Roberts Gemini 28 RD-28CFM Instructions Manual

Dab digital radio
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
RD-28CFM
DAB digital radio
Please read this manual before use

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Gemini 28 RD-28CFM and is the answer not in the manual?

Questions and answers

Related Manuals for Roberts Gemini 28 RD-28CFM

Summary of Contents for Roberts Gemini 28 RD-28CFM

  • Page 1 RD-28CFM DAB digital radio Please read this manual before use...

  • Page 2: Table Of Contents

    Contents Controls ................2 Battery operation ..............3 Mains operation ..............3 Operating your radio ............4 Selecting a station ..............5 Secondary services ............6 Display modes ..............6 Finding new stations ............7 Autoselect ................7 Manual tuning ..............8 Signal strength display ............8 Classic FM button ...............9 System reset ..............10 Headphone socket ............11 Line out socket ..............11...

  • Page 3: Controls

    Controls (Top) 1. On/Off button 7. Classic FM button 2. Mains LED indicator 8. Info button 3. Line out socket (on rear) 9. Select button 4. Telescopic aerial (on rear) 10. Auto Tune button 5. Headphone socket (on end) 11. Liquid crystal display (LCD) 6.

  • Page 4: Battery Operation

    Battery operation 1. Remove the Battery cover on the rear of the unit by pushing the battery door in and downwards. 2. Insert six LR14 (C size) batteries into the spaces in the compartment. Take care to ensure all batteries are inserted with the correct polarity as shown inside the battery compartment.

  • Page 5: Operating Your Radio

    2. Press the On/Off button to switch on your radio. The display will show Roberts DAB digital radio for a few seconds. 3. If this is the fi rst time the radio is used a quick scan of UK Band III DAB channels will be carried out.

  • Page 6: Selecting A Station

    Selecting a station 1. The top line of the display shows the name of the station currently selected. 2. Rotate the Tuning control to scroll through the list of available sta- tions. 3. Press and release the Select button to select the station. The display may show Tuning while your radio fi...

  • Page 7: Secondary Services

    Secondary services 1. Certain radio stations have one or more secondary services associ- ated with them. If a station has a secondary service associated with it the display will show > next to the station name on the station list. The secondary service will then appear immediately after the primary service as you turn the tuning control.

  • Page 8: Finding New Stations

    Finding new stations As time passes new stations may become available. To fi nd new stations proceed as follows:- 1. Press and release the Auto Tune button, the display will show Autotune Quick scan. Your radio will perform a scan of the UK DAB frequencies. As new stations are found the station counter on the right-hand side of the display will increase and stations will be added to the list.

  • Page 9: Manual Tuning

    Manual tuning Manual tuning allows you to tune directly to the various Band III DAB chan- nels. UK DAB stations are currently located in the range 11B to 12D. 1. Press and hold down the Select button until the display shows Manual tune.

  • Page 10: Classic Fm Button

    Classic FM button Your radio is fi tted with a button which when pressed will automatically tune your radio to Classic FM on the DAB waveband. 1. Press the Classic FM button. 2. Your radio will automatically tune to Classic FM. Note: If Classic FM is not available in your area the display will show "Not Found".

  • Page 11: System Reset

    1. Switch off your radio 2. Switch on your radio - before the screen shows Roberts DAB digital radio press and hold down the Select button until the display shows System Reset.

  • Page 12: Headphone Socket

    Headphone socket A 3.5mm Headphone Socket located on the right-hand end of your radio is provided for use with either headphones or an earpiece. Inserting a plug automatically mutes the internal loudspeaker. Line out socket A 3.5mm Line out socket located on the rear of your radio is provided for connecting the audio signal to an external amplifi...

  • Page 13: General

    General Do not allow this radio to be exposed to water, steam or sand. Do not leave your radio where excessive heat could cause damage such as in a parked car where the heat from the sun can build up even though the outside temperature may not seem too high.

  • Page 14: Mains Supply

    When replacing the fuse only a 3A ASTA approved to BS1362 type should be used and be sure to re-fi t the fuse cover. IF IN DOUBT - CONSULT A QUALIFIED ELECTRICIAN. Replacement fuse holders are available from Roberts Radio Technical Services at the address shown on the rear of this manual.

  • Page 15: Guarantee

    Company’s service department for attention. In the event that it is not possible to return the instrument to the Roberts' dealer from whom it was purchased, please contact Roberts Radio Technical Services at the address shown on the rear of this manual.
  • Page 16 ROBERTS RADIO TECHNICAL SERVICES 97-99 Worton Road Isleworth Middlesex TW7 6EG Technical Helpline :- 020 8758 0338 (Mon-Fri during offi ce hours) Website: http://www.robertsradio.co.uk Issue 1...
