- Page 1 WLAN17202ER User's Manual Embedded Wireless LAN 802.11a/b/g PC/104-Plus Module BDM-610020036 Rev. A...
- Page 2 WLAN17202ER User's Manual RTD EMBEDDED TECHNOLOGIES, INC. 103 Innovation Blvd State College, PA 16803-0906 Phone: +1-814-234-8087 FAX: +1-814-234-5218 E-mail sales@rtd.com techsupport@rtd.com Web Site http://www.rtd.com...
- Page 3 Copyright 2005 by RTD Embedded Technologies, Inc. All rights reserved The RTD Embedded Technologies Logo is a registered trademark of RTD Embedded Technologies. dspModule, cpuModule, and utilityModule are trademarks of RTD Embedded Technologies. PC/104, PC/104-Plus, and PCI-104 are registered trademark of PC/104 Consortium. Atheros is a trademark of Atheros Communications.
-
Page 4: Table Of Contents
Table of Contents Introduction ..............................1 Product Overview ............................1 Board Features............................1 PCI Interface ............................1 Physical Attributes..........................1 5004 MP Atheros 4G Mini-PCI Module Features................2 Available Options............................3 Getting Technical Support ......................... 3 Board Hardware ............................4 Block Diagram ............................ - Page 5 Atheros AR5004X Chipset ........................11 IEEE 802.11 WLAN Specifications......................11 Limited Warranty ............................12...
-
Page 6: Introduction
The WLAN17202ER is designed to provide wireless communication for PC/104-Plus and PCI-104 based systems. It communicates via the standard 802.11a/b/g protocols. The WLAN17202ER can be used to connect multiple PC systems together. The WLAN17202ER uses the 5004 MP Atheros 4G Mini-PCI module from Netgate. -
Page 7: 5004 Mp Atheros 4G Mini-Pci Module Features
5004 MP Atheros 4G Mini-PCI Module Features THE FOLLOWING SPECIFICATIONS COME FROM THE NATEGATE DATASHEET FOR THE 5004 MP ATHEROS 4G MINI-PCI MODULE. RTD EMBEDEDED TECHNOLOGIES ASSUMES NO RESPONSIBLILITY FOR ANY ERRORS IN THAT DATA SHEET AND DOES NOT ASSUME RESPONSIBILITY FOR VERIFYING ITS ACCURACY. -
Page 8: Available Options
CSMA/CA with ACK architecture 32-bit MAC Available Options The WLAN17202ER is available as part of a starter kit, bundled with an external antenna and cabling. The WLAN17202ER can also be purchased as an IDAN module for integration into an RTD IDAN system. -
Page 9: Board Hardware
Board Hardware Block Diagram Below is a block diagram of the WLAN17202ER. Primary board components are in bold, while external I/O connections and jumpers are italicized. WLAN17202ER Block Diagram WLAN Main WLAN Aux. External External Mini-PCI WLAN Module PC/104-Plus (PCI) Bus Connector and Jumper Locations The following diagram shows the location of all connectors and jumpers on the WLAN17202ER. -
Page 10: External I/O Connections
External I/O Connections The following sections describe the external I/O connections of the WLAN17202ER. Connector CN1/CN2 - PC/104 ISA Connector CN1/CN2 carries the signals of the PC/104-Plus ISA bus. The signals from this bus are not used on this module. The connector serves as a pass-through to other PC/104 and PC/104-Plus modules. -
Page 11: Pci Bus Signal Description
Interrupts INTA# Interrupt A is used to request Interrupts. INTB# Interrupt B is used to request Interrupts. INTC# Interrupt C is used to request Interrupts. INTD# Interrupt D is used to request Interrupts. WLAN17202ER User's Manual RTD Embedded Technologies, Inc. -
Page 12: Connectors J3 And J4 - Wlan Antenna Connectors
When the PC/104-Plus Specification was first introduced, it only allowed for three PCI add-on cards to be bus masters. Version 2.0 of the PC/104-Plus specification was released in November 2003. This version of the specification (which the WLAN17202ER is designed for) adds support for all 4 PCI slots to be bus masters. - Page 13 Note: The WLAN17202ER comes with jumpers JP1 and JP2 set to position 1-2 by default. This should be compatible with most PC/104-Plus CPUs. There is no need to change these jumpers unless you are having compatibility problems with your specific CPU.
-
Page 14: Board Installation
Board Installation Installing the Hardware The WLAN17202ER can be installed into a PC/104-Plus or PCI-104 stack. It can be located above or below the CPU, as long as all PCI add-on cards are on the same side of the CPU. -
Page 15: Installing Software
Installing Software After physically installing the WLAN17202ER, your operating system must be configured to recognize the new board. Windows Drivers Windows drivers should be included on CD-ROM with the WLAN17202ER. Installation instructions should be provided in the file README.TXT. Follows these instructions to install and configure the software. -
Page 16: Additional Information
For detailed information about the Atheros AR5004X chipset, contact Atheros at: Web: http://www.atheros.com IEEE 802.11 WLAN Specifications A copy of the 802.11 WLAN specifications can be downloaded from the IEEE web site at: Web: http://www.ieee.org WLAN17202ER User's Manual RTD Embedded Technologies, Inc. -
Page 17: Limited Warranty
RTD EMBEDDED TECHNOLOGIES, INC. This warranty is limited to the original purchaser of product and is not transferable. During the one year warranty period, RTD EMBEDDED TECHNOLOGIES will repair or replace, at its op- tion, any defective products or parts at no additional charge, provided that the product is returned, shipping prepaid, to RTD EMBEDDED TECHNOLOGIES.
