The following information appears in the header: • Device name • Device tag • Device status with status signal →  158 •...
Page 64: Disabling The Web Server
Operation options Proline Promass S 300 HART Working area Depending on the selected function and the related submenus, various actions can be performed in this area: • Configuring parameters • Reading measured values • Calling up help text • Starting an upload/download 8.4.6...
Page 65: Access To The Operating Menu Via The Operating Tool
Proline Promass S 300 HART Operation options Access to the operating menu via the operating tool The structure of the operating menu in the operating tools is the same as for operation via the local display. 8.5.1 Connecting the operating tool Via HART protocol This communication interface is available in device versions with a HART output.
Page 66: Service Interface
Operation options Proline Promass S 300 HART A0028746  28 Options for remote operation via HART protocol (passive) Control system (e.g. PLC) Transmitter power supply unit, e.g. RN221N (with communication resistor) Connection for Commubox FXA195 and Field Communicator 475 Field Communicator 475 Computer with web browser (e.g.
Page 67 Proline Promass S 300 HART Operation options Via WLAN interface The optional WLAN interface is available on the following device version: Order code for "Display; operation", option G "4-line, illuminated; touch control + WLAN" A0034570 Transmitter with integrated WLAN antenna...
Page 68: Field Xpert Sfx350, Sfx370
FieldCare Function range FDT-based (Field Device Technology) plant asset management tool from Endress+Hauser. It can configure all smart field units in a system and helps you manage them. By using the status information, it is also a simple but effective way of checking their status and condition.
Page 69 Proline Promass S 300 HART Operation options Access is via: • HART protocol →  65 • CDI-RJ45 service interface →  66 • WLAN interface →  67 Typical functions: • Transmitter parameter configuration • Loading and saving of device data (upload/download) •...
Page 70: Devicecare
DeviceCare Function range Tool for connecting and configuring Endress+Hauser field devices. The fastest way to configure Endress+Hauser field devices is with the dedicated "DeviceCare" tool. Together with the device type managers (DTMs) it presents a convenient, comprehensive solution. Innovation brochure IN01047S Source for device description files →...
Page 71: Field Communicator 475
Proline Promass S 300 HART Operation options 8.5.6 Field Communicator 475 Function scope Industrial handheld terminal from Emerson Process Management for remote configuration and measured value display via HART protocol. Source for device description files See information →  72 8.5.7...
Page 72: System Integration
System integration Proline Promass S 300 HART System integration Overview of device description files 9.1.1 Current version data for the device Firmware version 01.06.zz • On the title page of the manual • On the transmitter nameplate • Firmware version Diagnostics →...
Page 73: Measured Variables Via Hart Protocol
Proline Promass S 300 HART System integration Measured variables via HART protocol The following measured variables (HART device variables) are assigned to the dynamic variables at the factory: Dynamic variables Measured variables (HART device variables) Primary dynamic variable (PV) Mass flow...
Page 74 System integration Proline Promass S 300 HART Measured variables for PV (primary dynamic variable) • Measured variables which are generally available: • Mass flow • Volume flow • Corrected volume flow • Density • Reference density • Temperature • Electronics temperature •...
Page 75: Device Variables
Proline Promass S 300 HART System integration Measured variables for SV, TV, QV (secondary, tertiary and quaternary dynamic variable) • Measured variables which are always available: • Mass flow • Volume flow • Corrected volume flow • Density • Reference density •...
Page 76: Other Settings
System integration Proline Promass S 300 HART Other settings Burst mode functionality in accordance with HART 7 Specification: Navigation "Expert" menu → Communication → HART output → Burst configuration → Burst configuration 1 to n ‣ Burst configuration 1 to n Burst mode 1 to n →...
Page 77 Proline Promass S 300 HART System integration Parameter Description Selection / User entry Factory setting Burst variable 0 For HART command 9 and 33: select the • Mass flow Volume flow HART device variable or the process variable. • Volume flow • Corrected volume flow •...
Page 78 System integration Proline Promass S 300 HART Parameter Description Selection / User entry Factory setting Min. update period Enter the minimum time span between two Positive integer 1 000 ms burst commands of burst message X. Max. update period Enter the maximum time span between two...
Page 79: Commissioning
Proline Promass S 300 HART Commissioning Commissioning 10.1 Post-mounting and post-connection check Before commissioning the device: ‣ Make sure that the post-installation and post-connection checks have been performed successfully. • Checklist for "Post-installation" check→  29 • Checklist for "Post-connection" check→  41 10.2...
Page 80 Commissioning Proline Promass S 300 HART X X X X X X X 20.50 Main menu Display language English Display/operat. Setup Main menu Display/operat. Setup Diagnostic / ../Setup Medium selection XXXXXXXXX XXXXXXXXX A0032222-EN  31 Navigation to "Setup" menu using the example of the local display The number of submenus and parameters can vary depending on the device version.
Page 81: Defining The Tag Name
Proline Promass S 300 HART Commissioning ‣ Partially filled pipe detection →  108 ‣ Advanced setup →  109 10.4.1 Defining the tag name To enable fast identification of the measuring point within the system, you can enter a unique designation using the Device tag parameter and thus change the factory setting.
Page 82 Commissioning Proline Promass S 300 HART Corrected volume flow unit →  82 Corrected volume unit →  82 →  82 Density unit Reference density unit →  82 Density 2 unit →  83 Temperature unit →  83 →...
Page 83 Proline Promass S 300 HART Commissioning Parameter Description Selection Factory setting Density 2 unit Select second density unit. Unit choose list Country-specific: • kg/l • lb/ft³ Temperature unit Select temperature unit. Unit choose list Country-specific: • °C Effect • °F The selected unit applies to: •...
