- Page 1 PRIME B450-PLUS...
- Page 2 Product warranty or service will not be extended if: (1) the product is repaired, modified or altered, unless such repair, modification of alteration is authorized in writing by ASUS; or (2) the serial number of the product is defaced or missing.
-
Page 3: Table Of Contents
Contents Safety information ..................iv About this guide ..................iv Package contents ..................vi PRIME B450-PLUS specifications summary ..........vi Chapter 1: Product introduction Motherboard overview ................1-1 Central Processing Unit (CPU) ..............1-8 System memory ..................1-10 Chapter 2: BIOS information BIOS setup program ................. -
Page 4: Safety Information
Safety information Electrical safety • To prevent electrical shock hazard, disconnect the power cable from the electrical outlet before relocating the system. • When adding or removing devices to or from the system, ensure that the power cables for the devices are unplugged before the signal cables are connected. If possible, disconnect all power cables from the existing system before you add a device. - Page 5 Refer to the following sources for additional information and for product and software updates. ASUS websites The ASUS website provides updated information on ASUS hardware and software products. Refer to the ASUS contact information. Optional documentation Your product package may include optional documentation, such as warranty flyers, that may have been added by your dealer.
-
Page 6: Package Contents
MHz, un-buffered memory Memory Dual-channel memory architecture * Refer to www.asus.com for the latest Memory QVL (Qualified Vendors List). ** ECC memory(ECC mode) support varies by CPU. Integrated Graphics in the AMD Ryzen™ with Radeon™ Vega Graphics processors Multi-VGA output support: HDMI and DVI-D ports Graphics - Supports HDMI 2.0b output with a maximum resolution of 4096 x 2160 @60Hz... - Page 7 Dependable Stability ASUS 5X PROTECTION III - ASUS SafeSlot Core - Fortified PCIe Slot prevents damage - ASUS LANGuard: Protects against LAN surges, lightning strikes and static- electricity discharges! - ASUS Overvoltage Protection: World-class circuit-protecting power design - ASUS Stainless-Steel Back I/O: 3X corrosion-resistance for greater durability!
- Page 8 1 x AIO pump header 128 Mb Flash ROM, UEFI AMI BIOS, PnP, SM BIOS 3.1, ACPI 6.1, Multi- language BIOS, ASUS EZ Flash 3, ASUS CrashFree BIOS 3, F3 My Favorite, BIOS features Last Modified log, F12 PrintScreen,F4 AURA ON/OFF, F9 Search and ASUS...
- Page 9 Manageability WOL by PME, PXE Drivers ASUS Utilities Support DVD ASUS Update Anti-virus software (OEM version) OS support Windows 10 (64-bit) ® Form factor ATX form factor: 12” x 9.2” (30.5 cm x 23.4 cm) Specifications are subject to change without notice.
-
Page 10: Motherboard Overview
AUDIO 22110 2280 2260 2242 PCIEX16_1 8111H ® B450 BATTERY PCIEX1_1 Super CHA_FAN3 PCIEX16_2 PCIEX1_2 SATA6G_4 SATA6G_3 PCIEX1_3 CLRTC SATA6G_2 SATA6G_1 U31G1_12 USB56 USB34 SPDIF_OUT PANEL AAFP Scan the QR code to get the detailed pin definitions. ASUS PRIME B450-PLUS... - Page 11 • If you are uncertain about the minimum power supply requirement for your system, refer to the Recommended Power Supply Wattage Calculator at http://support. asus.com/PowerSupplyCalculator/PSCalculator.aspx?SLanguage=en-us for details. CPU and chassis fan connectors; AIO pump connector (4-pin CPU_FAN, 4-pin CHA_FAN1/2/3; 4-pin AIO_PUMP) Connect the fan cables to the fan connectors on the motherboard, ensuring that the black wire of each cable matches the ground pin of the connector.
- Page 12 Connect a USB module cable to any of these connectors, then install the module to a slot opening at the back of the system chassis. These USB connectors comply with USB 2.0 specifications and support up to 480Mbps connection speed. ASUS PRIME B450-PLUS...
- Page 13 Clear RTC RAM (2-pin CLRTC) CLRTC This header allows you to clear the CMOS RTC RAM data of the system setup information such as date, time, and system passwords. To erase the RTC RAM: PIN 1 Turn OFF the computer and unplug the power cord. Use a metal object such as a screwdriver to short the two pins.
- Page 14 • We recommend that you provide sufficient power when running CrossFireX™ mode. • Connect chassis fans to the motherboard chassis fan connectors when using multiple graphics cards for better thermal environment. ASUS PRIME B450-PLUS...
