Comprehensive Operating Manual & Guide to Metal Detecting
ACCESSORIES
Fisher Padded Carry Bag ......
$ 45.00
Rugged double stitched construction. Includes handy
exterior pocket for extra batteries or small accessories.
103693000C
Fisher Stereo Headphones ......
Use with Fisher metal detectors. Lightweight and adjustable with
true stereo sound, adjustable volume, 1/8 jack with 1/4 adaptor,
4' cable. 9720950000
Fisher Pin Pointer ......
$ 69.00
Pinpoints the exact location of buried metal objects. Audio signal
indicator and vibrator. Runs on 1 – 9-Volt Battery. FPOINT
Metal Sand Scoop ......
$ 29.99
Large galvanized metal scoop with filtering holes.
Strong Rubberized grip. SAND SCOOP
Lesche Knife ......
$ 49.95
Made from high quality heat-treated tempered steel.
The ultimate digging tool. Comes with a durable sheath.
12" in length with a 7" serrated blade. LESCHE KNIFE
Fisher Apron ......
$ 5.95
Natural canvas with 2 large pockets.
Fisher Baseball Cap ......
$ 14.95
One size fits all. FCAP
Fisher T-Shirt* ......
$ 19.99
®
100% white cotton with Fisher
Logo. Sizes – LG, XL & XXL
Replacement/Accessory Search Coils
......
11" Biaxial Accessory Coil - 11COIL-F75
10" Concentric Standard Coil (replacement)– 10COIL-F70
......
6.5" Concentric Accessory Coil - 6COIL-E
......
5" Biaxial Accessory Coil - 5COIL-F75
$ 159.95
Coil Covers
Specially made to protect your coil from abrasion and damage.
11" Biaxial Accessory Coil Cover – COVER-11DD
10" Concentric Standard Coil Cover – F70COVER
6.5" Concentric Accessory Coil Cover- 6COVER-E
5" Biaxial Accessory Coil Cover - 5COVER-CZ3
Fisher
Face Rain Cover......
®
$ 10.95
Specially made to protect your F70 from weather
Gold
Prospecting Kits
$ 29.99
$ 59.99
FOR COMPLETE DETAILS VISIT WWW.FISHERLAB.COM • 1-800-685-5050
*Image not shown.
M75M
$ 40.00
$ 199.95
.
$ 179.00
$ 169.00
......
$ 19.99
......
$ 19.95
......
$ 7.00
......
$ 7.00
$ 109.99
Rev. 2
122211
L
I
M
I
T
E
D
L
I
M
I
T
E
D
Metal Detector
Users Manual
Advertisement
Table of Contents
Related Manuals for Fisher F75 LIMITED
Summary of Contents for Fisher F75 LIMITED
- Page 1 103693000C Fisher Stereo Headphones ..$ 40.00 Use with Fisher metal detectors. Lightweight and adjustable with true stereo sound, adjustable volume, 1/8 jack with 1/4 adaptor, 4’ cable. 9720950000 Fisher Pin Pointer ..
-
Page 2: Product Features
• Covers provided for both the control housing and battery box. • Made in the USA If you have any questions, or need assistance with your metal detector, Call 1-915-225-0333, and ask for Fisher Hobby Technical Service Copyright Fisher Research Labs, Inc., September 28, 2009... -
Page 3: Table Of Contents
Static All Metal Mode ........18 To return your detector for service, please first contact Fisher Labs for a Return Discrimination Mode . -
Page 4: Specifications
LIMITED LIMITED Comprehensive Operating Manual & Guide to Metal Detecting Comprehensive Operating Manual & Guide to Metal Detecting Specifications How Metal Detectors Work Mechanical: S-rod with electronics housing mounted on handgrip, 3-piece Most hobby metal detectors use VLF Induction Balance technology. Here's how they work. breakdown, batteries under elbow, 2-way armrest adjustment —... -
Page 5: Quick-Start
• Never destroy historical or archaeological treasures. The 2-digit numeric display indicates approximate target depth, in inches. • All treasure hunters may be judged by the example you set; always conduct yourself with courtesy and consideration of others Copyright Fisher Research Labs, Inc. 2010. - Page 6 You will re-wrap the cable later after sizing the rods to your height. All Fisher Research Labs searchcoils are waterproof, allowing you to search in shallow water about two feet deep. If searching around water, be careful not to get the electronics housing wet.