Page 84: Selecting And Setting The Medium
Commissioning Proline Promass S 300 HART 10.4.3 Selecting and setting the medium The Select medium wizard submenu contains parameters that must be configured in order to select and set the medium. Navigation "Setup" menu → Medium selection ‣ Medium selection...
Page 85: Displaying The I/O Configuration
Proline Promass S 300 HART Commissioning Parameter Prerequisite Description Selection / User Factory setting entry / User interface Pressure value In the Pressure compensation Enter process pressure to be Positive floating- 1.01325 bar parameter, the Fixed value used for pressure correction. point number option is selected.
Page 86: Configuring The Current Input
Commissioning Proline Promass S 300 HART Parameter Description User interface / Selection / Factory setting User entry Apply I/O configuration Apply parameterization of the freely • No configurable I/O module. • Yes I/O alteration code Enter the code in order to change the I/O Positive integer configuration.
Page 87: Configuring The Status Input
Proline Promass S 300 HART Commissioning Parameter Prerequisite Description User interface / Factory setting Selection / User entry Current span – Select current range for • 4...20 mA (4... Country-specific: process value output and 20.5 mA) • 4...20 mA NE upper/lower level for alarm •...
Page 88: Configuring The Current Output
Commissioning Proline Promass S 300 HART Parameter overview with brief description Parameter Description Selection / User interface / Factory setting User entry Assign status input Select function for the status input. • Off • Reset totalizer 1 • Reset totalizer 2 • Reset totalizer 3 •...
Page 89 Proline Promass S 300 HART Commissioning Parameter overview with brief description Parameter Prerequisite Description User interface / Factory setting Selection / User entry Terminal number – Shows the terminal numbers • Not used – used by the current output • 26-27 (I/O 1) module.
Page 90 Commissioning Proline Promass S 300 HART Parameter Prerequisite Description User interface / Factory setting Selection / User entry Process variable current output – Select the process variable for • Off Mass flow the current output. • Mass flow • Volume flow • Corrected volume flow •...
Page 91 Proline Promass S 300 HART Commissioning Parameter Prerequisite Description User interface / Factory setting Selection / User entry Current range output – Select current range for • 4...20 mA NE Depends on country: process value output and (3.8...20.5 mA) • 4...20 mA NE upper/lower level for alarm •...
Page 92: Configuring The Pulse/Frequency
Commissioning Proline Promass S 300 HART 10.4.8 Configuring the pulse/frequency/switch output The Pulse/frequency/switch output wizard guides you systematically through all the parameters that can be set for configuring the selected output type. Navigation "Setup" menu → Advanced setup → Pulse/frequency/switch output ‣...
Page 93 Proline Promass S 300 HART Commissioning Parameter overview with brief description Parameter Prerequisite Description Selection / User Factory setting interface / User entry Operating mode – Define the output as a pulse, • Pulse Pulse frequency or switch output. • Frequency • Switch Terminal number –...
Page 94 Commissioning Proline Promass S 300 HART Configuring the frequency output Navigation "Setup" menu → Pulse/frequency/switch output ‣ Pulse/frequency/switch output 1 to n Operating mode →  94 Terminal number →  94 Signal mode →  94 Assign frequency output →...
Page 95 Proline Promass S 300 HART Commissioning Parameter Prerequisite Description Selection / User Factory setting interface / User entry Assign frequency output The Frequency option is Select process variable for • Off selected in Operating mode frequency output. • Mass flow parameter (→  92).
Page 96 Commissioning Proline Promass S 300 HART Parameter Prerequisite Description Selection / User Factory setting interface / User entry Maximum frequency value The Frequency option is Enter maximum frequency. 0.0 to 10 000.0 Hz 10 000.0 Hz selected in the Operating mode parameter (→  92)
Page 97 Proline Promass S 300 HART Commissioning Configuring the switch output Navigation "Setup" menu → Pulse/frequency/switch output ‣ Pulse/frequency/switch output 1 to n Operating mode →  97 Terminal number →  97 Signal mode →  97 Switch output function →...
Page 98 Commissioning Proline Promass S 300 HART Parameter Prerequisite Description Selection / User Factory setting interface / User entry Switch output function The Switch option is selected Select function for switch • Off in the Operating mode output. • On parameter. • Diagnostic behavior • Limit •...
Page 99: Configuring The Relay Output
Proline Promass S 300 HART Commissioning Parameter Prerequisite Description Selection / User Factory setting interface / User entry Switch-on value • The Switch option is Enter measured value for the Signed floating-point Depends on country: selected in the Operating switch-on point. number • 0 kg/h mode parameter.
Page 100 Commissioning Proline Promass S 300 HART Switch-off value →  101 Switch-off delay →  101 →  101 Switch-on value Switch-on delay →  101 Failure mode →  101 Switch state →  101 →  101 Powerless relay status...
Page 101 Proline Promass S 300 HART Commissioning Parameter Prerequisite Description User interface / Factory setting Selection / User entry Assign limit The Limit option is selected in Select process variable for limit • Mass flow Mass flow Relay output function function. • Volume flow parameter.
Page 102: 10.4.10 Configuring The Double Pulse Output
Commissioning Proline Promass S 300 HART 10.4.10 Configuring the double pulse output The Double pulse output submenu guides the user systematically through all the parameters that have to be set for configuring the double pulse output. Navigation "Setup" menu → Double pulse output ‣...
