All about the

Use

of your

Important Safety Information........................2

Features.........................................................4

Installation......................................................5

Door Removal................................................7

Door Handle Installation.................................9

Water Supply Connection..............................10

Controls and Settings....................................12

www.frigidaire.com USA 1.800.374.4432

Care

Refrigerator

TA B L E O F C O N T E N T S

Automatic Ice and Water Dispenser............20

Storage Features..........................................26

Normal Operating Sounds and Sights.........28

Filter Replacement.......................................29

Care and Cleaning.......................................32

Troubleshooting.............................................36

Warranty......................................................41

www.frigidaire.ca Canada 1-800-265-8352

Need help?

Do you have a question about the FGSS2335TF9 and is the answer not in the manual?

Questions and answers

Summary of Contents for Frigidaire FGSS2335TF9

Page 1 Important Safety Information……………………2 Automatic Ice and Water Dispenser…………20 Features…………………………………………………4 Storage Features……………………………………26 Installation………………………………………………5 Normal Operating Sounds and Sights………28 Door Removal…………………………………………7 Filter Replacement…………………………………29 Door Handle Installation……………………………9 Care and Cleaning…………………………………32 Water Supply Connection…………………………10 Troubleshooting………………………………………36 Controls and Settings………………………………12 Warranty………………………………………………41 www.frigidaire.com USA 1.800.374.4432 www.frigidaire.ca Canada 1-800-265-8352...
Page 2 IMPORTANT SAFETY INFORMATION WARNING Installation Checklist Please read all instructions before using Doors this refrigerator.  Handles are secure and tight Definitions  Door seals completely to cabinet on This is the safety alert symbol. It is used all sides to alert you to potential personal injury haz- ...
Page 3 IMPORTANT SAFETY INFORMATION Proper Disposal of your Appliance receptacle must be installed in accordance with local codes and ordinances. Consult a Risk of child entrapment qualified electrician. Avoid connecting refrig- erator to a Ground Fault Interrupter (GFI) Child entrapment and suffocation are not circuit. Do not use an extension cord or problems of the past.
Page 4 Special Item Small Rack Basket Meat Keeper Large and Cover Glide Out Basket Can Rack Crisper Pan and Cover Fixed Door Bin Toe Grille IMPORTANT Features not included with your refrigerator can be purchased at www.frigidaire.com or by calling 1-800-944-9044.
Page 5 INSTALLATION Toe Grille Installation and Removal This Use & Care Guide provides general operating instructions for your model. Use the To install toe grille refrigerator only as instructed in this Use & Care Guide. Before starting the refrigerator, 1 Open both doors. Slide left and right sides of follow these important first steps.
Page 6 INSTALLATION Door Opening To level the doors using the adjustable lower hinge (some models): NOTE  1 Before leveling either door, remove set screw that locks door height into position. he refrigerator doors are designed to shut (The door cannot be adjusted without set by themselves within a 20 degree opening.
Page 7 DOOR REMOVAL 4 Close the doors. Tools Necessary: To remove the refrigerator top hinge cover: 1 Remove the three screws from each cover over the top door hinges. 2 Lift hinge cover straight up and off. Rear Cover Front Cover Screw Screws Phillips™ Hinge Head Cover Hinge Screws Hinge...
Page 8 DOOR REMOVAL 3 Remove the 2 bottom hinge screws and connector releases when you press its hinge if necessary. outer sleeve inward. 4 Remove the screws from the top hinge Door and pull the multi-wire cable through it. Lift the door off of the bottom hinge. Hinge 5 Remove the 2 bottom hinge screws and Assembly hinge if necessary.
Page 9 DOOR HANDLE INSTALLATION Frigidaire Professional ® CAUTION Freezer Upper Refrigerator Upper End Cap End Cap Wear gloves and safety goggles and use extreme CAUTION when installing these handles. The rounded end of the handles may be sharp (some models). IMPORTANT...
Page 10 CAUTION your new refrigerator. Depending on your local/state building codes, Frigidaire To Avoid Property Damage: recommends for homes with existing valves its Smart Choice water line kit ®...
Page 11 WATER SUPPLY CONNECTION 5 With steel clamp and screw, secure water Plastic Water Steel supply line (copper tubing only) to rear Tubing to Ice Clamp panel of refrigerator as shown. Maker Fill Brass Tube Compression 6 Coil excess water supply line (copper tubing only), about 2½...
Page 12 CONTROLS AND SETTINGS Display Default Settings 1 The default setting of the refrigerator display activates upon touch and fades away the temperature settings after 10 seconds. 2 To reawaken the temperature settings, simply select “^/v” or “+/-“ buttons on the display. After 10 seconds the display will fade, excluding the ice/water selection LED.
