Delta Children Dresser With Changing Top Assembly Instructions Manual

Delta Children Dresser With Changing Top Assembly Instructions Manual

Hide thumbs Also See for Dresser With Changing Top:

Advertisement

Quick Links

Download this manual
Read all instructions
before assembly and use.
KEEP INSTRUCTIONS FOR
FUTURE USE.
EN
Style #:
___________
Lot:
___________
E
REV
Date:
___________
Before contacting Delta Consumer
Experience Center please ensure this
information matches the information
found on the label on the Back Panel.
To Make Assembly Even
Easier Watch Video Here!
ADULT ASSEMBLY REQUIRED
Due to the presence of small parts during assembly,
keep out of reach of children until assembly is complete.
This product is not intended for institutional or commercial use.
Dresser With
Changing Top
For Questions or
to Contact Us:
DeltaChildren.com/Help
If unable to access website, please email
wcs@DeltaChildren.com
Expect longer response times via email.
June 26, 2024, 45801, R0

Advertisement

loading
Need help?

Need help?

Do you have a question about the Dresser With Changing Top and is the answer not in the manual?

Questions and answers

Related Manuals for Delta Children Dresser With Changing Top

Summary of Contents for Delta Children Dresser With Changing Top

  • Page 1 Dresser With Changing Top Read all instructions For Questions or To Make Assembly Even before assembly and use. to Contact Us: Easier Watch Video Here! DeltaChildren.com/Help KEEP INSTRUCTIONS FOR FUTURE USE. If unable to access website, please email wcs@DeltaChildren.com Expect longer response times via email. Style #: ___________ ADULT ASSEMBLY REQUIRED...