Page 103: 10.4.11 Configuring The Local Display
Proline Promass S 300 HART Commissioning Parameter Description Selection / User interface / Factory setting User entry Failure mode Define output behavior in alarm condition. • Actual value No pulses • No pulses Invert output signal Invert the output signal. • No • Yes Visibility depends on order options or device settings 10.4.11 Configuring the local display...
Page 104 Commissioning Proline Promass S 300 HART Parameter overview with brief description Parameter Prerequisite Description Selection / User Factory setting entry Format display A local display is provided. Select how measured values • 1 value, max. size 1 value, max. size are shown on the display.
Page 105 Proline Promass S 300 HART Commissioning Parameter Prerequisite Description Selection / User Factory setting entry Value 1 display A local display is provided. Select the measured value that • Mass flow Mass flow is shown on the local display. • Volume flow •...
Page 106 Commissioning Proline Promass S 300 HART Parameter Prerequisite Description Selection / User Factory setting entry Value 2 display A local display is provided. Select the measured value that For the picklist, see None is shown on the local display. Value 1 display parameter (→...
Page 107: 10.4.12 Configuring The Low Flow Cut Off
Proline Promass S 300 HART Commissioning 10.4.12 Configuring the low flow cut off The Low flow cut off wizard systematically guides the user through all the parameters that must be set to configure low flow cut off. Navigation "Setup" menu → Low flow cut off ‣...
Page 108: 10.4.13 Configuring Partially Filled Pipe Detection
Commissioning Proline Promass S 300 HART 10.4.13 Configuring partially filled pipe detection The Partial filled pipe detection wizard guides you systematically through all parameters that have to be set for configuring the monitoring of the pipe filling. Navigation "Setup" menu → Partially filled pipe detection ‣...
Page 109: Advanced Settings
Proline Promass S 300 HART Commissioning 10.5 Advanced settings The Advanced setup submenu with its submenus contains parameters for specific settings. Navigation to the "Advanced setup" submenu X X X X X X X 20.50 0104-1 Main menu Display language English Display/operat.
Page 110: Using The Parameter To Enter The Access Code
Commissioning Proline Promass S 300 HART ‣ Sensor adjustment →  111 ‣ Totalizer 1 to n →  117 ‣ →  119 Display ‣ WLAN settings →  125 ‣ Configuration backup →  127 ‣ Administration →  128 10.5.1...
Page 111: Carrying Out A Sensor Adjustment
Proline Promass S 300 HART Commissioning Reference temperature (1816) →  111 Linear expansion coefficient (1817) →  111 →  111 Square expansion coefficient (1818) Parameter overview with brief description Parameter Prerequisite Description Selection / User Factory setting interface / User entry Select reference density –...
Page 112: Density Adjustment
Commissioning Proline Promass S 300 HART Navigation "Setup" menu → Advanced setup → Sensor adjustment ‣ Sensor adjustment Installation direction →  112 ‣ Density adjustment ‣ →  115 Zero verification ‣ Zero adjustment →  116 Parameter overview with brief description...
Page 113 Proline Promass S 300 HART Commissioning 3. Select the Measure density 1 option and confirm. 4. If 100% was reached in the Progress parameter on the display and the Ok option is displayed in the Execute density adjustment parameter, then confirm.
Page 114 Commissioning Proline Promass S 300 HART Density setpoint 2 →  114 Execute density adjustment →  114 →  114 Progress Density adjustment factor →  114 Density adjustment offset →  114 Parameter overview with brief description Parameter...
Page 115 Proline Promass S 300 HART Commissioning Experience shows that zero adjustment is advisable only in special cases: • To achieve maximum measurement accuracy even with low flow rates. • Under extreme process or operating conditions (e.g. very high process temperatures or very high-viscosity fluids).
Page 116 Commissioning Proline Promass S 300 HART Parameter overview with brief description Parameter Description Selection / User interface Factory setting Process conditions Ensure process conditions as follows. • Tubes are completely filled – • Process operational pressure applied • No-flow conditions (closed valves) •...
Page 117: Configuring The Totalizer
Proline Promass S 300 HART Commissioning Root cause →  117 Reliability of measured zero point →  117 →  117 Additional information Reliability of measured zero point →  117 Zero point measured →  117 Zero point standard deviation →...
Page 118 Commissioning Proline Promass S 300 HART Navigation "Setup" menu → Advanced setup → Totalizer 1 to n ‣ Totalizer 1 to n Assign process variable →  118 Unit totalizer 1 to n →  118 →  118 Totalizer operation mode Failure mode →...
Page 119: Carrying Out Additional Display Configurations
Proline Promass S 300 HART Commissioning 10.5.5 Carrying out additional display configurations In the Display submenu you can set all the parameters associated with the configuration of the local display. Navigation "Setup" menu → Advanced setup → Display ‣ Display Format display →...
Page 120 Commissioning Proline Promass S 300 HART 0% bargraph value 7 →  124 100% bargraph value 7 →  124 →  124 Decimal places 7 Value 8 display →  124 Decimal places 8 →  124 Display language →...
Page 121 Proline Promass S 300 HART Commissioning Parameter overview with brief description Parameter Prerequisite Description Selection / User Factory setting entry Format display A local display is provided. Select how measured values • 1 value, max. size 1 value, max. size are shown on the display.
Page 122 Commissioning Proline Promass S 300 HART Parameter Prerequisite Description Selection / User Factory setting entry Value 1 display A local display is provided. Select the measured value that • Mass flow Mass flow is shown on the local display. • Volume flow •...
Page 123 Proline Promass S 300 HART Commissioning Parameter Prerequisite Description Selection / User Factory setting entry Decimal places 1 A measured value is specified Select the number of decimal • x x.xx in the Value 1 display places for the display value. • x.x parameter.
