- Page 1 OPERATING AND MAINTENANCE MANUAL MV800 NOTICE: The complete user manual is available at the following address: XXXXXXXXXXXXXXXXXX MAN_MV800_QUICK_EN_IT_IS_R04_1.02.XXXX...
- Page 2 SAFETY CONVENTION DANGER ELECTRIC SHOCK WARNING PRECAUTIONS ATTENTION TECHNICAL CHARACTERISTICS ELECTRIC CHARACTERISTICS Instrument classification: class I, IP67/IP68 installation category II, rated pollution degree 2. Power Power supply voltage min10 / 30max V Voltage variations must not exceed ±10% of the nominal one. ‰...
- Page 3 ENVIRONMENTAL USE CONDITIONS The instrument can be installed inside or outside buildings ‰ Altitude: from –200m to 2000m (from -656 to 5602 feet) ‰ Humidity range: 0-100% (IP 67) ‰ E N V I R O N M E N T A L LIQUID TEMPERATURE TEMPERATURE Min.
- Page 4 ELECTRICAL CONNECTIONS VERSION WITH CABLE 1 (+) POWER SUPPLY 2 (+) OUTPUT 1 / INPUT 3 (+) OUTPUT 2 (OPTIONAL) 4 (+) 4-20mA max load: 500 Ω OUTPUT (OPTIONAL) 5 (-) POWER SUPPLY / OUTPUTS / INPUT 6 SHIELD (CONNECT TO GROUND) PIN 5-6 TO BE CONNECT TO THE GROUND VERSION WITH CONNECTOR 1 (+) POWER SUPPLY...
- Page 5 GROUNDING ALWAYS ensure that the instrument is grounded (earthed) correctly. The grounding ensures that the equipment and liquid are equipotential. POWER SUPPLY ENERGIEVERSORGUNG + ENERGIEVERSORGUNG - ‰ Before connecting the power supply, verify that the mains voltage is within the limits indicated on data plate. ‰...
- Page 6 OUTPUTS WIRING DIGITAL OUTPUTS 2 (Out1) 3 (Out2) ‰ Opto-insulated output ‰ Maximum switching voltage: 30V ‰ Maximum switching current: 100mA @ 25 °C ‰ Maximum saturation voltage between collector and emitter @100mA: 1.2V ‰ Maximum switching frequency (load 5 (-) on the collector or emitter, RL=470, VOUT=24V...
- Page 7 DISPLAY VISUALIZATION The direct exposure of the converter to the solar rays, could damage the liquid crystal display. No display pages are provided. m³/h gal/min m³ EMPTY PIPE WARNING ALARM WARNING PROCESS ALARM DATA TRANSMISSION FLOW DIRECTION ACTIVE FLOW RATE FLOW RATE MEASURE UNIT m³/h gal/min...
- Page 8 ACCESS TO THE CONFIGURATION MENU You can access the drive configuration menu only by MCP interface. It is a software that can be installed on Microsoft Windows® and allows you to set all the functions of the converter and customize the menu.
- Page 9 START VISUALIZATION PAGES ON MCP INTERFACE Electrode 2 resistance Electrode 1 resistance Video term. connected Flow speed % full scale Flow rate graph Flow rate value Flow rate trend Alarms list page Partial net totalizer Total net totalizer Reverse total totalizer Direct total totalizer Reverse partial totalizer Direct partial totalizer...
- Page 10 CONVERTER ACCESS CODE The access for programming the instrument is regulated by six access levels logically grouped. Every level is protected by a different code. ‰ Access Level 1-2-3-4 Freely programmable by user Access Code Set : Menu 13 System The CODE is inserted by keyboard or MCP interface.
- Page 11 MANUAL REVIEWS REVIEW DATE DESCRIPTION MV800_QUICK_EN_IT_R0_1.00.0 09/10/2017 First edition MV800_QUICK_EN_IT_R1_1.00.0 02/11/2017 Insert ground reference on electrical wiring MV800_QUICK_EN_IT_R2_1.02.0 17/07/2020 Software update MAN_MV800_QUICK_EN_IT_R03_1.04. 15/04/2021 Manual restored, 4-20 output graph added, graphic update XXXX MAN_MV800_QUICK_EN_IT_R04_1.04. 08/10/2021 Changes to data relating to digital output XXXX MAN_MV800_QUICK_EN_IT_IS_R04_1.02.XXXX 8 di 11...
- Page 12 MAN_MV800_QUICK_EN_IT_IS_R04_1.02.XXXX 9 di 11...
- Page 13 At the end of its lifetime, this product shall be disposed of in full compliance with the environmental regulations of the state in which it is located. MAN_MV800_QUICK_EN_IT_IS_R04_1.02.XXXX 10 di 11...
- Page 14 ISOIL INDUSTRIA S.p.A. HEAD OFFICE SERVICE Via Fratelli Gracchi, 27 20092 Cinisello Balsamo (MI) Tel +39 02 66027.1 service@isoil.it Fax +39 02 6123202 sales@isoil.it If you want to find the complete list of our distributors access at the following link: http://www.isoil.it/en...