-
Page 7: Assembly Instructions
LIMITED LIMITED Comprehensive Operating Manual & Guide to Metal Detecting Comprehensive Operating Manual & Guide to Metal Detecting Detecting Activities (continued) Assembly (continued) Gold Prospecting (continued) 7. Push cable into connector on back of housing. Do not twist the cable or plug. minerals, serious gold prospecting requires a detector with high sensitivity 8. -
Page 8: Mechanicals
LIMITED LIMITED Comprehensive Operating Manual & Guide to Metal Detecting Comprehensive Operating Manual & Guide to Metal Detecting Mechanicals Detecting Activities (continued) Relic Hunting (continued) BATTERIES (not included) or documentation, their context will be lost. The F75 requires four AA batteries. The ground balancing and Fe bar graph features of the F75 can be used to map the soils These non-rechargeable chemistries may be used: Alkaline, Nickel Oxy-Hydroxide... -
Page 9: Arm Rest Adjustment
LIMITED LIMITED Comprehensive Operating Manual & Guide to Metal Detecting Comprehensive Operating Manual & Guide to Metal Detecting Mechanicals (continued) Detecting Activities (continued) ARM REST Relic Hunting The arm rest WIDTH and POSITION are both adjustable. Relic hunting is searching for historical artifacts. The most common desired objects are battlefield debris, coins, jewelry, harness hardware, Arm Rest Width: The sides of the arm rest metal buttons, trade tokens, metal toys, household items, and tools... -
Page 10: Detecting Activities
The lead engineers on the F75 design team were John Gardiner and David Johnson. security personnel often have the legal authority to David Johnson’s previous Fisher design credits include the CZ-platform, the Gold Bug- prohibit any activity they do not like even if there is no series, most of the 1200-series, Impulse Underwater Detector, CZ-20 Underwater ordinance against it. -
Page 11: Controls
LIMITED LIMITED Comprehensive Operating Manual & Guide to Metal Detecting Comprehensive Operating Manual & Guide to Metal Detecting Search Techniques (continued) Controls Tips on ground balancing DUAL FUNCTION MENU BUTTON When the F75 first turns on, the ground balance setting is preset to 90. This will give a positive response on nearly all soils. -
Page 12: Hot Rocks
LIMITED LIMITED Comprehensive Operating Manual & Guide to Metal Detecting Comprehensive Operating Manual & Guide to Metal Detecting Controls (continued) Search Techniques (continued) The F75 has two controls on the front panel, MENU and SETTINGS. HOT ROCKS MENU Pushbutton (Red button on right of the front panel) A hot rock is a rock which causes the metal detector to sound off because the rock contains iron minerals. -
Page 13: Menu System
LIMITED LIMITED Comprehensive Operating Manual & Guide to Metal Detecting Comprehensive Operating Manual & Guide to Metal Detecting Search Techniques (continued) The Menu System NUISANCE BURIED OBJECTS The entire menu is printed on the LCD display. The display highlights the mode and settings In some areas there is a lot of metallic trash which produces weak signals. -
Page 14: Ground Balancing
LIMITED LIMITED Comprehensive Operating Manual & Guide to Metal Detecting Comprehensive Operating Manual & Guide to Metal Detecting Ground Balancing Search Techniques (continued) Estimating Target I.D. What is Ground Balancing? All soils contain minerals. Signals from ground minerals are often tens or hundreds of times With a single sweep over a target, you will usually see a 2-digit target ID displayed on the LCD. -
Page 15: Manual Ground Balancing
LIMITED LIMITED Comprehensive Operating Manual & Guide to Metal Detecting Comprehensive Operating Manual & Guide to Metal Detecting Search Techniques (continued) Ground Balancing (continued) MANUAL GROUND BALANCING Position the searchcoil an inch or two (2.5-5cm) above the ground, and to the side of the In most situations, it is preferable to push the trigger switch to activate FASTGRAB automatic target. - Page 16 In areas which have been pounded to death and were seemingly hunted out, even by the predecessor version of the Fisher F75, the Boost process can make such sites productive POSITIVE RESPONSE again.