Page 124 Commissioning Proline Promass S 300 HART Parameter Prerequisite Description Selection / User Factory setting entry Decimal places 5 A measured value is specified Select the number of decimal • x x.xx in the Value 5 display places for the display value. • x.x parameter.
Page 125: Wlan Configuration
Proline Promass S 300 HART Commissioning Parameter Prerequisite Description Selection / User Factory setting entry Display language A local display is provided. Set display language. • English English • Deutsch (alternatively, the • Français ordered language is • Español preset in the device) •...
Page 126 Commissioning Proline Promass S 300 HART Navigation "Setup" menu → Advanced setup → WLAN settings ‣ WLAN settings WLAN IP address →  126 Security type →  126 →  126 WLAN passphrase Assign SSID name →  126 SSID name →...
Page 127: Configuration Management
Proline Promass S 300 HART Commissioning 10.5.7 Configuration management After commissioning, you can save the current device configurationor restore the previous device configuration. The device configuration is managed via the Configuration management parameter. Navigation "Setup" menu → Advanced setup → Configuration backup ‣...
Page 128: Function Scope Of The "Configuration Management" Parameter
Commissioning Proline Promass S 300 HART Function scope of the "Configuration management" parameter Options Description Cancel No action is executed and the user exits the parameter. Execute backup A backup copy of the current device configuration is saved from the HistoROM backup to the memory of the device.
Page 129: Simulation
Proline Promass S 300 HART Commissioning Parameter overview with brief description Parameter Description User entry Define access code Restrict write-access to parameters to protect the configuration Max. 16-digit character string comprising of the device against unintentional changes. numbers, letters and special characters Confirm access code Confirm the entered access code.
Page 130 Commissioning Proline Promass S 300 HART or closed-control loops). The simulation can be performed without a real measurement (no flow of medium through the device). Navigation "Diagnostics" menu → Simulation ‣ Simulation Assign simulation process variable →  131 Process variable value →...
Page 131 Proline Promass S 300 HART Commissioning Parameter overview with brief description Parameter Prerequisite Description Selection / User Factory setting entry Assign simulation process variable – Select a process variable for • Off the simulation process that is • Mass flow activated. • Volume flow •...
Page 132: Protecting Settings From Unauthorized Access
Commissioning Proline Promass S 300 HART Parameter Prerequisite Description Selection / User Factory setting entry Pulse output simulation – Set and switch off the pulse • Off output simulation. • Fixed value • Down-counting  For Fixed value option: value Pulse width parameter defines the pulse width of the pulses output.
Page 133 Proline Promass S 300 HART Commissioning 2. Maximum of 16-digit character string comprising numbers, letters and special characters as the access code. 3. Enter the access code again in the Confirm access code parameter (→  129) to confirm.  The  symbol appears in front of all write-protected parameters.
Page 134: Write Protection Via Write Protection Switch
Proline Promass S 300 HART Via Web browser, FieldCare, DeviceCare (via CDI-RJ45 service interface), fieldbus You can only obtain a reset code from your local Endress+Hauser service organization. The code must be calculated explicitly for every device. 1. Note down the serial number of the device.
Page 135 Proline Promass S 300 HART Commissioning 2. Setting the write protection (WP) switch on the main electronics module to the OFF position (factory setting) disables hardware write protection.  No option is displayed in the Locking status parameter →  136. On the local display, the ...
Page 136: Operation
Operation Proline Promass S 300 HART Operation 11.1 Reading off the device locking status Device active write protection: Locking status parameter Operation → Locking status Function scope of the "Locking status" parameter Options Description None The access authorization displayed in the Access status parameter applies →...
Page 137: Measured Variables" Submenu
Proline Promass S 300 HART Operation 11.4.1 "Measured variables" submenu The Measured variables submenu contains all the parameters needed to display the current measured values for each process variable. Navigation "Diagnostics" menu → Measured values → Measured variables ‣ Measured variables Mass flow →...
Page 138 Operation Proline Promass S 300 HART Parameter Prerequisite Description User interface Corrected volume flow – Displays the corrected volume flow that Signed floating-point is currently calculated. number Dependency The unit is taken from: Corrected volume flow unit parameter (→  82) Density –...
Page 139: Totalizer" Submenu
Proline Promass S 300 HART Operation Parameter Prerequisite Description User interface Carrier corrected volume flow With the following conditions: Displays the corrected volume flow Signed floating-point • Order code for "Application package", currently measured for the carrier fluid. number option ED "Concentration"...
Page 140: Input Values" Submenu
Operation Proline Promass S 300 HART Parameter overview with brief description Parameter Prerequisite Description User interface Totalizer value 1 to n A process variable is selected in the Displays the current totalizer counter Signed floating-point Assign process variable parameter value.
Page 141: Output Values
Proline Promass S 300 HART Operation Navigation "Diagnostics" menu → Measured values → Input values → Status input 1 to n ‣ Status input 1 to n Value status input →  141 Parameter overview with brief description Parameter Description...
Page 142 Operation Proline Promass S 300 HART Parameter overview with brief description Parameter Description User interface Output current Displays the current value currently calculated for the current 3.59 to 22.5 mA output. Measured current Displays the current value currently measured for the current 0 to 30 mA output.
Page 143: Adapting The Measuring Device To The Process Conditions
Proline Promass S 300 HART Operation Parameter overview with brief description Parameter Description User interface Switch state Shows the current relay switch status. • Open • Closed Switch cycles Shows number of all performed switch cycles. Positive integer Max. switch cycles number Shows the maximal number of guaranteed switch cycles.
