Summary of Contents for Asus PRIME B760-PLUS
- Page 1 Questo manuale d’istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per Asus Prime B760- PLUS DDR5 o cerca il tuo prodotto tra le migliori offerte di Schede Madri PRIME B760-PLUS...
- Page 2 Product warranty or service will not be extended if: (1) the product is repaired, modified or altered, unless such repair, modification of alteration is authorized in writing by ASUS; or (2) the serial number of the product is defaced or missing.
-
Page 3: Table Of Contents
Contents Safety information ...................... iv About this guide ......................v Package contents ....................... vi PRIME B760-PLUS specifications summary............vi Chapter 1: Product Introduction Before you proceed ..................1-1 Motherboard overview ................. 1-2 Central Processing Unit (CPU) ..............1-10 System memory ..................1-12 M.2 installation .................... -
Page 4: Safety Information
Safety information Electrical safety • To prevent electrical shock hazard, disconnect the power cable from the electrical outlet before relocating the system. • When adding or removing devices to or from the system, ensure that the power cables for the devices are unplugged before the signal cables are connected. If possible, disconnect all power cables from the existing system before you add a device. -
Page 5: About This Guide
Refer to the following sources for additional information and for product and software updates. ASUS website The ASUS website (www.asus.com) provides updated information on ASUS hardware and software products. Optional documentation Your product package may include optional documentation, such as warranty flyers, that may have been added by your dealer. -
Page 6: Package Contents
Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max ® ® Technology 3.0** * Refer to www.asus.com for CPU support list. ** Intel Turbo Boost Max Technology 3.0 support depends on the CPU types. ® Intel B760 Chipset Chipset ®... - Page 7 PRIME B760-PLUS specifications summary Total supports 3 x M.2 slots and 4 x SATA 6Gb/s ports* Intel &12 Gen Processors ® M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode) Intel B760 Chipset ® Storage M.2_2 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 4.0 x4 mode) M.2_3 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x2 mode)
- Page 8 PRIME B760-PLUS specifications summary Fan and Cooling related 1 x 4-pin CPU Fan header 1 x 4-pin AIO Pump header 3 x 4-pin Chassis Fan headers Power related 1 x 24-pin Main Power connector 1 x 8-pin +12V Power connector Storage related 3 x M.2 slots (Key M)
- Page 9 Form Factor 12 inch x 9.6 inch (30.5 cm x 24.4 cm) • Specifications are subject to change without notice. Refer to the ASUS website for the latest specifications. • For more information on downloading and installing drivers and utilities for your...
-
Page 11: Chapter 1: Product Introduction
• The pin definitions in this chapter are for reference only. The pin names depend on the location of the header/jumper/connector. • For more information on installing your motherboard, please scan the QR code below: PRIME B760-PLUS... -
Page 12: Motherboard Overview
Motherboard overview 24.4cm(9.6in) CPU_FAN AIO_PUMP HDMI ATX_12V DIGI+ USB_78 U32G1_9 U32G2X2_C1 LGA1700 LAN_U32G2_34 M.2(WIFI) AUDIO 2242 2260 2280 M.2_1(SOCKET3) PCIEX1(G3)_1 PCIE SATA 4.0 X4 PCIEX16(G5) Ethernet Intel ® B760 BATTERY PCIEX1(G3)_2 Super COM_DEBUG PCIEX16(G4) Audio Codec 2280 2242 2260 22110 2280 2260 2242... -
Page 13: Expansion Slots
M.2_2 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 4.0 x4 mode) M.2_3 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x2 mode) 7. SATA 6Gb/s ports The SATA 6Gb/s ports allow you to connect SATA devices such as optical disc drives and hard disk drives via SATA cables. PRIME B760-PLUS... - Page 14 8. USB 3.2 Gen 1 Type-C Front Panel connector ® VBUS TX2+ The USB 3.2 Gen 1 Type-C connector allows you to connect a USB ® TX2- VBUS 3.2 Gen 1 Type-C module for an additional USB 3.2 Gen 1 Type-C ®...
-
Page 15: Clear Cmos Header
I/O module that supports HD Audio. Connect one end of the front panel audio I/O module cable to this header. AAFP We recommend that you connect a high-definition front panel audio module to this header to avail of the motherboard’s high-definition audio capability. HD-audio-compliant pin definition PRIME B760-PLUS... -
Page 16: S/Pdif Out Header
16. S/PDIF Out header SPDIF_OUT The S/PDIF Out header allows you to connect the Sony/Philips Digital Interface (S/PDIF) Out module. The S/PDIF module is purchased separately. 17. SPI TPM header This header supports a Trusted Platform Module (TPM) PIN 1 VCCSPI S_SPI_TPM_IRQ# system with a Serial Peripheral Interface (SPI), allowing you... - Page 17 Please visit the official website of your purchased add-on PIN 1 card for more details on compatibility. The add-on card can only be used when installed to the PCIEX16(G4) slot. Ensure to install your add-on card to the PCIEX16(G4) slot. PRIME B760-PLUS...
-
Page 18: Rear Panel Connectors
1.2.2 Rear panel connectors Video Graphics Adapter (VGA) port. This 15-pin port is for a VGA monitor or other VGA-compatible devices. USB 3.2 Gen 1 (up to 5Gbps) port. This Universal Serial Bus (USB) port connects to a USB 3.2 Gen 1 device. 2.5Gb Ethernet port. - Page 19 Center/ Center/ (Rear panel) Subwoofer Subwoofer Lime Side Speaker Out (Front panel) Pink (Front panel) To configure a 7.1-channel audio output: Use a chassis with HD audio module in the front panel to support a 7.1-channel audio output. PRIME B760-PLUS...
