- Page 1 ADP086-1 ADP086-2 USB 3.0 and SATA Adapter for PCIe/104 and PCI/104-Express Type 2 User’s Manual BDM-610040013 Rev. B RTD Embedded Technologies, Inc. AS9100 and ISO 9001 Certified...
- Page 2 RTD Embedded Technologies, Inc. 103 Innovation Boulevard State College, PA 16803 USA Telephone: 814-234-8087 Fax: 814-234-5218 www.rtd.com sales@rtd.com techsupport@rtd.com...
- Page 3 Failure to follow the instructions found in this manual may result in damage to the product described in this manual, or other components of the system. The procedure set forth in this manual shall only be performed by persons qualified to service electronic equipment. Contents and specifications within this manual are given without warranty and are subject to change without notice. RTD Embedded Technologies, Inc. shall not be liable for errors or omissions in this manual, or for any loss, damage, or injury in connection with the use of this manual.
- Page 4 Functional Description Functional Diagram ................................... 13 Backwards Compatibility with USB 2.0 ............................. 13 Power ......................................13 Troubleshooting Additional Information PC/104 Specifications ................................15 PCI and PCI Express Specification ............................15 Limited Warranty | www.rtd.com ADP086 User’s Manual RTD Embedded Technologies, Inc.
- Page 5 Table of Figures Figure 1: ADP086-1 ........................................6 Figure 2: ADP086-2 ........................................6 Figure 3: Board Dimensions (inches) ..................................9 Figure 4: Board Connections ....................................10 Figure 5: Example 104™Stack ....................................12 Figure 6: ADP086 Functional Diagram ................................... 13 Table of Tables Table 1: Ordering Options ......................................
- Page 6 PCIe/104 Type 2 bus. The ADP086’s utilization of a host’s PCIe/104 USB links avoids bandwidth starvation of the host’s primary USB I/O connections, making this module a useful accessory to any of RTD’s single board computers that poses a PCIe/104 Type 2 connector.
- Page 7 If you are having problems with your system, please try the steps in the Troubleshooting section of this manual. For help with this product, or any other product made by RTD, you can contact RTD Embedded Technologies technical support via the...
- Page 8 If supported by the host, 5V Standby may be used to power the board when the main power supply is turned off, permitting a means for USB to wake the system in low power modes. It is not required for board operation. | www.rtd.com ADP086 User’s Manual RTD Embedded Technologies, Inc.
- Page 9 When removing it from the bag, hold the board at the edges, and do not touch the components or connectors. Handle the board in an antistatic environment and use a grounded workbench for testing and handling of your hardware. Physical Characteristics STEP model is available upon request; contact RTD Tech Support for more information. • Weight: Approximately 0.05 Kg (0.11 lbs.) •...
- Page 10 CPU bottom-side port 0 CPU bottom-side port 1 NOTE: For proper operation at USB 3.0 (or USB 2.0) speeds, be sure to use a cable that is rated for USB 3.0 (or USB 2.0) | www.rtd.com ADP086 User’s Manual RTD Embedded Technologies, Inc.
- Page 11 If a USB 3.0 link is used, the ADP086 must be closer to the CPU than any board that uses a USB 2.0 link. For systems with PCI devices, the ADP086-2 (PCI/104-Express) may be required to meet these stacking requirements while allowing the PCI bus to pass through to other boards within the system. | www.rtd.com ADP086 User’s Manual RTD Embedded Technologies, Inc.
- Page 12 10. Attach any necessary cables to the PC/104 stack. 11. Re-connect the power cord and apply power to the stack. 12. Boot the system and verify that all the hardware is working properly. Figure 5: Example 104™Stack | www.rtd.com ADP086 User’s Manual RTD Embedded Technologies, Inc.
- Page 13 ADP086-2 exists to pass through the host’s PCI bus to PCI peripheral devices above or below the ADP086-2. Acceptable voltage ranges for +5V (V ) and +5V Standby (V ) are listed in Table 2: Operating Conditions. cc5-STBY | www.rtd.com ADP086 User’s Manual RTD Embedded Technologies, Inc.
- Page 14 If problems persist, or you have questions about configuring this product, contact RTD Embedded Technologies via the following methods: Phone: +1-814-234-8087 E-Mail: techsupport@rtd.com Be sure to check the RTD web site (http://www.rtd.com) frequently for product updates, including newer versions of the board manual and application software. | www.rtd.com ADP086 User’s Manual RTD Embedded Technologies, Inc.
- Page 15 A copy of the latest PC/104 specifications can be found on the webpage for the PC/104 Embedded Consortium: www.pc104.org PCI and PCI Express Specification A copy of the latest PCI and PCI Express specifications can be found on the webpage for the PCI Special Interest Group: www.pcisig.com | www.rtd.com ADP086 User’s Manual RTD Embedded Technologies, Inc.
- Page 16 RTD Embedded Technologies, Inc. warrants the hardware and software products it manufactures and produces to be free from defects in materials and workmanship for one year following the date of shipment from RTD Embedded Technologies, Inc. This warranty is limited to the original purchaser of product and is not transferable.
- Page 17 RTD Embedded Technologies, Inc. 103 Innovation Boulevard State College, PA 16803 USA Telephone: 814-234-8087 Fax: 814-234-5218 www.rtd.com sales@rtd.com techsupport@rtd.com Copyright 2024 by RTD Embedded Technologies, Inc. All rights reserved.