Page 144: Function Scope Of "Control Totalizer" Parameter
Operation Proline Promass S 300 HART Totalizer value 1 to n →  144 Reset all totalizers →  144 Parameter overview with brief description Parameter Prerequisite Description Selection / User Factory setting entry / User interface Control Totalizer 1 to n A process variable is selected Control totalizer value.
Page 145: Displaying The Measured Value History
Proline Promass S 300 HART Operation 11.7 Displaying the measured value history The Extended HistoROM application package must be enabled in the device (order option) for the Data logging submenu to appear. This contains all the parameters for the measured value history.
Page 146 Operation Proline Promass S 300 HART Data logging status →  148 Entire logging duration →  148 ‣ Display channel 1 ‣ Display channel 2 ‣ Display channel 3 ‣ Display channel 4 Endress+Hauser...
Page 147 Proline Promass S 300 HART Operation Parameter overview with brief description Parameter Prerequisite Description Selection / User Factory setting entry / User interface Assign channel 1 The Extended HistoROM Assign process variable to • Off application package is logging channel. • Mass flow available.
Page 148: Gas Fraction Handler
Operation Proline Promass S 300 HART Parameter Prerequisite Description Selection / User Factory setting entry / User interface Assign channel 2 The Extended HistoROM Assign a process variable to For the picklist, see application package is logging channel. Assign channel 1 available. parameter (→  147) ...
Page 149: Measurement Mode" Submenu
Proline Promass S 300 HART Operation In the case of two-phase media, the Gas Fraction Handler stabilizes the output values and enables better readability for operators and easier interpretation by the distributed control system. The level of smoothing is adjusted according to the severity of the disturbances introduced by the second phase.
Page 150 Operation Proline Promass S 300 HART Parameter overview with brief description Parameter Prerequisite Description User interface / User Factory setting entry Inhomogeneous medium index – Shows the degree of Signed floating-point – inhomogeneity of the medium. number Cut off inhomogeneous wet gas –...
Page 151: Diagnostics And Troubleshooting
Proline Promass S 300 HART Diagnostics and troubleshooting Diagnostics and troubleshooting 12.1 General troubleshooting For local display Error Possible causes Remedial action Local display is dark, but signal output is within The cable of the display module is not plugged in...
Page 152 Diagnostics and troubleshooting Proline Promass S 300 HART For access Fault Possible causes Remedial action Write access to parameters is not possible. Hardware write protection is enabled. Set the write protection switch on the main electronics module to the OFF position →...
Page 153 Proline Promass S 300 HART Diagnostics and troubleshooting Fault Possible causes Remedial action Operation with FieldCare or DeviceCare via Firewall of the PC or network is blocking Depending on the settings of the firewall used service interface CDI-RJ45 (port 8000) is not communication.
Page 154: Diagnostic Information Via Light Emitting Diodes
Diagnostics and troubleshooting Proline Promass S 300 HART 12.2 Diagnostic information via light emitting diodes 12.2.1 Transmitter Different LEDs in the transmitter provide information on the device status. 1 2 3 4 5 A0029629 Supply voltage Device status Not used...
Page 155: Diagnostic Information On Local Display
Proline Promass S 300 HART Diagnostics and troubleshooting 12.3 Diagnostic information on local display 12.3.1 Diagnostic message Faults detected by the self-monitoring system of the measuring device are displayed as a diagnostic message in alternation with the operational display. Operational display in alarm condition...
Page 156: Diagnostic Information
Diagnostics and troubleshooting Proline Promass S 300 HART Diagnostic behavior Symbol Meaning Alarm • Measurement is interrupted. • Signal outputs and totalizers assume the defined alarm condition. • A diagnostic message is generated. Warning • Measurement is resumed. • The signal outputs and totalizers are not affected.
Page 157: Calling Up Remedial Measures
Proline Promass S 300 HART Diagnostics and troubleshooting 12.3.2 Calling up remedial measures X X X X X X X X X X X X X X 20.50 S801 Supply voltage Menu Diagnostic list Diagnostics 1 S801 Supply voltage Diagnostics 2...
Page 158: Diagnostic Information In The Web Browser
Diagnostics and troubleshooting Proline Promass S 300 HART 12.4 Diagnostic information in the web browser 12.4.1 Diagnostic options Any faults detected by the measuring device are displayed in the Web browser on the home page once the user has logged on.
Page 159: Calling Up Remedy Information
Proline Promass S 300 HART Diagnostics and troubleshooting 12.4.2 Calling up remedy information Remedy information is provided for every diagnostic event to ensure that problems can be rectified quickly. These measures are displayed in red along with the diagnostic event and the related diagnostic information.
Page 160: Diagnostic Information In Fieldcare Or
Diagnostics and troubleshooting Proline Promass S 300 HART 12.5 Diagnostic information in FieldCare or DeviceCare 12.5.1 Diagnostic options Any faults detected by the measuring device are displayed on the home page of the operating tool once the connection has been established.
Page 161: Calling Up Remedy Information
Proline Promass S 300 HART Diagnostics and troubleshooting 12.5.2 Calling up remedy information Remedy information is provided for every diagnostic event to ensure that problems can be rectified quickly: • On the home page Remedy information is displayed in a separate field below the diagnostics information.
Page 162: Adapting The Diagnostic Information
Diagnostics and troubleshooting Proline Promass S 300 HART 12.6 Adapting the diagnostic information 12.6.1 Adapting the diagnostic behavior Each item of diagnostic information is assigned a specific diagnostic behavior at the factory. The user can change this assignment for specific diagnostic information in the Diagnostic behavior submenu.