Page 13 FRIGIDAIRE AND CONTROLS FRIGIDAIRE GALLERY AND SETTINGS User Interface (varies by model) Operating the Controls Press Options key Use Arrow keys ^/ᴠ to scroll the menu selections Use the + or - keys to change the option from on/off/change temperature or mode ºF/ºC Use the Options key to exit and save changes ...
Page 14 CONTROLS FRIGIDAIRE AND AND SETTINGS FRIGIDAIRE GALLERY User Interface (varies by model) Operating the Controls Press Options key Use Arrow keys ^/ᴠ to scroll the menu selections Press and hold Set key for 3 seconds Use the Options key to exit and save changes power off Press and hold Set for 3 seconds to turn off the cooling system. It...
Page 15 FRIGIDAIRE AND CONTROLS FRIGIDAIRE GALLERY AND SETTINGS User Interface (varies by model) Operating the Controls To activate features press the corresponding icon key on the display water Press the Water key to select water. Indicator light will be illuminated above the active feature.
Page 16 FRIGIDAIRE AND CONTROLS AND SETTINGS FRIGIDAIRE GALLERY Alarms Sabbath Mode The Sabbath Mode is a feature that disables Power In the event of a power failure, portions of the refrigerator and its controls Failure the power fail alert will be in accordance with observance of the weekly illuminated.
Page 17 FRIGIDAIRE CONTROLS PROFESSIONAL AND SETTINGS User Interface In-Door Controls (options may vary) POWER Press and hold for three seconds to turn ON-OFF off the cooling system. It also turns off the ice maker and all dispenser func- tions. The display will read “OFF”. DEFAULT Press and hold for three seconds to...
Page 18 FRIGIDAIRE CONTROLS AND SETTINGS PROFESSIONAL Dispenser Controls Alarms (options may vary) Power Failure In the event of a power failure, the “POWER FAIL” alert will be illuminated. Press “MUTE ALARM” to acknowledge the alarm. Other modes may be turned off until the alarm is acknowl- edged. While a “POWER FAIL” alert is displayed on the control panel, the unit will continue normal operation.
Page 19 FRIGIDAIRE CONTROLS PROFESSIONAL AND SETTINGS Sabbath Mode The Sabbath Mode is a feature that disables portions of the refrigerator and its controls in accordance with observance of the weekly Sabbath and religious holidays within the Orthodox Jewish community. Sabbath Mode is turned ON and OFF by simultaneously pressing and holding both the freezer “-”...
Page 20 AUTOMATIC ICE AND WATER DISPENSER FRIGIDAIRE & FRIGIDAIRE GALLERY Priming the Water Supply System Ice Production: What to Expect How much ice will a side-mounted ice Your refrigerator’s water supply system maker produce in 24 hours? includes several tubing lines, an advanced...
Page 21 AUTOMATIC ICE AND WATER DISPENSER FRIGIDAIRE & FRIGIDAIRE GALLERY Turning the REAR MOUNTED Ice Ice Maker/Dispenser Tips Maker On and Off • Ice cubes stored too long may develop an odd flavor. Empty the ice container as Ice production is controlled by the ice maker’s explained below.
Page 22 AUTOMATIC ICE AND WATER DISPENSER FRIGIDAIRE & FRIGIDAIRE GALLERY Cleaning the Ice Maker IMPORTANT Clean the ice maker and ice bin at regular When removing or replacing the ice bin, intervals, particularly before you take a ensure that the ice bin is fully seated before vacation or move.
Page 23 AUTOMATIC ICE AND WATER DISPENSER FRIGIDAIRE PROFESSIONAL Priming the water supply system Ice Maker and Storage Bin Capacity CAUTION This ice maker should produce 2.5 to 3 pounds of ice per 24 hours, depending on usage For proper dispenser operation, recommended conditions.
Page 24 AUTOMATIC ICE AND WATER DISPENSER FRIGIDAIRE PROFESSIONAL Using the ice maker after Ice maker/dispenser tips installation • If your refrigerator is not connected to a water supply or the water supply is turned Before making ice for the first time, be sure off, turn off the ice maker as described in to prime the water supply system. Air in new the previous section.
Page 25 AUTOMATIC ICE AND WATER DISPENSER FRIGIDAIRE PROFESSIONAL Cleaning the storage bin Remove and empty the ice bin if: • An extended power failure (one hour or Clean the ice longer) causes ice cubes in the ice bin to maker and ice...
Page 26 STORAGE FEATURES The dairy compartment, which is warmer than CAUTION the general food storage section, is intended for short term storage of cheese, spreads, or butter. To avoid personal injury or property damage, Fresh Drawers with Humidity handle tempered glass shelves carefully. Control (some models) Shelves may break suddenly if nicked, scratched, or exposed to sudden temperature...
Page 27 STORAGE FEATURES Chill Drawer (some models) Some models are equipped with a Chill Drawer. Chill Drawer temperatures can be adjusted by sliding the Chill Drawer Temperature Control in either direction. Use this pan for short term storage of bulk meat items. If meats are to be kept longer than one or two days, they should be frozen. The Chill Drawer is fixed and cannot be moved up or down. If fruits or vegetables are to be stored in the Chill Drawer, set the Chill Drawer Temperature Control to a warmer setting to prevent freezing.