-
Page 20: Central Processing Unit (Cpu)
CPU designed for LGA1155, LGA1156, LGA1151, and LGA1200 sockets on the LGA1700 socket. • ASUS will not cover damages resulting from incorrect CPU installation/removal, incorrect CPU orientation/placement, or other damages resulting from negligence by the user. Installing the CPU... - Page 21 PRIME B760-PLUS 1-11...
-
Page 22: System Memory
Supported memory types, data rate (speed), and number of DRAM modules vary depending on the CPU and memory configuration, for more information please refer to CPU/Memory Support list under the Support tab of product information site or visit https://www.asus.com/support/. Recommended memory configurations DIMM_A1... -
Page 23: Installing A Dimm
Installing a DIMM To remove a DIMM PRIME B760-PLUS 1-13... -
Page 24: Installation
M.2 installation OPTIONAL • Ensure to install the bundled M.2 rubber pad before installing your single sided M.2 storage device. • DO NOT install the bundled M.2 rubber pads when installing a double-sided M.2 storage device. The rubber pad installed by default is compatible with double sided M.2 storage devices. -
Page 25: Chapter 2: Bios And Raid Support
BIOS and RAID Support Knowing BIOS The new ASUS UEFI BIOS is a Unified Extensible Interface that complies with UEFI architecture, offering a user-friendly interface that goes beyond the traditional keyboard- only BIOS controls to enable a more flexible and convenient mouse input. You can easily navigate the new UEFI BIOS with the same smoothness as your operating system. -
Page 26: Bios Setup Program
BIOS Setup program Use the BIOS Setup to update the BIOS or configure its parameters. The BIOS screens include navigation keys and brief onscreen help to guide you in using the BIOS Setup program. Entering BIOS at startup To enter BIOS Setup at startup, press <Delete> or <F2> during the Power-On Self Test (POST). -
Page 27: Asus Ez Flash 3
ASUS EZ Flash 3 The ASUS EZ Flash 3 feature allows you to update the BIOS without using an OS-based utility. Ensure to load the BIOS default settings to ensure system compatibility and stability. Select the Load Optimized Defaults item under the Exit menu or press hotkey <F5>. -
Page 28: Asus Crashfree Bios 3
ASUS CrashFree BIOS 3 The ASUS CrashFree BIOS 3 utility is an auto recovery tool that allows you to restore the BIOS file when it fails or gets corrupted during the updating process. You can restore a corrupted BIOS file using a USB flash drive that contains the BIOS file. -
Page 29: Raid Configurations
For more information on configuring your RAID sets, please refer to the RAID Configuration Guide which you can find at https://www.asus.com/support, or by scanning the QR code. RAID definitions RAID 0 (Data striping) optimizes two identical hard disk drives to read and write data in parallel, interleaved stacks. - Page 30 Chapter 2: BIOS and RAID Support...
-
Page 31: Appendix
Appendix Notices FCC Compliance Information Responsible Party: Asus Computer International Address: 48720 Kato Rd., Fremont, CA 94538, USA Phone / Fax No: (510)739-3777 / (510)608-4555 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. - Page 32 Compliance Statement of Innovation, Science and Economic Development Canada (ISED) This device complies with Innovation, Science and Economic Development Canada licence exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.
-
Page 33: India Rohs
ASUS products sold in Vietnam, on or after September 23, 2011,meet the requirements of the Vietnam Circular 30/2011/TT-BCT. Các sản phẩm ASUS bán tại Việt Nam, vào ngày 23 tháng 9 năm2011 trở về sau, đều phải đáp ứng các yêu cầu của Thông tư 30/2011/TT-BCT của Việt Nam. -
Page 34: Safety Precautions
France sorting and recycling information À DÉPOSER À DÉPOSER Cet appareil EN MAGASIN EN DÉCHÈTERIE et ses accessoires se recyclent Points de collecte sur www.quefairedemesdechets.fr Privilégiez la répara�on ou le don de votre appareil ! Safety Precautions Accessories that came with this product have been designed and verified for the use in connection with this product. -
Page 35: Simplified Eu Declaration Of Conformity
Français AsusTek Computer Inc. déclare par la présente que cet appareil est conforme aux critères essentiels et autres clauses pertinentes des directives concernées. La déclaration de conformité de l’UE peut être téléchargée à partir du site Internet suivant : www.asus.com/support. -
Page 36: Warranty
• ASUS offers a voluntary manufacturer’s Commercial Guarantee. • ASUS dragovoljno nudi komercijalno proizvođačko jamstvo. • ASUS reserves the right to interpret the provisions of the ASUS • ASUS zadržava prava na tumačenje odredbi ASUS komercijalnog Commercial Guarantee. jamstva. •... - Page 37 • ASUS tilbyr som produsent en frivillig kommersiell garanti. • Bảo hành thương mại này của ASUS được cung cấp độc lập và ngoài • ASUS forbeholder seg retten til å tolke bestemmelsene i ASUS sin Bảo đảm pháp lý theo luật định và không có cách nào ảnh hưởng đến kommersielle garanti.
-
Page 38: Asus Contact Information
Address: 1F., No. 15, Lide Rd., Beitou Dist., Taipei City 112 ASUS COMPUTER INTERNATIONAL (America) Address: 48720 Kato Rd., Fremont, CA 94538, USA ASUS COMPUTER GmbH (Germany and Austria) Address: Harkortstrasse 21-23, 40880 Ratingen, Germany ASUSTeK (UK) LIMITED Address: 1st Floor, Sackville House, 143-149 Fenchurch Street, London, EC3M 6BL,...