Page 163 Proline Promass S 300 HART Diagnostics and troubleshooting Symbol Meaning Maintenance required Maintenance is required. The measured value remains valid. A0013957 Has no effect on the condensed status. A0023076 Endress+Hauser...
Page 164: Overview Of Diagnostic Information
Diagnostics and troubleshooting Proline Promass S 300 HART 12.7 Overview of diagnostic information The amount of diagnostic information and the number of measured variables affected increase if the measuring device has one or more application packages. In the case of some items of diagnostic information, the status signal and the diagnostic behavior can be changed.
Page 165 Proline Promass S 300 HART Diagnostics and troubleshooting Diagnostic Short text Remedy instructions Status Diagnostic number signal behavior [from the [from the factory] factory] Module incompatible 1. Check electronic modules Alarm 2. Check if correct modules are available (e.g. NEx, Ex) 3.
Page 166 Diagnostics and troubleshooting Proline Promass S 300 HART Diagnostic Short text Remedy instructions Status Diagnostic number signal behavior [from the [from the factory] factory] Sensor electronics 1. Restart device Warning (ISEM) faulty 2. Check if failure recurs 3. Replace sensor electronic module...
Page 167 Proline Promass S 300 HART Diagnostics and troubleshooting Diagnostic Short text Remedy instructions Status Diagnostic number signal behavior [from the [from the factory] factory] Diagnostic event Deactivate simulation Warning simulation active Status input simulation Deactivate simulation status input Warning active...
Page 168 Diagnostics and troubleshooting Proline Promass S 300 HART Diagnostic Short text Remedy instructions Status Diagnostic number signal behavior [from the [from the factory] factory] Process value below 1. Decrease process value Warning limit 2. Check application 3. Check sensor Partly filled pipe 1.
Page 169: Pending Diagnostic Events
Proline Promass S 300 HART Diagnostics and troubleshooting 12.8 Pending diagnostic events The Diagnostics menu allows the user to view the current diagnostic event and the previous diagnostic event separately. To call up the measures to rectify a diagnostic event: •...
Page 170 Diagnostics and troubleshooting Proline Promass S 300 HART / ../Diagnose list Diagnostics F273 Main electronic Diagnostics 2 Diagnostics 3 A0014006-EN  36 Using the example of the local display To call up the measures to rectify a diagnostic event: • Via local display →  157 •...
Page 171: 12.10 Event Logbook
Proline Promass S 300 HART Diagnostics and troubleshooting 12.10 Event logbook 12.10.1 Reading out the event logbook A chronological overview of the event messages that have occurred is provided in the Events list submenu. Navigation path Diagnostics menu → Event logbook submenu → Events list / ../Eventlist...
Page 172: 12.10.3 Overview Of Information Events
Diagnostics and troubleshooting Proline Promass S 300 HART 12.10.3 Overview of information events Unlike a diagnostic event, an information event is displayed in the event logbook only and not in the diagnostic list. Info number Info name I1000 --------(Device ok)
Page 173 Proline Promass S 300 HART Diagnostics and troubleshooting Info number Info name I1515 Upload finished I1517 Custody transfer active I1518 Custody transfer inactive I1554 Safety sequence started I1555 Safety sequence confirmed I1556 Safety mode off I1618 I/O module 2 replaced...
Page 174: 12.11 Resetting The Measuring Device
Diagnostics and troubleshooting Proline Promass S 300 HART 12.11 Resetting the measuring device The entire device configuration or some of the configuration can be reset to a defined state with the Device reset parameter (→  129). 12.11.1 Function range of "Device reset" parameter...
Page 175: 12.12 Device Information
Proline Promass S 300 HART Diagnostics and troubleshooting 12.12 Device information The Device information submenu contains all parameters that display different information for device identification. Navigation "Diagnostics" menu → Device information ‣ Device information Device tag →  175 Serial number →...
Page 176 Diagnostics and troubleshooting Proline Promass S 300 HART Parameter Description User interface Factory setting Device name Shows the name of the transmitter. Promass 300/500 –  The name can be found on the nameplate of the transmitter. Manufacturer Displays the manufacturer.
Page 177: 12.13 Firmware History
"Manufacturer' s information" document. The manufacturer' s information is available: • In the Download Area of the Endress+Hauser web site: www.endress.com → Downloads • Specify the following details: •...
Page 178: 12.14 Device History And Compatibility
Diagnostics and troubleshooting Proline Promass S 300 HART 12.14 Device history and compatibility The device model is documented in the order code on the nameplate of the device (e.g. 8F3BXX-XXX..XXXA1-XXXXXX). Device model Release Change compared with earlier model Compatibility with earlier model 09.2019...
Page 179: Maintenance
Observe the inside diameter of the measuring tube and process connection. 13.2 Measuring and test equipment Endress+Hauser offers a variety of measuring and testing equipment, such as Netilion or device tests. Your Endress+Hauser Sales Center can provide detailed information on the services.
Page 180: Repair
• The measuring devices have a modular design. • Spare parts are grouped into logical kits with the associated Installation Instructions. • Repairs are carried out by Endress+Hauser Service or by appropriately trained customers. • Certified devices can only be converted to other certified devices by Endress+Hauser Service or at the factory.
Page 181: Disposal
Proline Promass S 300 HART Repair 14.5 Disposal If required by the Directive 2012/19/EU on waste electrical and electronic equipment (WEEE), the product is marked with the depicted symbol in order to minimize the disposal of WEEE as unsorted municipal waste. Do not dispose of products bearing this marking as unsorted municipal waste.
Page 182: Accessories
Various accessories, which can be ordered with the device or subsequently from Endress +Hauser, are available for the device. Detailed information on the order code in question is available from your local Endress+Hauser sales center or on the product page of the Endress+Hauser website: www.endress.com.
