ducting kits are optional accessories and have to be ordered, they are not automatically supplied with
the chimney hood.
IN THE EXTRACTION MODE:
a- Fit the non-return backflow flaps C over the round outlet item 6 on top of the canopy while pressing
down until they snap into position, and then connect the ducting 150mm (6 INS) and secure the connec-
tions with appropriate clamping rings or adhesive tape (Fig. 8).
b- Make the electrical connection of the remote motor as described in the section titled ELECTRICAL.
c- Fit the remote motor inside the structure.
d- Connect the electrical plug of the remote motor cord on the body hood and the earthing connection
(Fig.7).
e- Check the connectors of the motor (Fig 9).
f- Place the canopy under the structure and fix it with the screws provided as illustrated in Fig. 10.
Attention: 2 persons are necessary to secure this operation.
g- Test the lights and the fan motor.
h- Fit the metal grease filters and close the deflector.
IN THE RECIRCULATION MODE:
a- To carry out an inlet for recycling air in the kitchen (Fig.11).
b- Connect the ducting 150mm (6 INS) not provided between motors item 6 and the recirculation spigot
and secure the connections with appropriate clamping rings or adhesive tape (Fig. 12).
c- Make the electrical connection of the remote motor as described in the section titled ELECTRICAL.
d- Fit the remote motor inside the structure.
e- Connect the electrical plug of the remote motor cord on the body hood and the earthing connection
(Fig.7).
f- Check the connectors of the motor (Fig 9).
g- Place the canopy under the structure and fix it with the crews provided as illustrated in Fig. 10.
Attention: 2 persons are necessary to secure this operation.
g- Test the lights and the fan motor.
h- Fit the metal grease filters and close the deflector.
i- Fit the cardridge bracket and then the charcoal filter (Fig. 13).
j- Fit the metal grease filters and close the deflector.