-
Page 17: Motion All Metal Mode
LIMITED LIMITED Comprehensive Operating Manual & Guide to Metal Detecting Comprehensive Operating Manual & Guide to Metal Detecting Search Techniques Motion All Metal Mode Sweeping Searchcoil (this does not The Motion All Metal mode is more sensitive and offers better feel than the Discrimination apply to Pinpointing with the trigger mode, and is used to find all metal objects present in the ground. -
Page 18: Static All Metal Mode
LIMITED LIMITED Comprehensive Operating Manual & Guide to Metal Detecting Comprehensive Operating Manual & Guide to Metal Detecting Static All Metal Mode Capabilities And Limitations (continued) STEEL BOTTLE CAPS & FLAT IRON TRASH This mode is useful for finding large, deep objects, i.e. larger than a coin and deeper than 12 Modern motion-type target ID metal detectors usually have difficulty consistently identifying inches (30cm). -
Page 19: Discrimination Mode
LIMITED LIMITED Comprehensive Operating Manual & Guide to Metal Detecting Comprehensive Operating Manual & Guide to Metal Detecting Capabilities And Limitations (continued) Discrimination Mode GROUND BALANCING The Discrimination Mode is used to eliminate trash metal objects from detection, e.g. nails, To achieve maximum depth in any detection mode, as well as when using the PinPoint aluminum foil, or pull-tabs. -
Page 20: Capabilities And Limitations
LIMITED LIMITED Comprehensive Operating Manual & Guide to Metal Detecting Comprehensive Operating Manual & Guide to Metal Detecting Discrimination Mode (continued) Capabilities And Limitations NOTCH DEPTH Unlike Discrimination Level, which eliminates all targets from the left of the scale to the right, The F75 can detect U.S. -
Page 21: Frequency Shifting
LIMITED LIMITED Comprehensive Operating Manual & Guide to Metal Detecting Comprehensive Operating Manual & Guide to Metal Detecting Frequency Shifting Discrimination Mode (continued) Using DISC LEVEL in conjunction with NOTCH gives you a great deal of flexibility in deciding One disadvantage of a highly sensitive metal detector is its susceptibility to electrical which values to include or exclude from detection. - Page 22 LIMITED LIMITED Comprehensive Operating Manual & Guide to Metal Detecting Comprehensive Operating Manual & Guide to Metal Detecting Discrimination Mode (continued) LCD Visual Display (continued) FOUR DIFFERENT AUDIO TONES This selection is similar to 3, but with a fourth medium- BATTERY CONDITION INDICATOR high tone for targets in the numeric range of 53 to 65.
- Page 23 LIMITED LIMITED Comprehensive Operating Manual & Guide to Metal Detecting Comprehensive Operating Manual & Guide to Metal Detecting LCD Visual Display (continued) Discrimination Mode (continued) CL: CACHE LOCATING PROCESS Since different metal objects can produce similar signals, and since minerals in the soil can This process is an enhanced sensitivity, slow-speed, version of the dE (default) process.
-
Page 24: Lcd Visual Display
"zinc penny". The LCD screen will then holes you will dig. Fisher Research Labs offers the FPoint™ pinpointer, a robust and illuminate the block above “ZINC”...