- Page 15 Rear panel connectors PS/2 Keyboard/Mouse cambo port. This port is for a PS/2 keyboard or mouse. DVI-D port. This port is for any DVI-D compatible device. DVI-D can not be converted to output from RGB Signal to CRT and is not compatible with DVI-I.
- Page 16 HDMI port. This port is for a High-Definition Multimedia Interface (HDMI) connector, and is HDCP compliant allowing playback of HD DVD, Blu-ray, and other protected content. USB 2.0 ports. These 4-pin Universal Serial Bus (USB) ports are for USB 2.0/1.1 devices. ASUS PRIME B450-PLUS...
-
Page 17: Central Processing Unit (Cpu)
Central Processing Unit (CPU) The motherboard comes with an AMD AM4 socket designed for AMD Ryzen™ 2 Generation / Ryzen™ with Radeon™ Vega Graphics / Ryzen™ 1 Generation processors. Unplug all power cables before installing the CPU. The AM4 socket has a different pinout from the FM2+/FM2 socket. Ensure that you use a CPU designed for the AM4 socket. - Page 18 Installing the CPU heatsink and fan assembly Type 1 Type 2 Remove the screws and the retention module only. Do not remove the plate on the bottom. ASUS PRIME B450-PLUS...
-
Page 19: System Memory
Check with the retailer to get the correct memory modules. • For system stability, use a more efficient memory cooling system to support a full memory load (4 DIMMs). • Refer to www.asus.com for the latest Memory QVL (Qualified Vendors List) Recommended memory configuration DIMM_A1 DIMM_A2* DIMM_A2*... - Page 20 Installing a DIMM To remove a DIMM ASUS PRIME B450-PLUS 1-11...
-
Page 21: Chapter 2: Bios Information
The BIOS setup screens shown in this section are for reference purposes only, and may not exactly match what you see on your screen. • Visit the ASUS website at www.asus.com to download the latest BIOS file for this motherboard. •... -
Page 22: Ez Mode
EZ Mode By default, the EZ Mode screen appears when you enter the BIOS setup program. The EZ Mode provides you an overview of the basic system information, and allows you to select the display language, system performance mode, fan profile and boot device priority. To access the Advanced Mode, click Advanced Mode(F7) or press <F7>. -
Page 23: Advanced Mode
MyFavorite Search Q-Fan control AURA ON/OFF Language Menu bar Configuration Sub-menu items Scroll bar fields Search on General help Last modified Menu items settings Hot Keys Goes back Popup window to EZ Mode Displays hardware monitoring data ASUS PRIME B450-PLUS... -
Page 24: Exit Menu
Search on FAQ Move your mouse over this button to show a QR code. Scan this QR code with your mobile device to connect to the ASUS BIOS FAQ web page. You can also scan the QR code below. Exit menu The Exit menu items allow you to load the optimal default values for the BIOS items, and save or discard your changes to the BIOS items. -
Page 25: Appendix
The use of shielded cables for connection of the monitor to the graphics card is required to assure compliance with FCC regulations. Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. ASUS PRIME B450-PLUS... - Page 26 Compliance Statement of Innovation, Science and Economic Development Canada (ISED) This device complies with Innovation, Science and Economic Development Canada licence exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.
- Page 27 ASUS Recycling/Takeback Services ASUS recycling and takeback programs come from our commitment to the highest standards for protecting our environment. We believe in providing solutions for you to be able to responsibly recycle our products, batteries, other components as well as the packaging materials.
- Page 28 доступний на: www.asus.com/support Cijeli tekst EU izjave o sukladnosti dostupan je na: www.asus.com/support Türkçe AsusTek Computer Inc., bu aygıtın temel gereksinimlerle ve ilişkili Čeština Společnost ASUSTeK Computer Inc. tímto prohlašuje, že toto Yönergelerin diğer ilgili koşullarıyla uyumlu olduğunu beyan eder.
-
Page 29: Asus Contact Information
+1-510-739-3777 +1-510-608-4555 Web site http://www.asus.com/us/ Technical Support Support fax +1-812-284-0883 Telephone +1-812-282-2787 Online support http://qr.asus.com/techserv ASUS COMPUTER GmbH (Germany and Austria) Address Harkort Str. 21-23, 40880 Ratingen, Germany +49-2102-959931 Web site http://www.asus.com/de Online contact http://eu-rma.asus.com/sales Technical Support Telephone +49-2102-5789555 Support Fax... - Page 30 FCC COMPLIANCE INFORMATION Per FCC Part 2 Section 2.1077 Asus Computer International Responsible Party: Address: 800 Corporate Way, Fremont CA 94539. Phone/Fax No: (510)739-3777/(510)608-4555 hereby declares that the product Product Name : Motherboard Model Number : PRIME B450-PLUS compliance statement: This device complies with part 15 of the FCC Rules.