Page 183: For The Sensor
Is used to stabilize the temperature of the fluids in the sensor. Water, water vapor and other non-corrosive liquids are permitted for use as fluids.  If using oil as a heating medium, please consult with Endress+Hauser. Use the order code with the product root DK8003. ...
Page 184: Service-Specific Accessories
Via the Internet: https://portal.endress.com/webapp/applicator Netilion lloT ecosystem: Unlock knowledge With the Netilion IIoT ecosystem,Endress+Hauser allows you to optimize your plant performance, digitize workflows, share knowledge, and enhance collaboration. Drawing upon decades of experience in process automation, Endress+Hauser offers the process industry an IIoT ecosystem designed to effortlessly extract insights from data.
Page 185: Technical Data
Proline Promass S 300 HART Technical data Technical data 16.1 Application The measuring device is intended only for the flow measurement of liquids. Depending on the version ordered, the measuring device can also measure potentially explosive, flammable, poisonous and oxidizing media.
Page 186: Input
To increase the measurement accuracy of certain measured variables, the automation system can continuously write various measured values to the measuring instrument: • Operating pressure to increase measurement accuracy (Endress+Hauser recommends the use of a pressure measuring device for absolute pressure, e.g. Cerabar M or Cerabar •...
Page 187 Proline Promass S 300 HART Technical data Current input The measured values are written from the automation system to the measuring device via the current input →  187. Current input 0/4 to 20 mA Current input 0/4 to 20 mA (active/passive) Current span •...
Page 188: Output
Technical data Proline Promass S 300 HART 16.4 Output Output signal Current output 4 to 20 mA HART Order code "Output; input 1" (20): Option BA: current output 4 to 20 mA HART Signal mode Can be set to: • Active •...
Page 189: Current Output 4 To 20 Ma
Proline Promass S 300 HART Technical data Damping Configurable: 0 to 999.9 s Assignable measured • Mass flow variables • Volume flow • Corrected volume flow • Density • Reference density • Temperature • Electronics temperature • Oscillation frequency 0 •...
Page 190 Technical data Proline Promass S 300 HART Maximum output values 22.5 mA Maximum input voltage DC 30 V Load 0 to 700 Ω Resolution 0.38 µA Damping Configurable: 0 to 999 s Assignable measured • Mass flow variables • Volume flow •...
Page 191 Proline Promass S 300 HART Technical data Assignable measured • Mass flow variables • Volume flow • Corrected volume flow • Density • Reference density • Temperature • Electronics temperature • Oscillation frequency 0 • Oscillation damping 0 • Signal asymmetry •...
Page 192 Technical data Proline Promass S 300 HART Pulse/pause ratio Assignable measured • Mass flow variables • Volume flow • Corrected volume flow • Density • Reference density • Temperature  The range of options increases if the measuring device has one or more application packages.
Page 193: Local Display
Proline Promass S 300 HART Technical data Current output 0/4 to 20 mA 4 to 20 mA Failure mode Choose from: • 4 to 20 mA in accordance with NAMUR recommendation NE 43 • 4 to 20 mA in accordance with US •...
Page 194: Web Browser
Technical data Proline Promass S 300 HART Interface/protocol • Via digital communication: HART protocol • Via service interface • CDI-RJ45 service interface • WLAN interface Plain text display With information on cause and remedial measures Web browser Plain text display...
Page 195 Proline Promass S 300 HART Technical data Order code Terminal voltage Frequency range "Power supply" DC 24 V ±20% – Option I AC 100 to 240 V –15…+10% 50/60 Hz Power consumption Transmitter Max. 10 W (active power) switch-on current Max.
Page 196: Performance Characteristics
Technical data Proline Promass S 300 HART 16.6 Performance characteristics Reference operating • Error limits based on ISO 11631 conditions • Water • +15 to +45 °C (+59 to +113 °F) • 2 to 6 bar (29 to 87 psi) •...
Page 197: Accuracy Of Outputs
Proline Promass S 300 HART Technical data SI units 1:10 1:20 1:50 1:100 1:500 [mm] [kg/h] [kg/h] [kg/h] [kg/h] [kg/h] [kg/h] 2 000 6 500 18 000 1 800 45 000 4 500 2 250 70 000 7 000 3 500...
Page 198 Technical data Proline Promass S 300 HART Influence of ambient Current output temperature Temperature coefficient Max. 1 μA/°C Pulse/frequency output Temperature coefficient No additional effect. Included in accuracy. Influence of medium Mass flow temperature o.f.s. = of full scale value...
Page 199 Proline Promass S 300 HART Technical data o.r. = of reading It is possible to compensate for the effect by: • Reading in the current pressure measured value via the current input or a digital input. • Specifying a fixed value for the pressure in the device parameters.
Page 200: Mounting
The device is suitable for use outdoors and indoors with a relative humidity of 4 to 95 %. Operating height According to EN 61010-1 • ≤ 2 000 m (6 562 ft) • > 2 000 m (6 562 ft) with additional overvoltage protection (e.g. Endress+Hauser HAW Series) Degree of protection Transmitter •...
Page 201: Process
Proline Promass S 300 HART Technical data Rough handling shocks according to IEC 60068-2-31 Internal cleaning • CIP cleaning • SIP cleaning • Cleaning with pigs Options Oil- and grease-free version for wetted parts, without declaration Order code for "Service", option HA...
