- Page 1 HDO Grill Gazebo Model No.: A103001403 WE HAVE YOU IN MIND, LET US SERVE YOU! Questions? Issues? CONTACT US 24 hours / 7 days a week www.sunjoyonline.com fredmeyer@sunjoygroup.com 1-(866)-578-6569...
- Page 2 GENERAL BEST PRACTICES FOR ASSEMBLY • Please read and understand this entire manual before attempting to assemble or install the product. • Before beginning assembly of product, make sure all parts are present. Compare parts with package contents list and hardware contents list. If any part is missing or damaged, do not attempt to assemble the product. • The assembled gazebo should be located at least 6 feet from any obstruction such as fence, garage, house, overhanging branches, laundry lines or electrical wires. • Some parts may contain sharp edges. Wear protective gloves if necessary, during assembly. • Check all nuts and bolts periodically for tightness and, when required, tighten them again. • Pay attention to the parts orientation. MAINTENANCE • Install the gazebo on level ground. Stakes are provided to secure the gazebo to the ground. • Do not assemble the gazebo on sandy, muddy or loose soil, as stakes do not have enough anchorage in these types of soil. • If you wish to secure the gazebo to a wood deck or concrete surface, use anchors suited to these surfaces. • Snow must be cleared off regularly during snowy days. • Do not leave the gazebo where there is a risk of high wind, as possible damage will occur to the structure. • Any assembly or maintenance of the product must be carried out by adults only. • Please check your state and local regulations prior to purchasing. Some jurisdictions may require permits for installation and use. Some special procedures may be valid in your area. • Keep all flame and heat sources away from the tent fabric. This tent is made with fabric that meets CPAI‐84 specifications for flame resistance. It is not fire proof. The fabric will burn if right in continuous contact with any flame source. The application of any foreign substance to the tent fabric may render the flame resistant properties ineffective.
- Page 3 WARNINGS • Steel components for this gazebo are treated with rust inhibiting paint that protects it from rusting. However, due to the nature of steel, surface oxidation (rusting) will occur if these protective coatings are scratched. This is not a defect and thus not covered by the warranty. • To minimize this condition, it is recommended to use care when assembling and handling the product to prevent scratching the paint. Should any scratching or damage occur, it is recommended to cover the scratch immediately with rust inhibiting paint (not included). • Surface rust can also be easily removed with a very light application of regular cooking oil or WD‐40. If surface oxidation (rusting) occurs and if no measure is taken to prevent this, the oxidation may start dripping onto deck or patio and caused damaging stains, which may be difficult to remove. This can be prevented if the above‐mentioned measures are taken to keep the product from oxidizing. • Do not use bleach, acid, or other abrasive cleaners on the roof or frame parts. • Keep instruction manual for future reference. • Keep the original packaging to store the gazebo. • Periodically check and ensure that all bolts are well‐tighten during use. Tools Needed (Not Included) Included ...
- Page 4 Exploded Drawing...
- Page 5 Parts List Label Part Number Description Part Image P000200540 Post (1) P000200541 Post (2) P000501497 Small Top Connector P000501498 Big Top Connector Slant Beam For Small P000601819 Roof P000601820 Slant Beam For Big Roof P000401041 Long Screen P000401042 Short Screen P002100414 Table Top 1 P005800001...
- Page 6 Hardware Pack Label Part Number Description Spare Part Image H010020011 Bolt M6*15 H050030001 Flat Washer M6 H010020022 Bolt M6*40 H040010004 Nut M6 H070010005 Stake ￠6*230 H090010017 M6 Wrench...
- Page 19 Country of Origin: China n: Chin Production Number: 2021200027...
