Package contents

Check your motherboard package for the following items.
Motherboard
Cables
Miscellaneous
Documentation
If any of the above items is damaged or missing, contact your retailer.

PRIME B760-PLUS specifications summary

CPU
Chipset
Memory
Graphics
Expansion Slots
vi
1 x PRIME B760-PLUS motherboard
2 x SATA 6Gb/s cables
1 x I/O Shield
1 x M.2 Rubber Package
2 x Screw Packages for M.2 SSD
1 x User guide
Intel Socket LGA1700 for 13
®
Core™, Pentium Gold and Celeron
®
Supports Intel Turbo Boost Technology 2.0 and Intel
®
Technology 3.0**
* Refer to www.asus.com for CPU support list.
** Intel Turbo Boost Max Technology 3.0 support depends on the CPU types.
®
Intel B760 Chipset
®
4 x DIMM, Max. 128GB, DDR5 Non-ECC, Un-buffered Memory*
Dual Channel Memory Architecture
Supports Intel Extreme Memory Profile (XMP)
®
OptiMem II
* Supported memory types, data rate (speed), and number of DRAM modules vary
depending on the CPU and memory configuration, for more information please
refer to CPU/Memory Support list under the Support tab of product information
site or visit https://www.asus.com/support/.
* Non-ECC, un-buffered DDR5 memory supports On-Die ECC function.
1 x DisplayPort**
1 x VGA port
1 x HDMI port***
TM
* Graphics specifications may vary between CPU types. Please refer to
www.intel.com for any updates.
** Supports max. 4K@60Hz as specified in DisplayPort 1.4.
*** Supports 4K@60Hz as specified in HDMI
Intel 13 &12 Gen Processors
® th th
1 x PCIe 5.0 x16 slot
Intel B760 Chipset
®
1 x PCIe 4.0 x16 slot (supports x4 mode)
2 x PCIe 3.0 x1 slots
Note: To ensure compatibility of the device installed, please refer to
https://www.asus.com/support/ for the list of supported peripherals.
(continued on the next page)
Gen Intel Core™ & 12
th ®
Processors*
®
2.1.
TM
Gen Intel
th ®
Turbo Boost Max
®