Page 202: 16.10 Mechanical Construction
Technical data Proline Promass S 300 HART The sensor housing burst pressure refers to a typical internal pressure which is reached prior to mechanical failure of the sensor housing and which was determined during type testing. The corresponding type test declaration can be ordered with the device (order code for "Additional approval", option LN "Sensor housing burst pressure, type test").
Page 203: Transmitter Housing
Proline Promass S 300 HART Technical data Weight in SI units Weight [kg] [mm] Weight in US units Weight [lbs] [in] ½ 1½ Materials Transmitter housing Order code for "Housing": • Option A "Aluminum, coated": aluminum, AlSi10Mg, coated • Option B "Stainless, hygienic": stainless steel, 1.4404 (316L) Window material Order code for "Housing":...
Page 204: Sensor Housing
Technical data Proline Promass S 300 HART Order code for "Housing", option A "Aluminum, coated" The various cable entries are suitable for hazardous and non-hazardous areas. Cable entry/cable gland Material Non-Ex: plastic Compression fitting M20 × 1.5 Z2, D2, Ex d/de: brass with plastic Adapter for cable entry with female thread G ½"...
Page 205: 16.11 Operability
Proline Promass S 300 HART Technical data Process connections • Fixed flange connections: • EN 1092-1 (DIN 2501) flange • EN 1092-1 (DIN 2512N) flange • ASME B16.5 flange • JIS B2220 flange • DIN 11864-2 Form A flange, DIN 11866 series A, flange with notch •...
Page 206 Technical data Proline Promass S 300 HART A0026785  39 Operation with touch control Display elements • 4-line, illuminated, graphic display • White background lighting; switches to red in event of device errors • Format for displaying measured variables and status variables can be individually...
Page 207 Proline Promass S 300 HART Technical data Housing material The housing material of the display and operating module DKX001 depends on the choice of transmitter housing material. Transmitter housing Remote display and operating module Order code for "Housing" Material Material Option A "Aluminum, coated"...
Page 208 Technical data Proline Promass S 300 HART Supported operating Operating unit Interface Additional information tools Field Xpert SMT70/77/50 • All fieldbus protocols Operating Instructions • WLAN interface BA01202S • Bluetooth Device description files: • CDI-RJ45 service Use update function of...
Page 209: Historom Data Management
Proline Promass S 300 HART Technical data HistoROM The measuring device features HistoROM data management. HistoROM data management data management comprises both the storage and import/export of key device and process data, making operation and servicing far more reliable, secure and efficient.
Page 210: 16.12 Certificates And Approvals
The device meets the legal requirements of the applicable EU Directives. These are listed in the corresponding EU Declaration of Conformity along with the standards applied. Endress+Hauser confirms successful testing of the device by affixing to it the CE mark. UKCA marking The device meets the legal requirements of the applicable UK regulations (Statutory Instruments).
Page 211 Directive a) PED/G1/x (x = category) or b) PESR/G1/x (x = category) on the sensor nameplate, Endress+Hauser confirms compliance with the "Essential Safety Requirements" a) specified in Annex I of the Pressure Equipment Directive 2014/68/EU or b) Schedule 2 of Statutory Instruments 2016 No. 1105.
Page 212: Application Packages
The application packages can be ordered with the device or subsequently from Endress+Hauser. Detailed information on the order code in question is available from your local Endress+Hauser sales center or on the product page of the Endress+Hauser website: www.endress.com.
Page 213: Heartbeat Verification
Proline Promass S 300 HART Technical data Event log: Memory volume is extended from 20 message entries (standard version) to up to 100 entries. Data logging (line recorder): • Memory capacity for up to 1000 measured values is activated. • 250 measured values can be output via each of the 4 memory channels. The recording interval can be defined and configured by the user.
Page 214: 16.14 Accessories
For an overview of the scope of the associated Technical Documentation, refer to the following: • Device Viewer (www.endress.com/deviceviewer): Enter the serial number from the nameplate • Endress+Hauser Operations app: Enter serial number from nameplate or scan matrix code on nameplate. Standard documentation Brief Operating Instructions...
Page 215: Safety Instructions
Proline Promass S 300 HART Technical data Supplementary device- Safety instructions dependent documentation Safety instructions for electrical equipment for hazardous areas. Contents Documentation code ATEX/IECEx Ex d/Ex de XA01405D ATEX/IECEx Ex ec XA01439D cCSAus XP XA01373D cCSAus Ex d/ Ex de...
Page 216: Installation Instructions
Technical data Proline Promass S 300 HART Installation instructions Contents Note Installation instructions for spare part sets and • Access the overview of all the available spare part accessories sets via Device Viewer →  180 • Accessories available for order with Installation Instructions →...
Page 217: Index
Proline Promass S 300 HART Index Index 0 … 9 Connection see Electrical connection 3-A approval ......211 Connection cable .
Page 218 Index Proline Promass S 300 HART Display Field of application see Local display Residual risks ......10 Display and operating module DKX001 .
Page 219 Proline Promass S 300 HART Index Inspection Mounting ....... . . 21 Connection .
Page 220 Index Proline Promass S 300 HART Configuration backup (Submenu) ... . 127 Process connections ......205 Corrected volume flow calculation (Submenu) .
Page 221 Proline Promass S 300 HART Index Status input ......87 Totalizer ......139 Switch output .
Page 222 Index Proline Promass S 300 HART UKCA marking ......210 Use of measuring device Borderline cases .
Page 224 *71674552* 71674552 www.addresses.endress.com...

Endress+Hauser Proline Promass S 300 Operating Instructions Manual

Quick Links

Need help?

Questions and answers

Related Manuals for Endress+Hauser Proline Promass S 300

Summary of Contents for Endress+Hauser Proline Promass S 300

Table of Contents