Page 28 NORMAL OPERATING SOUNDS AND SIGHTS Understanding the Sounds you  NOTE may Hear Energy efficient foam in your refrigerator is Your new, high-efficiency refrigerator may not a sound insulator. introduce unfamiliar sounds. These sounds normally indicate your refrigerator is operating  NOTE correctly. Some surfaces on floors, walls, and kitchen cabinets may make these sounds more During automatic defrost cycle, a red glow noticeable.
Page 29 4 Slide the housing back into position. Air Filter Ordering Replacement Filters To order your replacement filters, please visit our online store at www.frigidaire.com/store, by calling toll-free at 877-808-4195, or by visiting the dealer where you purchased your refrigerator. Frigidaire recommends that you order extra filters when you first install your refrigerator, and that you replace your filters at least once every six months.
Page 30 FRIGIDAIRE FILTER REPLACEMENT PROFESSIONAL More about your Advanced 7 After filling one glass of water, continue flushing the system for about four Water Filter minutes. 8 Turn On the ice maker. The PureSource Ultra ice and water filter system is tested and 9 Press and hold the Water Filter button certified to NSF/ANSI Standards on the Ice & Water Dispenser control 42, 53 and 401 for the reduction panel for three seconds.
Page 31 3 Slide the old filter cartridge straight out of Ordering Replacement Filters the housing and discard it. 4 Unpackage the new filter cartridge. Slide it To order your replacement filters, please visit into the filter housing as far as it will go with our online store at www.frigidaire.com/store, the grip end horizontal. by calling toll-free at 1-800-599-7569, or by 5 Push lightly inward on the filter while rotating visiting the dealer where you purchased your it clockwise (to the right). The filter will then refrigerator.
Page 32 CARE AND CLEANING Protecting your investment Keeping your refrigerator clean maintains appearance and prevents odor build-up. Wipe up any spills immediately and clean the freezer and fresh food compartments at least twice a year. When cleaning, take the following precautions: •...
Page 33 CARE AND CLEANING Care and Cleaning Tips Part Cleaning Tips and Precautions Agents Interior & • Soap and water • Use two tablespoons of baking soda in one quart of Door Liners warm water. • Baking soda and water • Be sure to wring excess water out of sponge or cloth before cleaning around controls, light bulb or any electrical part.
Page 34 Frigidaire parts for replacement. Ordering Replacement LED Lights To replace LED Lights: Order new LEDs by calling 877-808-4195, online at www.frigidaire.com/store, or through 1 Unplug your refrigerator’s power cord. the dealer where you bought the refrigerator. 2 Remove lens cover.
Page 35 CARE AND CLEANING Replacing light bulbs (select models) Both the freezer and fresh food compartments of your refrigerator include light bulbs that Water will need replacing from time to time. Some Filter lights have covers that you will need to remove Bulbs before replacing the bulbs.
Page 36 CAUSE SOLUTION AUTOMATIC ICE MAKER Ice maker is • Ice maker is turned off. • Turn on ice maker. For the Frigidaire not making any Professional ice maker, press and hold the ice. “ON-OFF” button for three seconds until the indicator light is on. For the Frigidaire &...
Page 37 TROUBLESHOOTING CONCERN CAUSE SOLUTION AUTOMATIC ICE MAKER (Continued) Ice maker is • The Frigidaire ice maker produces • Ice maker is producing not making less ice than you expect. approximately 4 to 4.5 pounds of ice every enough ice. 24 hours depending on usage conditions.
Page 38 • Press and hold control lock for three not dispense engaged. (Does not apply seconds. water. to Frigidaire Professional.) • Water filter not seated • For Frigidaire & Frigidaire Gallery, remove properly. and reinstall the water filter. Be sure to push the filter firmly so that you hear it lock solidly into position. For Frigidaire Professional, remove and reinstall the water filter. Be sure to press inward as you rotate it clockwise to lock it in place.
Page 39 TROUBLESHOOTING CONCERN CAUSE SOLUTION DISPENSER (Ice & Water) (Continued) Water pressure • Cut-off and cut-on • Have someone turn up the cut-off and cut- is extremely pressures are too low on pressure on the water pump low. (well systems only). system (well systems only). • Reverse osmosis system • It is normal for a reverse osmosis system is in regenerative phase.
Page 40 Compressor) faster, such as after a (Some Models) defrost cycle. DIGITAL TEMPERATURE DISPLAY Digital • Electronic control system • Call your Frigidaire service representative, temperature has detected a who can interpret any messages or number displays are performance problem. codes flashing on the digital displays.
Page 41 Obligations for service and parts under this warranty must be performed by Electrolux or an authorized service company. Product features or specifications as described or illustrated are subject to change without notice. Canada 1.800.265.8352 1.800.374.4432 Electrolux Canada Corp. Frigidaire 5855 Terry Fox Way 10200 David Taylor Drive Mississauga, Ontario, Canada Charlotte, NC 28262 L5V 3E4...
